Operator's Manual
A-62032
Part No. 3C4923
KODAK
TM
IMAGELINK
Printer 7
BUSINESS IMAGING SYSTEMS

Advertisement

Table of Contents
loading

Related Manuals for Kodak Imagelink Printer 7

Summary of Contents for Kodak Imagelink Printer 7

  • Page 1 Operator's Manual A-62032 Part No. 3C4923 KODAK IMAGELINK Printer 7 BUSINESS IMAGING SYSTEMS...
  • Page 2 The Kodak Imagelink Printer 7, CAT No. 887 9405, with the Kodak Imagelink Printer 7 Paper Supply, CAT No. 859 1943, the Kodak Imagelink Printer 7 Sorter, CAT No. 864 6754, and the Kodak Imagelink Printer 7 Sorter Interface, CAT No. 199 7964, are in conformance...

  • Page 3: Warning And Safety Information

    For a comfortable, healthy, and safe operating environment, it is recommended that the room be well-ventilated. A dedicated electrical socket-outlet shall be installed near the printer and shall be easily accessible. Printer 7 KODAK IMAGELINK...

  • Page 4: Section 1 Overview

    A-62032 November 1996 We are pleased that you have purchased the Kodak Imagelink Printer 7. We feel confident that you will find your new laser printer more than adequate to meet your printing needs. In order to make the best use of the printer, we recommend that you read the information in this manual carefully and follow the instructions contained herein.
  • Page 5 Location/Description of parts—Back 9. Paper Supply Cabinet Right Cover 10. Paper Exit Tray 11. Printer Right Cover 12. Printer Cable Interface Socket 13. Printer Rear Cover 14. Image Transfer/Paper Separator Ozone Filter Cover 15. Paper Supply Cabinet Rear Cover 16. Dataplate 17.
  • Page 6 Location/Description of parts—Inside 20. Vertical Transport Roller Knob (M6) 21. Separator Roller 22. Feed Roller 23. Transport Roller Knob (M5) 24. Transport Section Release Plate (M4) 25. Synchronizing Roller Knob (M3) 26. Toner Bottle Holder 27. Toner Bottle A-62032 November 1996 28.

  • Page 7: Section 2 Operation

    Paper Jam Clear paper jam A-62032 November 1996 Check that the power cord has been connected to the printer and outlet; turn the power ON/OFF switch to its right side ( turn the power on. Turn the power ON/OFF switch to its left side ( power off.

  • Page 8: Loading Paper

    Switch to “Inch” when paper size is 11 x 17" (LedgerT), 8-1/2 x 14" (LegalT), 8-1/2 x 11" (LetterT/Y), 7-1/4 x 10-1/2" (ExecutiveT/Y), 5-1/2 x 8-1/2" (InvoiceT), or 7 x 8 1/2".* All trays must be set to “Inch” if the previous paper sizes are used.
  • Page 9 A-62032 November 1996 3. While holding the cassette, depress and spread the front paper guide wider than the paper size to be used. 4. Slide the green resin plate of the right paper guide toward the right side wider than the paper size to be used. NOTE: Be sure to slide the resin plate and not to hold the lever part, as that may bend it.
  • Page 10 Swing the lift-up plate release lever back into position to lift up the paper lift plate. 7. Push the universal cassette back into position. To attach the paper exit tray, insert the two hooks of the paper exit tray into the lower holes of the paper exit section.

  • Page 11: Clearing Paper Jams

    When a paper jam occurs, remove the paper jammed in each section according to the following procedures. 1. Pull the paper cassettes out from the printer and check if the paper in each cassette is stored correctly. If the paper is not stored correctly, remove the jammed piece of paper.
  • Page 12 (M3) in the direction of the arrow. 3. When the leading edge of jammed paper has reached into the fusing unit, remove the paper toward the inside of the printer while depressing and rotating the roller knob (M1) in the direction of the arrow.
  • Page 13 Inside the sorter and sorter interface unit (J4 or J6 error) Lock Release Lever “Removing Jammed Paper” diagram A-62032 November 1996 1. Press the lock release lever of the 20-bin sorter to open the sorter. 2. Open the transport guide plates (upper and lower) of the sorter to check if the paper is jammed inside the option.
  • Page 14 3. Open the upper cover of the sorter interface unit and check to be sure there is no jammed paper. If there is paper, remove it and close the upper cover again. 4. Close the 20-bin sorter. November 1996 A-62032...
  • Page 15 1. Open the front cover. 2. Pull the toner bottle holder lever to swing the toner bottle out of the printer (1). Remove the toner bottle from the toner holder (2). 3. Turning the toner seal right side up, insert the new toner bottle into the holder so that the protrusions of the bottle fit in the cutouts of the holder.
  • Page 16 2-10 4. Check that the triangle marks on the toner bottle and the toner bottle holder face each other as in the illustration. Holding the toner bottle with your left hand, gently pull the toner seal out of the toner bottle. 5.
  • Page 17 12%. When this indicator appears, follow the steps below to replace the toner collection bottle. 1. Take out the toner collection bottle and cover the mouth with the cap attached on the bottle. 2. Insert the new toner collection bottle into the printer. 2-11...

  • Page 18: Appendix A Specifications

    Appendix A Specifications General specifications A-62032 November 1996 Type ... Console-type dry electrophotographic printer Resolution ... 400 DPI Print method ... Laser diode, polygon mirror system Laser ... Maximum power: 1.1 x 10 Wavelength: 785 +10, -15 nm Dimensions ... Width : 36" (860 mm) x depth : 27" (684 mm) x height : 40"...
  • Page 19 * These papers can be fed in either direction (i.e., dimensions are interchangeable for these sizes). † Feeds from upper 3 cassettes only. NOTE: Dimension A cannot be greater than 11.7 in. (297 mm). Dimension B must be 8.25 in. (209.6 mm) or Feed Direction greater.

  • Page 20: Appendix B Installation Considerations

    Appendix B Installation considerations Space requirements A-62032 November 1996 The figures and illustrations below show the minimum space required for the installation of your printer. — Installed without sorter option 100 (4) 860 (34) Unit: mm (inch) 100 (4)
  • Page 21 Installed with sorter option Unit: mm (inch) 100 (4) 1093 (43) 100 (4) 540 (21 1/4) 553 (21 3/4) November 1996 A-62032...

  • Page 22: Installation Environment

    — Only connect to a dedicated electrical socket-outlet. — Use the printer in a place which is near an electrical outlet and where there is little voltage fluctuation. (The power supply voltage should be specified voltage 10% for imaging and +10% or -15% for feeding.

  • Page 23: Handling Of Consumables

    Kodak Imagelink Printer 7 / 220-240 V, 50 Hz Kodak Imagelink Printer 7 Paper Supply / 100 V, 50/60 Hz Kodak Imagelink Printer 7 Paper Supply / 120 V, 60 Hz Kodak Imagelink Printer 7 Paper Supply / 220-240 V, 50 Hz...

  • Page 24: Appendix C Printer 7 Error, Maintenance, And Caution Codes

    The drum-charge erase lamp has malfunctioned. * These maintenance procedures are to be performed by Kodak authorized and fully trained persons only. These errors (for the EP unit and fuser unit) normally appear every 150,000 prints. At this time, an Image Quality Kit needs to be installed.
  • Page 25 The main drive motor has malfunctioned. The transfer corona or separator has malfunctioned. The polygon drive motor has malfunctioned. Turn the printer off and then on again. If the The S-SCAN-out has malfunctioned. Command overflow. There is an error in the external communications system.
  • Page 26 * These maintenance procedures are to be performed by Kodak authorized and fully trained persons only. These errors (for the EP unit and fuser unit) normally appear every 150,000 prints. At this time, an Image Quality Kit needs to be installed.

  • Page 27: Appendix D Maintenance

    Before conducting any maintenance procedures, follow these precautions: — Before beginning the maintenance procedures, be sure to turn OFF the power ON/OFF switch and unplug the printer’s power cord. — Do not put any equipment that produces a magnetic field near the printer.
  • Page 28 2. Remove the (4) paper guides by lifting them straight up. Clean the outside of housing with a soft cloth. 3. Carefully clean the wires using the cleaning pen contained in the accessories for the machine as in the illustration. 4.

  • Page 29: Cleaning The Printer

    ON/OFF switch and unplug the power cord from the outlet. 1. Wipe the cover and external parts of the printer with a dry, soft cloth. If the cover is extremely dirty, use a cloth that has been dampened slightly in a neutral cleaning solution.
  • Page 30 5:00 p.m.), excluding holidays celebrated locally. Any on-site service performed after normal working hours will be billed at prevailing overtime rates. In the U.S. call (800) 356-3253; or call your local Kodak Service Office. Standard warranty service is limited to the contiguous United States, Hawaii, and certain areas of Alaska.
  • Page 31 This limitation of liability will not apply to claims for injury to persons or damage to property caused by the sole negligence or fault of Kodak or by persons under its direction or control. The Kodak Imagelink Printer 7 has a rated machine life of 4.8 million print actuations or 5 years, whichever...
  • Page 32 1-2 Machine life, A-1, Warranty Maintenance, D-1–D-3 Mechanical print counter, 1-3, “Metric” paper position switch, Ordering information accessories, B-4 consumables, B-4 Printer 7, B-4 Operation panel, 1-1, 2-1 Overview, 1-1–1-3 Paper, clearing jams, 2-5–2-8 feeding, A-2 loading, 2-2 sizes, A-2 types, A-2 Paper cassette 1-1, 2-2–2-4...
  • Page 33 Printer right cover, 1-2 Printer top cover, 1-1 Release lever (M2), 1-3 Safety information, ii Separator roller, 1-3 Sorter, 2-7, A-2, B-2 Sorter interface unit, 2-7, B-2 Space requirements, B-1, B-2 Specifications, A-1 Synchronizing roller knob (M3), 1-3 Test control, 2-1...
  • Page 34 Business Imaging Systems EASTMAN KODAK COMPANY Rochester, New York 14650 Kodak and Imagelink are trademarks of Eastman Kodak Company. Printed on recycled paper. A-62032 Part No. 3C4923 11/96 © Eastman Kodak Company, 1996 Printed in U.S.A.
