Belt Drive CD Player
USB Sound System
Installaton and Setup Gudie
for USB Driver on Windows PC
Thank you for purchasing a CD5.
This guide book will show you how to install and setup the CD5 USB
driver at your Windows PC to playback music files through USB
connection.
POWER
SOURCE
CD5
HEADPHONE
VOLUME
BELT DRIVE CD PLAYER CD5
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for cec CD5
Summary of Contents for cec CD5
- Page 1 Installaton and Setup Gudie for USB Driver on Windows PC Thank you for purchasing a CD5. This guide book will show you how to install and setup the CD5 USB driver at your Windows PC to playback music files through USB connection.
- Page 2 OS or Browser. USB Driver (Your PC recognizes CD5 as a regular audio device.) ▷ B RAVO-HD (is the USB driver specialized in CD5, supplied by SAVITEC, USB Audio IC manufacturer.) Necessary components to reproduce DSD files at foobar2000 ▷...
-
Page 3: Usb Driver Installation
BRAVO-HD is an exclusive USB driver that a USB Audio IC maker, SAVITEC company provides for CD5. 1. Installation for BRAVO-HD 1.1. Melt (open) the "CD5_usb_win.zip" file downloaded from CEC download site and save the melted folder at ex. desktop. 1.. Double-click and open the saved "cd5_usb_win" folder. - Page 4 CD PLAYER / USB SOUND SYSTEM CD5 1.4. BRAVO-HD install wizard will start. Click "Next" to continue. 1.5. Select an install folder and Windows user. Click "Browse" to select an installation folder other than the default folder being showed. Select "Everyone" for all Windows users to use BRAVO-HD or "Just me" only for the user that is installing the driver now.
- Page 5 CD5 USB Driver Installation and Setup 1.6. Click "Next" to start the installation. 1.7. When the installation finishes a short-cut icon "BRAVO-HD Audio CPL" will be created on desktop and the restart wizard will appear. Click "Yes(Y)" to restart the computer.
- Page 6 Sound property on WindowXP Sound property on Windows7 1.10. Starting a PC-music after selecting the USB input on CD5 you can listen to the playback music through the analog or headphones output on CD5. CD5 USB input is compatible with up to 3bit/384kHz PCM signal but the sampling frequency may be limited by the system setting or PC-Music player.
- Page 7 Installation and Setup to play DSD files Installing ASIO and DSD drivers to a freeware pc-music player foobar000 for Windows DSD64(2.8224MHz) and DSD128(5.6448MHz) files can be played through CD5. Before starting these steps install foobar000 to your Windows PC, which can be downloaded from http://www.foobar000.org/.
- Page 8 CD PLAYER / USB SOUND SYSTEM CD5 2.5. The installing component "foo_out_asio" will be listed up marked with (unknown). Click "Apply" to continue the installation. 2.6. Click "OK" to complete the installation and change. foobar000 will restart.
- Page 9 CD5 USB Driver Installation and Setup 3. Installation for foobar2000 ASIO Proxy 3.1. Double-click "ASIOProxyInstall-0.6.0.exe" in the "cd5_dsd-plugin_fbk" folder. 3.. Click "Next" on ASIO Proxy for foobar000 Setup wizard to continue.
- Page 10 CD PLAYER / USB SOUND SYSTEM CD5 3.3. Select an install folder. Click "Browse" to select a folder other than the default folder being showed. Click "Install" to start the installation. 4.2. Install will finish soon and click "Close" to complete the installation.
- Page 11 CD5 USB Driver Installation and Setup 4. Installation for foobar2000 DSD Driver 4.1. Double-click "foo_input_sacd.fbk-component" in the "cd5_dsd-plugin_fbk" folder. 4.. foobar000 Component Installer will start. Click "Yes(Y)" to continue.
- Page 12 CD PLAYER / USB SOUND SYSTEM CD5 4.3. The installing component "foo_input_sacd" will be listed up marked with (unknown). Click "Apply" to continue the installation. 2.6. Click "OK" to complete the installation and change. foobar000 will restart.
- Page 13 CD5 USB Driver Installation and Setup 5. DSD Playback Setting on foobar2000 5.1. Click "File" on foobar000 to open "Preferences". 5.. Click "Tools - SACD" on the left side tree and select "DSD" at ASIO Driver Mode. 5.3. Click "Playback - Output - ASIO" on the left side tree, and double-click "foo_dsd_asio"...
- Page 14 CD PLAYER / USB SOUND SYSTEM CD5 5.4. Dialog for foo_dsd_asio v0.6.0 setting will appear. Select "BRAVO-HD" at ASIO Driver. Select "ASIO Native", "DoP marker" or "dCS Marker" at DSD Playback Method. Note: ASIO Native is not compatible with DSD18.
- Page 15 5.5. Click "Playback - Output" at the left side tree and select "ASIO:foo_dsd_asio" at Devices. And click "OK" to finish the setup. All the installation and setup have completed. Now foobar000 is compatible with DSD64/18 and PCM up to 3bit/384kHz through CD5.
- Page 16 CD PLAYER / USB SOUND SYSTEM CD5 BRAVO-HD Control Panel 1. Start "BRAVO-HD Audio CPL" from the short- . Turning on CD5 connected via USB cable the BRAVO-HD control panel will change to show cut on desktop or programs menu. BRAVO- a current setting.
- Page 17 CD5 USB Driver Installation and Setup 3. Changing the sample rate and bits per sample on BRAVO-HD control panel the Windows system setting on "sound - digital output property" will change accordingly, and vice versa. Note: Setting 35.8kHz or 384kHz the sound from ex. an internet browser may be unstable and noisy.
- Page 18 CD PLAYER / USB SOUND SYSTEM CD5 4. PCM, bit rate, sampling frequency and buffer Ex. Playback after changing the bit rate and size of a current PCM playback via ASIO like buffer size during stop will show the new a foobar000 output setting are displayed.
- Page 19 CD5 USB Driver Installation and Setup 5. Displaying a DSD64/.8MHz playback. 6. Displaying a DSD18/5.6MHz playback. Note: When playing a DSD file set the bit rate 4 or 3. 16 bits setting can not play any DSD. Ex. Playback after changing to 3 bits and 10ms buffer during stop will show the new settings.
- Page 20 CEC Co., Ltd., Japan 1410-B...
