- Page 1 35-PC. ROTARY TOOL KIT OWNER’S MANUAL WARNING: Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Item# 21402...
-
Page 2: General Safety Rules
Thank you very much for choosing a Wel-Bilt™ product! For future reference, please complete the owner’s record below: Model: _______________ Purchase Date: _______________ Save the receipt, warranty and these instructions. It is important that you read the entire manual to become familiar with this product before you begin using it. - Page 3 IMPORTANT SAFETY CONSIDERATIONS • Stay alert, watch what you are doing and use common sense when operating the Rotary Tool. Do not use the Rotary Tool while you are tired or under the influence of drugs, alcohol or medication. A moment of inattention while operating the Rotary Tool may result in serious personal injury.
- Page 4 OPERATION: Spring chuck Securing ring Spindle lock Carbon brush cap Speed dial On/Off switch Manual stand OPERATING INSTRUCTIONS Fitting the accessories to the tool (Fig. 1) 1. Switch off the tool and disconnect from the main power supply before fitting accessories. 2.
- Page 5 Assembling abrasive discs & grinding stones to accessory shaft 1 (Fig. 2) 1. Mount the selected disc onto the accessory shaft 1 as illustrated. Ensure the two washers are correctly placed. 2. Do not over-tighten the screw. Assembling abrasive bands to accessory shaft 2 (Fig. 3) 1.
- Page 6 MAINTENANCE • Maintain your Rotary Tool. It is recommended that the general condition of any Rotary Tool be examined before it is used. Keep your Rotary Tool in good repair by adopting a program of conscientious repair and maintenance. Have necessary repairs made by qualified service personnel.
- Page 7 Part list Part# Description Part# Description Collet nut Speed control switch Collet Screw Base Screw Bearing Right body Rotor Spindle lock button Stator Spring piece Carbon brush Left body Cap body Switch Cord sleeve Trimming circuit board Cord Lock board Plug For replacement parts and technical questions, please call 1-800-222-5381.
- Page 8 WARNING Some dust created by power sanding, sawing, grinding, drilling, and other construction activities contains chemicals known to the State of California to cause cancer, birth defects or other reproductive harm. Some examples of these chemicals are: • lead from lead-based paints, •...
