Summary of Contents for Wel-Bilt 18649
- Page 1 131-PC. ROTARY TOOL KIT OWNER’S MANUAL WARNING: Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Item# 18649...
-
Page 2: Intended Use
Thank you very much for choosing a Wel-Bilt™ product! For future reference, please complete the owner’s record below: Model: _______________ Purchase Date: _______________ Save the receipt, warranty and these instructions. It is important that you read the entire manual to become familiar with this product before you begin using it. -
Page 3: Work Area
WORK AREA Keep work area clean, free of clutter and well lit. Cluttered and dark work areas can cause accidents. Do not use your tool where there is a risk of causing a fire or an explosion; e.g. in the presence of flammable liquids, gasses, or dust. -
Page 4: Personal Safety
6-10 18 AWG 16 AWG 14 AWG 12 AWG 10-12 16 AWG 16 AWG 14 AWG 12 AWG 12-16 14 AWG 12 AWG (NOT RECOMMENDED) If in doubt, use larger cord. Be sure to check voltage requirements of the tool to your incoming power source. Do not expose power tools to rain or wet conditions. -
Page 5: Operation
Store idle tools. When tools are not is use, store them in a dry, secure place out of the reach of children. Inspect tools for good working condition prior to storage and before re-use. Use only accessories that are recommended by the manufacturer for your model. Accessories that may be suitable for one tool may create a risk of injury when used on another tool. -
Page 6: On/Off Switch
On/off switch Locking chuck (flexible shaft) 10. Spindle lock (flexible shaft) 11. Handle (flexible shaft) 12. Fitting collar (flexible shaft) ON / OFF SWITCH WARNING! Before connecting a tool to a power supply be sure that the voltage supply is the same as that specified on the nameplate of the tool. - Page 7 before commencing any work with your tool). LOCATING A CUTTING/SANDING DISC 1. Locate the disc holder in the collet nut (2). 2. Remove the screw from the end of the disc holder with the 2-in-1 wrench provided, and insert the screw through the cutting disc. 3.
-
Page 8: Maintenance
It is recommended that you never bend the flexible shaft any smaller than 5 in. in diameter. (Fig.2) Bending the flexible shaft any tighter than 5 in. will cause the inner shaft to bind, causing additional load on your tool. Additional load could cause the tool to overheat and the motor to fail or burn out. Motor burnout caused by this action will not be covered under warranty. - Page 9 CAUTION: Do not use cleaning agents to clean the plastic parts of the tool. A mild detergent on a damp cloth is recommended. Water must never come into contact with the tool. • Repairs 1. Only an authorized Electrician or service technician should replace the cord set or make other repairs.
- Page 10 DIAGRAM AND PARTS LIST Part list Part# Description Qty. Part# Description Qty. Collet nut Screw Collet Speed control knob Nose cap Stator Spindle lock button Speed control board Switch Ø8 base (cu) Bearing Hanger Cord sleeve Rotor Plug Right housing Cord Brush Left housing...
- Page 11 WARNING Some dust created by power sanding, sawing, grinding, drilling, and other construction activities contains chemicals known to the State of California to cause cancer, birth defects or other reproductive harm. Some examples of these chemicals are: • lead from lead-based paints, •...
