Installation Instructions

for use by heating contractor
Vitocell-B 100
CVB Series
Enameled dual-coil, indirect-fired domestic hot water storage tank
79 and 120 USG / 300 and 450 ltr capacity
This tank version is not suitable
for steam heating applications.
VITOCELL-B 100
5285 658 v2.1 09/2008
CAUTION
THE HEAT TRANSFER
MEDIUM MUST BE WATER
OR OTHER NON-TOXIC
FLUID HAVING A TOXICITY
RATING OR CLASS OF 1,
AS LISTED IN CLINICAL
TOXICOLOGY OF
COMMERCIAL PRODUCTS,
5TH EDITION.
THE PRESSURE OF THE
HEAT TRANSFER MEDIUM
MUST BE LIMITED TO A
MAXIMUM OF 30 PSIG BY
AN APPROVED SAFETY
OR RELIEF VALVE (SEE
PAGE 2).
IMPORTANT
Read and save these instructions
for future reference.
