Page 1: Service Manual
Service Manual DOT MATRIX PRINTER MODEL CBM-910II Aug 20th, 2005 Issued... -
Page 2: Table Of Contents
How to remove the Operation Panel....................3 How to remove the Paper Hook......................3 Exploded View CBM-910 II........................ 4 Exploded View : CBM-910 ......................... 5 CBM-910II Parts List 1/2 ........................6 CBM-910II PartsList 2/2 ........................7 PartsPosition:CBM-910IIRF....................... 8 Parts Position : CBM-910IIPF......................9 SchematicDiagramCBM-910IIRF...................... -
Page 3: How To Remove The Upper Cover
(4) Disconnect the 2 Connectors from the Control Board. 2. How to remove the Printer Mechanism (1) Remove the Upper Cover. (2) Unfasten 4 screws M2.6 × 8 and M2 × 6 as shown below. (3) Lift the Printer Mechanism in the arrow direction. CITIZEN... -
Page 4: How To Remove The Control Board
And remove the Power Switch from the Bottom Cover. Then lift in the arrow direction Remove the shield Plate together with the Control Board. 4. How to remove the Paper Holder (1) Remove the Printer Cover. (2) Unfasten a screw as shown below. CITIZEN... -
Page 5: How To Remove The Operation Panel
(2) Release a Lock Hook as shown below and lift the Paper Hook to the upside. (3) When you set this Lock Hook, set the side of Hook to the Upper Cover, and according to the guide, inset the Lock Hook until this is locked completely. CITIZEN... -
Page 6: Exploded View Cbm-910 Ii
CBM-910IIService Manual 7. Exploded View: CBM-910II CITIZEN... -
Page 7: Exploded View : Cbm-910
CBM-910II Parts List Ref No. Parts No. Description Remarks E 62010670 Top case Standard color 80-0159 OP sheet MD910 Printer MD910 24 columns MD911 Printer MD911 40 columns E 4000-850 OP assy SW1,2 E 5102-430 SWITCH SKHHAN LED1,2 E 480-290... -
Page 8: Cbm-910Ii Parts List 1/2
CBM-910II Parts List Ref No. Q''ty Description Parts No. ‚ ‚ o Remarks 950037-00 PCB Assy 910-2 R JPN/EUR 24col JPN/EUR 24col 950038-00 PCB Assy 910-2 R USA 24col ‚ t ‚ r ‚ ` 24col 950039-00 PCB Assy 910-2 R JPN/EUR 40col...
