- Page 1 SF-OEMCTV200-150&500-GR.qxd 16/05/2005 11:21 Page 1 Security Floodlight E-636 E-638 IQ Europe Limited Sandbeck Lane, Wetherby LS22 7TW. V1.0 - 04/05 Visit us at www.iq-europe.co.uk IQ-OEMCTV200-150-GR Installation helpline 0871 717 1100 IQ-OEMCTV200-500-GR...
- Page 2 SF-OEMCTV200-150&500-GR.qxd 16/05/2005 11:21 Page 2 MANUFACTURER'S EXTENDED WARRANTY In addition to your statutory rights relating to this product it is also guaranteed by IQ (Europe) Limited ("IQ") for 12 months from the date of purchase against faulty materials or workmanship which affect its designed ability to detect or switch.
-
Page 3: General Information
SF-OEMCTV200-150&500-GR.qxd 16/05/2005 11:21 Page 3 SECTION ONE GENERAL INFORMATION This unit utilises passive infrared technology to detect heat radiation of moving human bodies. Upon detection, the lamp will illuminate for a user-determined time period. An integral daylight sensor ensures night-only operation. PARTS INCLUDED - Luminaire / PIR Sensor unit. - Page 4 SF-OEMCTV200-150&500-GR.qxd 16/05/2005 11:21 Page 4 SECTION THREE NSTALLATION After choosing a suitable location (see previous section) install the unit as follows: The unit is suitable for connection to a 240V 50Hz electricity supply. It is suggested that 3-core round flexible cable of 1mm² gauge is used. An internal switch should be installed to switch the power to the unit ON &...
-
Page 5: Top View
SF-OEMCTV200-150&500-GR.qxd 16/05/2005 11:21 Page 5 200º Dusk Time TOP VIEW 2.5m SIDE VIEW Lens Mask Less sensitive Restrict long detection Restrict short detection Restrict RHS detection Restrict LHS detection More sensitive... - Page 6 SF-OEMCTV200-150&500-GR.qxd 16/05/2005 11:21 Page 6 wall plate fixing screw...
-
Page 7: Connection Diagram
SF-OEMCTV200-150&500-GR.qxd 16/05/2005 11:21 Page 7 CONNECTION Connect the cable to the terminal block on the unit as follows (see connection diagram): NEUTRAL (Blue) EARTH (Green/Yellow) LIVE (Brown) Ensure that the connections are secure. Fit the terminal block to the posts on the wall plate Re-fit the floodlight to the wall plate by locating the lugs onto into the recess on the top of the wall bracket, lift the floodlight so it fits over the wall plate (reverse diagram F) Fully tighten the fixing screw (fig E). -
Page 8: Operation And Testing
SF-OEMCTV200-150&500-GR.qxd 16/05/2005 11:21 Page 8 SECTION FOUR OPERATION AND TESTING WALK TESTING PROCEDURE The sensor will rotate from left to right, and tilt forward or backward. Adjust the sensor to point in the desired direction. Set the two adjustment controls on the underside of the unit (diagram C) to the following positions: TIME - Fully anti-clockwise DUSK - Fully clockwise... -
Page 9: Manual Override Mode
SF-OEMCTV200-150&500-GR.qxd 16/05/2005 11:21 Page 9 MANUAL OVERRIDE MODE At night, to switch the unit into manual override mode, turn the power off/on/off/on (twice) within 1 second,using the internal wall switch/circuit breaker. The unit should now enter manual override mode until dawn when it will reset to its normal operation. The lamp will illuminate at full power until dawn. -
Page 10: Troubleshooting Guide
If problems still exist, do not immediately return the unit to store. Telephone the IQ Customer Helpline 0871 71 71 100 Weekdays 9.00am - 5.00pm support@iq-group.com www.iq-europe.co.uk Qualified Customer Support Co-ordinators will be on-line to assist in resolving your query. - Page 11 SF-OEMCTV200-150&500-GR.qxd 16/05/2005 11:21 Page 11 DID YOU KNOW... IQ products are designed and manufactured to give many years of trouble-free service. The materials used during manufacture have been selected to improve their ability to be recycled when the product is no longer functional. Waste electrical products should not be disposed of with household waste.
