Pride Mobility GOPHER Owner's Manual page 14

■ How to re-position the seat
The seat can be slide backward and forward for a comfortable driving position. To slide the
seat, pull the lever at the front the seat and reposition as required.
■ Tiller Adjustment
The tiller can be adjusted in to many different positions to suit each driver.
1. Loosen the lever to adjust the tiller to positions you want.
2. Once decide the position, tighten the lever to secure the tiller.
■ Main Circuit Breaker (Reset Button)
When the voltage in your scooter‟s batteries becomes low or the scooter is heavily strained
because of excessive loads or steep inclines ,the main circuit breaker may tip to protect the
motor and electronics from damage.
4 . O P E R AT I O N
13
Slide lever
Swivel lever
