CB Radio AE 6490
USER'S GUIDE
English
English
21

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CB Radio AE 6490 and is the answer not in the manual?

Questions and answers

Summary of Contents for Albrecht CB Radio AE 6490

  • Page 1 CB Radio AE 6490 USER'S GUIDE English English...
  • Page 2: Table Of Contents

    Contents Safety Warnings ......................23 Controls and Connectors ..................24 Front View ......................... 24 Rear View ........................... 25 Microphone ........................25 Installation ........................25 Open the carton box and find: ..................25 Antenna Installation ......................26 12 V / 24 V DC POWER CONNECTION ................27 Mounting using DIN Sleeve ....................
  • Page 3: Safety Warnings

    Important Information Please read before installing or operating your AE 6490/AE6191 Radio This radio is an advanced technology mobile C.B transceiver. This High Tech CB radio combines the latest circuit design with microprocessor control system. Very easily and advanced user features make it the premier radio for your mobile communications.
  • Page 4: Controls And Connectors

    unless it is a type especially qualified for such use (for example, by intrinsic safe approvals). • Sparks in such areas could cause an explosion or fire resulting in injury or even death. Blasting caps areas • To avoid possible interference with blasting operations turn your radio OFF near electrical blasting caps or in a "blasting area"...
  • Page 5: Rear View

    Rear View Antenna Connection with PL 259 coaxial Connector External Speaker Socket (for 3.5 mm mono plug) DC Power supply cable for 12…24 V depending on version Microphone Push-to-talk Switch (PTT) Up key Down key ASQ on-off toggle key Installation Open the carton box and find: ●...
  • Page 6: Antenna Installation

    Antenna Installation To obtain the best performance from your CB radio is important to install a good quality antenna. • You should purchase a suitable mobile antenna designed for the 27MHz frequency band. • Connect the antenna to the rear antenna socket using a PL259 coaxial connector.
  • Page 7: 12 V / 24 V Dc Power Connection

    12 V / 24 V DC POWER CONNECTION While the standard AE 6490 version is designed for 12 V (with allowed variations between 10.8 and 15.6 V) standard car installation (with negative ground). DC cable wiring • Connect the negative (black) DC power lead to the vehicle chassis or directly to the vehicle battery negative terminal if preferred.
  • Page 8: Removing The Radio From Din Sleeve

    • The rubber ring will act as a seal against DIN Sleeve. At the left and right sides of the ring a slot space will be provided by pulling slowly the left and right side of the ring. • The slots in the fitted rubber ring will enable the proper removal of radio from the DIN sleeve.
  • Page 9: Operation

    Operation Power On/Off Turn the rotary volume switch clockwise to power on and adjust the sound level for comfortable reception. How to start the country switching (European Multi-standard support) Both versions are prepared to use the actual European Multi-standard codes. This new European standard with AM+FM 4 Watts on 40 channels “E”...
  • Page 10: Sq Control

    Operation This last key combination is used to perform a Factory Reset (to default settings) This may be a useful action in cases where the radio may perhaps react abnormal. A reset can restore the functions if the CPU seems to be blocked. SQ Control •...
  • Page 11: Fc ( Function ) Selector

    Operation FC ( Function ) Selector The squelch control knob has an important function, if you press this knob. • If you press this SQ control knob short, you can start the “second” functions which are printed in the upper part of each function control button. AM/FM switching You can select AM or FM modulation by pressing the AM/FM button.
  • Page 12: Emg Channel Selection

    EMG Channel selection The EMG (Emergency) button is for instant access to international Calling & Emergency channel 9, which is monitored by all truckers and many CB users and in some regions even by road safety organizations. If you need any help or assistance, it is a good idea to call on this channel 9.
  • Page 13: Operation For Secondary Functions

    Operation for secondary functions MENU This MENU button can control four SUB MENU functions in sequence. To start the MENU, please consider that it is a secondary function like all others which will be described in this chapter. • You must press the FUNCTION knob (squelch button FC) first. •...
  • Page 14: Mscan

    Operation for secondary functions 3) LCD backlighting color selection (green/ red) 4) LCD backlighting brightness control (dimmer → bright) MSCAN The Memory channel Scan feature allows the radio automatically scan through memorized 5 channels. • To access, press FC and MSCAN •...
  • Page 15: Msave

    MSAVE This MSAVE button is used to store any channel in the each memory buttons at M1 to M5 To store channels: • Select the desired channel with Rotary knob or UP/DOWN • Press FC + MSAVE / MEM • You can choose any memory channel number with a button from MENU (M1) to LO / CT (M5) LO / CT ≫...
  • Page 16: Technical Specifications Ae 6490

    MONO TYPE UHF TYPE (PL) ANT. CONNECTOR SO 239 (50 Ohms socket for PL 259 plugs) CONDENSOR MICROPHONE & 6 PIN Corresponds to Albrecht & GDCH 6 pin JACK standard wiring except PIN 4 ≫ TRANSMITTER OUTPUT POWER FM 4 W / AM 4WATT FREQUENCY RANGE 26.965-27.405MHz...
  • Page 17: Customer Support & Warranty Matters

    Customer Support & Warranty matters ≫ Troubleshooting Check at first the power supply and the fuse. A problem may be caused through power supply, when no light or display appears after switching on. If the unit works in a strange way, disconnect the power supply cable (or take out the fuse from the holder), while the radio remains switched on, wait some time (minimum 10 seconds), and then reconnect power cord again.
  • Page 18: Technical Enquiries And Repair Matters

    note that the acceptance of AM+FM in the different European countries has just started and may be subject to unpredictable changes. Our homepage will provide the latest information about using the radio. Technical enquiries and repair matters: e-mail: service@alan-electronics.de Service-Download www.service.alan-electronics.de Repair enquiries: Phone:...
  • Page 19: Legal Information And Conformity Declaration

    Legal Information and Conformity Declaration Albrecht Radio Passport For your AE 6490 / AE6491 following programming and use rules apply (subject to change, as of May 2014) in countries that apply the European R & TTE directive: Country 80/40 40/40 40 FM Remarks No radios with country switch allowed.
  • Page 20: Declaration Of Conformity

    Declaration of Conformity We hereby declare that our product: / Wir erklären hiermit, dass unser Produkt CB-Radio Albrecht AE 6490 satisfies all technical regulations applicable to the product within the scope of EU Council Directives, European Standards and national frequency applications:/ alle technischen Anforderungen im Geltungsbereich der EU Richtlinien, europäischer Normen und nationaler...
