SurePrint T90 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
USER
USER
USER
USER MANUAL
The contents of this document are subject to change without notice
MANUAL
MANUAL
MANUAL
T90
T90
T90
T90
THERMAL
THERMAL
THERMAL
THERMAL PRINTER
PRINTER
PRINTER
PRINTER

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T90 and is the answer not in the manual?

Questions and answers

Related Manuals for SurePrint T90

Summary of Contents for SurePrint T90

  • Page 1 USER USER MANUAL MANUAL USER USER MANUAL MANUAL THERMAL THERMAL PRINTER PRINTER THERMAL THERMAL PRINTER PRINTER The contents of this document are subject to change without notice...
  • Page 2 CAUTIONS � It’s grade A product，maybe it cause wireless jammer in the environment. In such circumstances, need the user to do related steps. � Without permission, do not change the content of this document. � No part of this document may be reproduced, transmitted in any form or by any means, without the prior written permission.

  • Page 3: Table Of Contents

    TABLE TABLE TABLE TABLE OF OF CONTENTS CONTENTS CONTENTS CONTENTS GENERAL DESCRIPTION ..................... 1 1.1 Basic Specifications ......................1 1.2 Character Specifications ....................... 1 1.3 Autocutter ..........................1 1.4 Paper Specifications ......................1 1.5 Printable Area ........................1 1.6 Internal Buffer ........................2 1.7 Printing Position and Tear off Position .................
  • Page 4 3．8HexDump .......................... 19 3．9 Error Processing ....................... 20 3．9．1 Error Type ......................20 3．9．2 Printer Operation When an Error Occurs ..........20 3．9．3 Date Receive Error ..................21 3．10 Status Conditions ......................21 3.11 Buffer-Full Printing ......................21 3.12 Page Mode ......................... 21 3.12.1 Description ......................
  • Page 5 ESC L ..........................44 ESC m ..........................45 ESC M n ........................... 45 ESC R n ........................... 45 ESC S ..........................46 ESC T n ..........................46 ESC V n ..........................47 ESC W xL xH yL yH dxL dxH dyL dyH ............... 47 ESC \ nL nH ........................
  • Page 6 GS v 0 m xL xH yL yH d1 ... dk ..................77 GS w n ..........................78 5.5 Chinese Character Control Command ................78 FS ! n ..........................78 FS & ..........................79 FS – n ..........................80 FS ............................. 80 FS 2 [c11 c12 d1...d1k]1 …...

  • Page 7: General Description

    T90 User Manual 1 1 1 1 GENERAL GENERAL DESCRIPTION DESCRIPTION GENERAL GENERAL DESCRIPTION DESCRIPTION 1.1 B B B B asic asic asic asic Specifications Specifications Specifications Specifications Printing Method： Line Thermal Printer Printing Density： 8dot/mm Printing Directions：Feed Paper Directions Printing Speed：...

  • Page 8: Internal Buffer

    T90 User Manual Internal Internal Buffer Buffer 1.6 Internal Internal Buffer Buffer 1、Receive Date Buffer Memory: 4 KB 2、User-defined Buffer Memory： 12KB 3、Macro Defined Buffer Memory：2K 4、NV Bit Image BufferMemory： 256K 5、User-defined Commands Buffer Memory：1K Printing Printing Position Position Tear...

  • Page 9: Environmental Specifications

    T90 User Manual Autocutter：1000000 times 1.10 1.10 Environmental Environmental Specifications Specifications 1.10 1.10 Environmental Environmental Specifications Specifications 1、Temperature：During Operation：5 ～55°C During Storage：-10 ～ 50°C（excludes paper） 2、Humidity：During Operation：10～90％RH During Storage：10～90％RH（excludes paper） Figure Figure Figure Figure 1.8 1.8 Operating Operating Operating Operating Temperature...

  • Page 10: Interface Specifications

    T90 User Manual 2 2 2 2 CONFIGURATION CONFIGURATION INSTALLATION INSTALLATION CONFIGURATION CONFIGURATION AND AND INSTALLATION INSTALLATION 2.1 Interface Interface Interface Interface Specifications Specifications Specifications Specifications 2.1.1 RS232 Serial Interface 2.1.1 2.1.1 2.1.1 RS232 RS232 RS232 Serial Serial Serial Interface...
  • Page 11 T90 User Manual When DTR/DSR control is selected，The signal indicates whether the printer is busy. SPACE indicates that the printer get ready to receive data，but MARK indicates that the printer is busy. Changing the Memory Switch setting to be used as a signal for printer busy.

  • Page 12: Specifications

    T90 User Manual Changing the DIP switch setting enables this signal to be used as a reset signal for the printer. Outpu Same as RTS signal This signal indicates whether the host computer can receive data. SPACE indicates that the host computer can receive data, and MARK indicats the host computer can’t receive the data.
  • Page 13 T90 User Manual detected by either the paper roll end detector or the paper roll near-end detector with a printing halt due to paper shortage enabled by ESC c 4). 6) During macro executing standby status. 7) When an error has occurred.
  • Page 14 T90 User Manual Host nInit nInit Printer nFault nDataAvail/Data0, 4 Printer DK_STATUS Printer Host nSelectIn 1284-Active *NC: Not Connected ND: Not Defined NOTES： 1. A prefix “n” to signal names refer to low level active signals. 2. To the host provided with none of the signal lines listed above, both-way communication fails.
  • Page 15 T90 User Manual +5 V Signal Sender Characteristics Specifications Characteristics Symbol Conditions Output High Voltage =0.32 mA Output Low Voltage *2.4 V 5.5 V While the power is Output High Current Output Low Current 0.32 mA =2.4 V While the power is...

  • Page 16: Ethernet Interface

    T90 User Manual using the both-way communication facility in the Nibble/Byte Modes in accordance with the IEEE 1284. In this case, different from in the RS-232 serial interface apecifications, the real-time interruptions from the printer to the host are disabled and thus precautions must be taken to the followings:...

  • Page 17: Printer Installation

    NOTE ： To guarantee the normal operation to the printer. Please use the standard power from our company. Pin Defination： Pin NO. Signal ＋24 SHELL F．G Drawer Drawer Connector Connector 2.3 Drawer Drawer Connector Connector T90 used RJ-11 6 connector，as follows...
  • Page 18 T90 User Manual Pin Definition as the following table Pin NO. Signal Ground Direction Frame GND Drawer kick-out drive signal 1 Output Drawer open/close signal Input +24V Drawer kick-out drive signal 1 Output Signal GND...

  • Page 19: Functions

    T90 User Manual 3 3 3 3 FUNCTIONS FUNCTIONS FUNCTIONS FUNCTIONS 3.1 List List List List of of of of Commands Commands Commands Commands Comman Command Type Standard Page Name Executive Mode Mode ¡ ¡ ¡ Horizontal tab ¡ ¡...
  • Page 20 T90 User Manual ¡ ¡ ¡ ESC \ \ \ \ Set relative print position ¡ （¡ ） ESC a a a a Select justification ▲ ESC c c c c 3 3 3 3 Select paper sensors to output ¡...

  • Page 21: Power Button

    T90 User Manual ¡ ¡ GS w Set bar code width List of Chinese characters command Command Type Comm Standard Page Name Executive Mode Mode ¡ ¡ ¡ FS ! ! ! ! Set print modes for Chinese character ¡...

  • Page 22: Dip Switch

    NOTE：ESC c 5, enable/diable the button fuction. Push button to prohibit, it isn’t valid. 3.3DIP Switch 3.3DIP 3.3DIP 3.3DIP Switch Switch Switch T90 designed two DIP Switchs and printed agreed number, each function refer to the below sections； 3.3.1 3.3.1 3.3.1 3.3.1 DIP DIP Switch Switch Switch...

  • Page 23: Led/Alarm

    T90 User Manual DIP Switch 2 Switch Switch Switch Switch Function Function Function Function Default Default Default Default Line printing 48 Line printing 42 Select print valid width characters characters Select print gray leve Deepen Lighten Select print paper width...

  • Page 24: Roll Paper Cover

    T90 User Manual another mechanism error. Off：Printer is ready to go. 5） ALARM：Buzzer Sound ：Paper out, Cover open, The temperature of print head is extremely high, Autocuttererror, Print the receipt under the back kitchen mode, another mechanism error. ：Printer is ready to go.

  • Page 25: 3．8Hexdump

    T90 User Manual Then, Turn the autocutter wheel around, do it make the autocutter reset. Autocutter wheel 3 3 3 3 ．7 7 7 7 Self-test Self-test Self-test Self-test Self-test that checks whether the printer is stable or not. If the self-test is correct, indicates that the printer is stable except the interface what connect the host.

  • Page 26: 3．9 Error Processing

    T90 User Manual example: push the feed paper button down). 3）Ending hexadecimal dumping Hexadecimal printing ends by setting SW-5 is “OFF” in DIP-SW2 function, resetting the printer, push down button three times (but returning to hexadecimal at once). < Printing example >...

  • Page 27: 3．10 Status Conditions

    T90 User Manual · Goes BUSY. · Blinks the ERROR LED. 3 3 3 3 ．9 9 9 9 ．3 3 3 3 Date Date Receive Error Date Date Receive Receive Receive Error Error Error If one of the following errors during serial interface communication, the printer prints“？”or ignores the data.

  • Page 28: Page Mode

    T90 User Manual page mode. Print all received data by ESC FF command， but execute FF command, after printing all data, the printer return to the standard mode. Execute ESC S command, the printer return to the standard mode directly, but do not print the received data which received under the page mode, these data will be delected from memory.
  • Page 29 T90 User Manual 4、 Under default circumstances, the line width spacing is 4.23mm （1/6 inch），the width is 30 dots. If the date in the next line printing date is higher than the height of double printing, then the dot image will be had two lines or more, bar code is higher than the stable characters, the total lines of feed paper is not enough, leed to overlapping printing.
  • Page 30 T90 User Manual Figure Figure 3.11.2 3.11.2 Character Character Data Data Initial Initial Position Position Figure Figure 3.11.2 3.11.2 Character Character Data Data Initial Initial Position Position...
  • Page 31 T90 User Manual Figure 3.11.3 Printing Data Initial Position Figure Figure Figure 3.11.3 3.11.3 3.11.3 Printing Printing Printing Data Data Data Initial Initial Initial Position Position Position Figure Figure 3.11.4 3.11.4 Download Download Image Image Initial Initial Position Position Figure Figure 3.11.4...

  • Page 32: Color

    Appearance Foot Dataline Cash Power Paper Keyboar Paper Oil-proof Interface Interface Interface Cover Switch Figure 1 1 1 1 ：T90 Figure 2 2 2 2 ：T90 Figure Figure Figure T90 Back Back Back Back Figure Figure Figure T90 Plan Plan...

  • Page 33: Commands

    T90 User Manual 5 5 5 5 COMMANDS COMMANDS COMMANDS COMMANDS 5.1 Command Notation [Name] The name of the command [Format] The code sequence [ ] k indicates the contents in brackets [ ] should be repeated k time. [Range]...

  • Page 34: List Of Commands

    T90 User Manual (9) MSB Most Significant Bit (10) LSB Least Significant Bit (11)Baseline The standard position of the characters data which be stroed in the print buffer area.The following indicates the general characters position under the standard mode and page mode:...
  • Page 35 T90 User Manual ¡ ¡ ¡ ESC D D D D Set horizontal tab positions ¡ ¡ ¡ ESC E E E E Turn emphasized mode on/off ¡ ¡ ¡ ESC G G G G Turn double-strike mode on/off ¡...
  • Page 36 T90 User Manual GS T T T T Set print position as printing origin Ignore ¡ ¡ ¡ （¡ ） ¡ GS V V V V Selct out mode and cut paper ¡ （¡ ） GS W W W W Set print area width ▲...

  • Page 37: Detailed Explanation Of Commands

    T90 User Manual 5.4 Detailed Explanation of Commands [Name] Horizontal tab [Format] ASCII Decimal [Description] Moves the print position to the next horizontal tab position. [Paticularize] • If didn’t set the next horizontal tab position, then this command will be ignored.

  • Page 38: Can

    T90 User Manual [Paticularize] · For serial interface mode, the feed paper fuction of this command could be ignored. ·• This command set the print position to the starting of the line. [Reference] [Name] Cancel print data in page mode...
  • Page 39 T90 User Manual EOT 3 3 3 3 . DSR)will be changed to MARK， so before receiving the n, interrupt DLE DLE EOT The code of DLE DLE EOT EOT 3 3 3 3 <10>H will be dealed with as the code of ESC ESC 3 3 3 3 <10>H.
  • Page 40 T90 User Manual No automatically recoverable error. Automatically recoverable error occurred. Not used. Select off. Bit 2：While the cover is opening, the printer showed it as the mechanical error. Bit 6：If the temperature of print head is extremely high, bit 6 will be turn on, until temperature of the print head effectively comes down or open the cover during printing.
  • Page 41 T90 User Manual This command only effects for the error which can be recovered, except for print head temperature error. ≤ ≤ · Whenever receive <10>H<05>H<n> (1 [Notes] 2) data sequence，will send status. For example: ESC * m nL nH dk, d1 = <10>H, d2 = <05>H, d3 = <01>H ·...

  • Page 42: Esc % N

    T90 User Manual [Description] Select print modes by the data of appointing parameter n.The definition of n as follows: Off/On Decimal Function × Character type A (12 24)。 × Character type B (9 17)。 Undefined Undefined Emphasized mode is turned off.
  • Page 43 T90 User Manual [Particularize] ·The set which be appointed as the print area will be ignored. · In stable mode, use the horizontal motor unit (x). · In page mode, horizontal or vertical motor unit wihich will be different as the original of printable area, as follows: ①When ESC...
  • Page 44 T90 User Manual · Set the relevant of printing dot is 1 or 0 which is the relevant of do not printing the dots. · Define the different user-defined character mode for each character type by this ESC ! ! ! ! or ESC ESC M M M M .
  • Page 45 T90 User Manual × · When set the character type B (9 17).

  • Page 46: Esc * M Nl Nh D1

    T90 User Manual ESC * * * * m m m m nL nL nH nH d1... d1... d1... d1... dk [Name] Select bit-image mode [Format] ASCII m nL nH d1...dk m nL nH d1...dk Decimal m nL nH d1...dk...
  • Page 47 T90 User Manual • 24-dot bit-image is selected: ESC – – – – n n n n [Name] Turn underline mode on/off [Format] ASCII Decimal ≤ ≤ ≤ ≤ [Range] 2, 48 [Description] Turns underline mode on/off: Function 0, 48 Turns off underline mode.
  • Page 48 T90 User Manual · The printer can print all character with underline (include the right spacing of [Notes] character), except for blank which set by HT. · The printer can not print underline of the character of clockwise 90 and reverse character.
  • Page 49 T90 User Manual ≤ ≤ [Range] [Description] Cancel user-defined characters. · This command stops the type which defined for character code, character code set [Notes] by n . After canceling the user-defiend character, prints with inner character relative mode. · Select character type by ESC !, this command delects the type which defined the pointed code.
  • Page 50 T90 User Manual ·For stable and page mode, character width will be memoried. Default position is 8 character spacing (raw 9，17，25 ...) of type A (12 ´ 24). [Default] [Reference] ESC E E E E n n n n [Name]...
  • Page 51 T90 User Manual ESC J J J J n n n n [Name] Print and feed paper [Format] ASCII Decimal ≤ ≤ [Range] × [Description] Prints and outputs the data in print buffer area, and feed paper [n 0.125 mm ].
  • Page 52 T90 User Manual [Format] ASCII Decimal [Description] The printer received this command, then executing partial cut at present position. [Note] As the printer do not feed paper when executing this command, so before executing this command in the next time, assure that feed paper at least 5mm or more, prevent cutter broken.
  • Page 53 T90 User Manual Latin America Korea [Default] n = 0 [Reference] International character set ESC S S S S [Name] Select standard mode [Format] ASCII Decimal [Description] Switch from page mode to standard mode. · This command only effects in page mode.
  • Page 54 T90 User Manual ESC $ $ $ $ , ESC ESC L L L L , ESC ESC W W W W , ESC ESC \ \ \ \ , GS GS $ $ $ $ , GS GS \ \ \ \...
  • Page 55 T90 User Manual · Set horizontal starting position and print area width by using 0.125mm spacing, and set vertical starting position and print area height. · x0, y0, dx and dy specify horizontal starting horizontal starting position, vertical starting position, print area width, print area height separately, print area set as...
  • Page 56 T90 User Manual ESC a a a a n n n n [Name] Select justification [Format] ASCII Decimal ≤ ≤ ≤ ≤ [Range] 2, 48 [Description] Justify a line data according to the point position Select justification by n as follows:...
  • Page 57 T90 User Manual Roll paer end sensor enable. Undefind. · Select several sensors and input signal. In this case, if any one of sensors detect [Notes] paper out, it will output paper out signal. ·This command only effects to parallel interface, in serial interface mode, this command will be ignored.
  • Page 58 T90 User Manual feed paper button are enable. But can not feed paper. [Default] n = 0 ESC d d d d n n n n [Name] Print and feed n lines [Format] ASCII Decimal ≤ ≤ [Range] [Description] Prints the data in the right buffer and feeds the paper n.
  • Page 59 T90 User Manual ≤ ≤ [Range] [Description] Turn upside-down print mode on/off. ·When the LSB of n is 0, upside-down print mode is turned off. · When the LSB of n is 1, upside-down print mode is turned on. ·Effect when the LSB of n.

  • Page 60: Fs Q N [Xl Xh Yl Yh D1...Dk]1...[Xl Xh Yl Yh D1...Dk]N

    T90 User Manual ·If set the NV bit image print area width which is less than a vertical line by GS L and GS W, Executes the following operation only for problem line. In NV bit image mode, a vertical line means the dot of normal mode (m = 0, 48) and double height mode (m = 2, 50)，two dots of double width mode (m = 1, 49) and quadruple mode...
  • Page 61 T90 User Manual · NV bit image is one bit image which definds in NVM. Prints by FS p which defined by FS q. · In stable mode, This command only effecs on the original line. · In page mode, this command is invalid.
  • Page 62 T90 User Manual GS ! ! ! ! n n n n [Name] Select character size [Format] ASCII Decimal ≤ ≤ [Range] ≤ ≤ ≤ ≤ vertical 8, 1 horizontal [Description] Set character height by 0-2, character width by 4-6. As follows:...
  • Page 63 T90 User Manual Decimal Width Decimal Width 1(Standard) 1(Standard) 2(Double 2(Double width) height) Table 1 Table 2 Set character width Set character height [Notes] .This command affects to all characters (English characters and Chinese) except for HRI character. .If n is out of the definition scale, this command will be ignored.
  • Page 64 T90 User Manual ① When the starting position sets at the up-left or down-right，this command sets the absolute position in the vertical direction. ② When the starting position sets at the up-right or down-left, this command sets the absolute position in the parallel direction.
  • Page 65 T90 User Manual d1...d( x ´ y ´ 8 ) d1...d( x ´ y ´ 8 ) Decimal ≤ ≤ [Range] ≤ ≤ × × 48 (x 1536) ≤ ≤ [Description] Specifies dot by x and y, and defines the down-load bit image.
  • Page 66 T90 User Manual m set mode from following table： Vertical dot Mode Horizontal dot density density 0, 48 Stable 203.2 dpi 203.2 dpi Double 1, 49 203.2 dpi 101.6 dpi width Double 2, 50 101.6 dpi 203.2 dpi height 3, 51 Quadruple 101.6 dpi...
  • Page 67 T90 User Manual .The content of macro definition reaches to 2048 bytes. If the content of macro definition overs 2048 bytes, so it can not store the over part of data. [Reference] GS ^ ^ ^ ^ GS B B B B n n n n...
  • Page 68 T90 User Manual 2, 50 Left Add blank to right · If n or m overs defined range, the original print mode is the same as before. [Notes] · If n = 0， m has not any meaning. [Default] n = 0, m = 0...
  • Page 69 T90 User Manual GS C C C C 2 2 2 2 nL nL nH [Name] Set attribute value [Format] ASCII Decimal ≤ ≤ [Range] ≤ ≤ [Description] Set serial attribute data. × · nL and nH define the attribute value as [nL + nH 256].
  • Page 70 [Range] 3, 49 [Description] Transmit printer ID. · n indicates the type of printer ID. Printer ID type 1, 49 Printer type ID Model: T90, Hex: 21H 2, 50 Type ID Below table 3, 51 Firmware version ID [Type ID]...
  • Page 71 T90 User Manual Not support double byte character code. Support double byte character type. Uninstall auto cutter. Install auto cutter. Undefined. Not used. Not used. Undefined. Undefined. Not used. [Particularize] .In serial interface mode, controls by selecting DTR/DSR, be sure that the host have ready to receive data(DSR signal is SPACE), The printer only transmits one byte.
  • Page 72 T90 User Manual · In stable mode, this command is valid only at the line origin position. [Notes] · Input this command in page mode, the printer only executes the inner sign operation. · In page mode, this command can not affect the print.

  • Page 73: Printable Area

    T90 User Manual [The particularize for ②] When n≠0, the printer feeds paper to (cut paper position+[n×0.125㎜{0.0049 inch}] and cut paper. GS W W W W nL nL nH [Name] Set pirnt area width [Format] ASCII Decimal ≤ ≤ [Range] ≤...
  • Page 74 T90 User Manual [Default] Horizont Mode type Default al dot (82.5 mm paper width type ) 640 dot nL = 128, nH = 2 (79.5 mm paper width type ) 576 dot nL = 64, nH = 2 (60 mm paper width type )
  • Page 75 T90 User Manual When the LSB of m is 0: Macro continues to execute r times at the specified time spacing. When the LSB of m is 1: After the waiting time which specifies by t, PAPER OUT LED will be flashed, and the printer be waited, FEED button will be pushed.
  • Page 76 T90 User Manual .Because the data processed in the receiving buffer area and executed later, so there are one period of lag time between date receiving and condition transmission. .When uses DLE EOT or GS r, have to distinguish the transmission status and ASB status, according to appendix C, the process of transmission status in read.
  • Page 77 T90 User Manual Roll paper near-end sensor: roll paper near end. Roll paper end sensor: with roll paper. 2, 3 Roll paper end sensor: no roll paper. Off is fixed. 5, 6 Undefined. Off is fixed. The fourth byte (roll paper sensor information)
  • Page 78 T90 User Manual printing buffer area, prints the attribute value in the printing buffer area. . Set attribute count print mode by GS C 0. . Set attribute count print mode by GS C 1 or GS C. . At the increase attribute mode, If the attribute value which set by this command overs the attribute operation range which set by GS C 1 or GS C, then the attribute value have to change to the min value.
  • Page 79 T90 User Manual Decimal d1 ... dn ≤ ≤ ① 0 [Range] 6 (k and d decided by the used bar code system ) ≤ ≤ ② 65 73 (n and d decided by the used bar code system) [Description] Select bar code system and print bar code.
  • Page 80 T90 User Manual ·The number of ITF bar code data must be even. When inputting the odd number, the printer ignores the last receiving data. [Note②] · n specifies bar code data bytes, and the printer processes n byte data as bar code data from the next character.
  • Page 81 T90 User Manual ■B ■R ■C ■S ■D ■T ■E ■U ■F ■V ■G ■W ■H ■X ■I ■Y ■J ■Z ■K ■A ■L ■B ■M ■C ■N ■D ■O ■E ■T [For example] Print GS k 72 7 67 111 100 101 13 57 51 When using CODE128 (m = 73) ：...
  • Page 82 T90 User Manual .If the head of bar code data is not the code font selected characters, the printer stops processing the command, and deals with the continued data as the normal data. .If“{” and continued character group are not meet to any special characters, the printer stops processing the command, and deals with the continued data as the normal data.
  • Page 83 T90 User Manual （0C） （12） Roll paper end sensor: end. Off is fixed. 5，6 Undefined. Off is fixed. Bit 2 and 3: When the roll paper end sensor detects no paper, the printer turns to offline, and don’t execute this command. So, bit 2 and 3 can not transmit no paper status.
  • Page 84 T90 User Manual be printed as 0. × [For example] When xL+xH 256=64 GS w n [Name] Set bar code width [Format] ASCII Decimal ≤ ≤ [Range] [Description] Set bar code horizontal size. n set bar code width as follows:...
  • Page 85 T90 User Manual Undefined Undefined Disable double width mode Enable double width mode Disable double height mode Disable double height mode Undefined Undefined Undefined Disable underline mode Enable underline mode [Particularize] . Set both double width mode and double height mode (contain right side and left side character spacing), will print four times character size.
  • Page 86 T90 User Manual Decimal ≤ ≤ ≤ ≤ [Range] 2, 48 [Description] For receipt and allonge, turn underline mode on/off for Chinese characters as follows: Function 0, 48 Turn underline mode off for Chinese characters 1, 49 Turn underline mode on for Chinese characters(1 dot width)
  • Page 87 T90 User Manual .After transmitting FS [c11 c12 d1...d1k]1...[cn1 cn2 d1...dnk]n, finishes definition by transmitting NUL finally. ·After sending FS 2 [c11 c12 d1...d1k]1 … [cn1 cn2 d1...dnk]n ，at last send NUL to finish the definition. .Repeat [note] to define the character frequently, It may break FLASH MEMORY, so suggests that it is less than ten times every day.
  • Page 88 T90 User Manual Decimal [Range] n = 0、1、2、48、49、50 [Description] User defined zone Code bit range AAA1 ～ AFFE 0，48 User zone 1 F8A1 ～ FEFE 1，49 User zone 2 A140 ～ A7A0 2，50 User zone 3 Notes： 1、Change user zone , will clear all old characters.
  • Page 89 T90 User Manual [Description] Turn quadruple-size mode on/off for Chinese characters. · When the LSB is 0, turn quadruple-size mode off for Chinese characters. ·When the LSB is 1, turn quadruple-size mode on for Chinese character. [Particularize] .Only LSB of n is effective.
  • Page 90 T90 User Manual · Over high voltage or low voltage occurred, turn the power off as soon as possible. A.3 Another Another Another Another Notes Notes Notes Notes � The printer operation � When roll paper cover is closed, do not pull the roll paper.
  • Page 91 T90 User Manual ３．Clean cotton with a little alcohol, paint to surface dirt slightly, do not use sandpaper, blade or force materials to clean print head slice! Or, the thermal print head slice will be damaged, and can not be recovered.
  • Page 92 T90 User Manual ② Specify print area by ESC W. ③ Specify print direction by ESC T. ④ Transmit print data. ⑤ Put data together by FF. ⑥ The printer automatically returns to standard mode after printing For example 1：BASIC program example(if #1 file opened，can be transmitted data totheprinter) 100 PRINT #1,CHR$(&H1B);"L";...
  • Page 93 T90 User Manual 140 PRINT #1,"Page mode lesson 2 CAN command" 150 PRINT #1,CHR$(&HA); 160 PRINT #1,"ABCDEFGHIJKLMNOPQRST1234567890" 170 PRINT #1,CHR$(&HC); The process as follows： Firstly，transmit ESC L to turn to page mode（100 lines）. Then sending n1 to n8 by ESC W according to the specified print area.
  • Page 94 T90 User Manual APPENDIX APPENDIX CODE128 CODE128 CODE CODE APPENDIX APPENDIX G: G: CODE128 CODE128 BAR BAR CODE CODE G.1 CODE128 CODE128 CODE128 CODE128 bar bar code code code code description description description description In CODE128 bar code system, use one bar code character set, indicate 128 unit ASCII charactersand 2 bit data.
  • Page 95 T90 User Manual > CODEC 7B,43 123,67 " & Printable Printable Printable Printable character character character character in in in in code code code code set set B B B B Transmit Data Transmit Data Transmit Data Character Character Character...
  • Page 96 T90 User Manual < > Printable Printable Printable Printable character character character character in in in in code code code code set set C C C C Transmit Data Transmit Data Transmit Data Character Character Character Decima Decimal Decimal FNC1...
  • Page 97 T90 User Manual...
