Summary of Contents for IQ-group E-614
- Page 1 SF-73CA180-150-D.qxd 16/05/2005 11:20 Page 1 Security Floodlight E-614 E-616 IQ Europe Limited Sandbeck Lane, Wetherby LS22 7TW. Visit us at www.iq-europe.co.uk V2 : 04/05 IQ-73CA180-150-D Installation helpline 0871 717 1100 IQ-73CA180-300-D...
- Page 2 SF-73CA180-150-D.qxd 16/05/2005 11:20 Page 2 MANUFACTURER'S EXTENDED WARRANTY In addition to your statutory rights relating to this product it is also guaranteed by IQ (Europe) Limited ("IQ") for 12 months from the date of purchase against faulty materials or workmanship which affect its designed ability to detect or switch.
-
Page 3: General Information
SF-73CA180-150-D.qxd 16/05/2005 11:20 Page 3 SECTION ONE GENERAL INFORMATION This unit utilises passive infrared technology to detect heat radiation of moving human bodies. Upon detection, the lamp will illuminate for a user-determined time period. An integral daylight sensor ensures night-only operation. This unit has a dual light level operation. During darkness the lamp will illuminate constantly at a user defined light level until it detects movement, then the unit will switch to full brightness for a user defined time on period. -
Page 4: Installation
SF-73CA180-150-D.qxd 16/05/2005 11:20 Page 4 SECTION THREE INSTALLATION After choosing a suitable location (see previous section) install the unit as follows: The unit is suitable for connection to a 240V 50Hz electricity supply. It is suggested that 3-core round flexible cable of 1mm² gauge is used. An internal switch should be installed to switch the power to the unit ON &... -
Page 5: Top View
SF-73CA180-150-D.qxd 16/05/2005 11:20 Page 5 180º TOP VIEW Time Dimmer 2.5m Adjustment Dusk SIDE VIEW Lens Mask Less sensitive Restrict long detection Restrict short detection Restrict RHS detection Restrict LHS detection More sensitive... - Page 6 SF-73CA180-150-D.qxd 16/05/2005 11:20 Page 6 wall plate fixing screw...
-
Page 7: Connection Diagram
SF-73CA180-150-D.qxd 16/05/2005 11:20 Page 7 CONNECTION Connect the cable to the terminal block on the unit as follows (see connection diagram): NEUTRAL (Blue) EARTH (Green/Yellow) LIVE (Brown) Ensure that the connections are secure. Fit the terminal block to the posts on the wall plate Re-fit the floodlight to the wall plate by locating the lugs onto into the recess on the top of the wall bracket, lift the floodlight so it fits over the wall plate (reverse diagram F) Fully tighten the fixing screw (fig E). - Page 8 SF-73CA180-150-D.qxd 16/05/2005 11:20 Page 8 Walk across the detection area approx 5 metres from the unit. As you cross a detection "zone" the lamp will illuminate. Now stand still until the lamp extinguishes (this should take approx. 5 seconds). Start moving again. As you cross each "zone" the lamp will illuminate. Repeat the above, walking at various distances and angles to the unit.
-
Page 9: Technical Specifications
If you experience problems do not immediately return the unit to store. Telephone the IQ Customer Helpline 0871 71 71 100 Weekdays 9.00am - 5.00pm support@iq-group.com www.iq-europe.co.uk Qualified Customer Support Co-ordinators will be on-line to assist in resolving your query. -
Page 10: Troubleshooting Guide
SF-73CA180-150-D.qxd 16/05/2005 11:20 Page 10 SECTION SIX TROUBLESHOOTING GUIDE SOLUTION PROBLEM The unit may be suffering from false activation. Cover the o Lamp stays ON all the time at sensor lens completely with a thick cloth. This will prevent the night. - Page 11 SF-73CA180-150-D.qxd 16/05/2005 11:20 Page 11 DID YOU KNOW... IQ products are designed and manufactured to give many years of trouble-free service. The materials used during manufacture have been selected to improve their ability to be recycled when the product is no longer functional. Please be kind to our environment and help conserve scarce resources by disposing of this product at your local waste recycling facility at the end of its life.
