- Page 1 FULL HD BLACK BOX CR-200HD Vehicle HD Video Recorder Manual...
- Page 2 Before you use the product, please read this manual carefully. This manual is based on Fine Digital's CR-200HD, and there may be technical or editorial errors or omissions in the contents. The performance of the product is subject to change without notice.
-
Page 3: Table Of Contents
Contents Chapter 1 Before You Start Chapter 3 Menu 1-1. Precautions ..................6 3-1. User setup program ............... 38 1-2. Product & accessories ............10 3-2. View recorded video and pictures ........ 47 1-3. Name of each part ..............11 1-4. Installation ................... 12 1-5. - Page 5 Chapter 1 Before You Start 1-1. Precautions ............6 1-2. Product & accessories ....... 10 1-3. Name of each part ........11 1-4. Installation ..........12 1-5. Connecting power ........14 1-6. Memory card..........16 1-7. Black box memory management ... 18 1-8.
-
Page 6: Precautions
DANGER death. Fine Digital Inc. is not liable for any accidents • Failure to do so could discharge the battery or cause a fire. DANGER arising from not following the precautions. - Page 7 Do not operate the product with wet hands. DANGER may result in dangerous situations such as severe injury It may result in electric shock. or death. Fine Digital Inc. is not liable for any accidents WARNING WARNING arising from not following the precautions.
- Page 8 WARNING it won't obstruct your view. or death. DANGER CAUTION DANGER Fine Digital Inc. is not liable for any accidents arising CAUTION Failure to do so may result in an accident. CAUTION from not following the precautions. WARNING DANGER...
- Page 9 DANGER DANGER DANGER DANGER Precautions WARNING WARNING WARNING WARNING CAUTION CAUTION Do not press the Reset button with an awl or a CAUTION CAUTION Excessive tinting on the windshield may change the sharp object. DANGER DANGER balance of the video. DANGER DANGER Doing so may cause breakage and/or product failure.
-
Page 10: Product & Accessories
A Video output cable [4-pole to RCA] B Video input/output cable [compatible with other Fine Digital products (4-pole to 4-pole)] ※ The components of this product are subject to change without notice to improve its performance. If you want to order accessories other than the basic... -
Page 11: Name Of Each Part
Name of each part Camera lens Captures images and video of objects in front of the vehicle. USB port Provides power to the product when it is connected to a PC, and is used when you play recorded video or move it to a storage device. External output port Lets you view video in real-time. -
Page 12: Installation
Installation Inserting memory card and attaching black box to the mount Installation in vehicle Click! Right Double-sided Left tape Protective plastic film Contact area Open the memory card Push the mount in the Remove the protective Mount the black box on the cover and insert the direction of the arrow until plastic film from the... - Page 13 Fixing position and angle of view Power cable Insert the power cable into Plug the cigarette jack cord Connect the signal cable from Start the external input on the GPS navigation system. Look the “DC12V” jack. into the cigarette jack. the “VIDEO”...
-
Page 14: Connecting Power
Connecting power Using the cigarette jack cord Connecting the USB cable to a PC... - Page 15 Connecting power Only use the cigarette jack cord or the USB cable that came with the black box. Built-in battery specifications Battery type Li-Polymer Charging time Approx. 120 mins Cell capacity 150 mAh Purpose of use For manual recording in an accident or RTC Voltage 3.7 V Operating time...
-
Page 16: Memory Card
A data writing error may occur when you use it for a long time. Purchase a new memory card. (Please note that Fine Digital Inc. is not liable for data errors or failure to write due to writing/reading for an extended period of time.) Inserting the memory card Do not impact, bend or drop the memory card. - Page 17 Memory card Micro-SDHC card memory map: 8 GB for 4 hrs (4 GB for 2 hrs/ 16 GB for 8 hrs) Category Normal recording Image capturing Shock recording Manual recording Remarks 2 MP images, Record in 3 minute Toggle the REC button Shock recording for max.
-
Page 18: Black Box Memory Management
Black box memory management Overall memory Shock recording Recording Images Manual recording (including parking) allocation Record 10 secs before/30 secs after Manual recording for max. 3 mins Use the toggle key to stop manual recording detection of an impact Memory management in Normal recording Impact Manual recording starts... -
Page 19: Connecting To Pc
Connecting to PC Connecting the black box to a PC (USB storage device) Connecting the black box to a PC: Connect the USB cable from the black box to the PC and press the Note button for 2 seconds in accordance with the voice instructions. The mode then switches to the USB storage device mode and the You can operate the black box with USB power from the PC. -
Page 20: Firmware Upgrade
Firmware upgrade Download the firmware from the website. Remove the Micro SDHC memory card from the black box and insert it into the memory card adapter. Connect the memory card reader to the PC. [A Micro SDHC memory card adapter is provided.] When the memory card reader is connected to the PC, it runs as a removable disk. -
Page 21: Using The Product
Chapter 2 2-1. Features ............22 2-2. Basic operation........... 25 Using the product • Operation with the black box button • Basic operation information with the ● button colors • Operation with the ▼ button • Connecting power • Recording while driving •... -
Page 22: Features
Features Recording while driving/ capturing images/ Clear video quality manual recording 16:9 wide screen, full HD resolution, high quality video recording • 1920 * 1080 1080p full HD recording, 15 fps H.264 Normal recording while driving: Every 3 minutes • 1280 * 720 720p wide angle recording, 30 fps H.264 Auto event recording: 10 secs before/ 30 secs after: a 40 sec file •... - Page 23 Features Voice recording and audio output Real-time video display Vivid audio recording with a high sensitivity microphone [Mute You can view video in real-time on the VGA screen. available] [Video output cables are provided.] Clear sound effects/voice guidance with a speaker You can view video via the VGA AV-In port of the GPS navigation [You can adjust or turn off the volume] and digital media devices.
-
Page 24: Memory Management
Features Mounting structure Adjust the brightness of the video in 3 levels at night When you install the black box onto the windshield, you can adjust it up and down and rotate it 360 degrees horizontally You can adjust the brightness of the video at night in low lighting When you install the black box onto the windshield or the conditions. -
Page 25: Basic Operation
Basic operation Operation with the black box button Color Operational description and status display Yellow Booting is in progress (less than 30 seconds.) White Green The black box is recognized as a removable disk in the USB mode. - Page 26 Basic operation Operation with the black box button Color Operational description and status display Green Indicates the power is supplied by the cigarette cord (12V) or PC USB cable (5V). Yellow Indicates the black box is on battery operation mode. Indicates the status when taking a picture.
- Page 27 Basic operation Operation with the black box button Color Operational description and status display Blue Indicates normal recording. Yellow Indicates shock detection recording. Indicates manual recording (the user's urgent recording). Purple Indicates playback mode switchover/ motion detection in parking mode.
- Page 28 Basic operation Connecting power When booting is in progress When booting is complete When you switch the vehicle power to ON or start the ignition, the LEDs on the button turn on. When booting is in progress: ● button: yellow LED / ▼ button: white LED, booting time: less than 30 seconds When booting is complete: ●...
- Page 29 Basic operation Recording while driving Normal recording Shock recording Manual recording button Manual recording ▶ Normal recording “normal” ● button: green LED (flashing)/ ▼ button: blue LED (flashing). Video is recorded and stored in the folder on the memory card. Shock recording “event”...
- Page 30 Basic operation Taking a picture during normal recording Shooting button Shooting in progress When you press the ● button in Normal Recording mode, you can take a picture. The shooting alarm will sound through the speaker and ● button LED will flash red when you take a picture. The picture ▶...
- Page 31 Basic operation Recording with the built-in battery Before turning off power After turning off power Start recording Recording in progress Complete recording ▶ ▶ ▶ Starting manual recording When you turn off the ignition or remove the cigarette jack cord, the black box operates with the built-in battery power. The yellow LED then flashes for 30 seconds.
- Page 32 Basic operation Shooting with the built-in battery Booting with the built-in battery Standby Shooting button Shooting in progress Built-in battery booting button Built-in battery status ▶ ▶ ▶ If you press the ● button for 2 seconds when there is no If you press the ●...
- Page 33 Basic operation Recording when parked If you press the ▼ button for 1 second or if there is no movement of Parking mode button Into Parking mode Impact in Parking mode the vehicle for 10 minutes, the mode changes automatically to Parking mode.
- Page 34 Basic operation Motion detection Enable/Disable voice recording Parking mode button Into Parking mode Motion detection in Parking mode This function is used for enabling/disabling voice recording. When you press the ● button for 2 seconds, ▶ ▶ you can enable or disable voice recording along with voice guidance.
- Page 35 Basic operation Playing video (playing on the GPS navigation device) Descriptions of video playback screen Video playback mode access button Video playback mode accessed ▶ This function is used when you view the video footage recorded in an accident. When you press the ● button for 10 seconds in Normal Recording mode, it switches to Video Playback mode and the To start Video Playback mode when the power is connected, the black box Video latest video file is played automatically as shown above.
-
Page 36: Status Alarms
When there is insufficient space for Normal recording, the old video files are deleted, and the new video files are stored. Fine Digital Inc. is not liable for any data loss or damage to the product due to a car accident or product failure which can occur in any... - Page 37 Chapter 3 3-1. User setup program........38 Menu • PC USB connection and execution • configuration • resolution and number of frames • Acceleration sensor sensitivity / Driving mode and Parking mode • Into Parking Mode • Motion Detection in Parking Mode •...
-
Page 38: User Setup Program
User setup program (PC USB connection and execution) Connect the USB cable from the black box to the PC. If you press the ▼ button for 2 seconds after booting in accordance with the voice guidance, the connection will be completed. When you click “Open folder to view Connect the USB cable from the black If you press the ▼... - Page 39 User setup program (configuration) Name Description Information Display Displays the model name and the firmware version. Recording Mode Allows you to set a recording mode. Allows you to adjust the shock sensitivity in Driving and Shock Sensitivity Parking modes. Allows you to select “Manual” or “Auto” (auto access 10 Into Parking Mode minutes after parking).
- Page 40 User setup program (resolution and number of frames) 1280 1280 * 720 16:9 wide HD 720p 30 frame/sec 116° horizontal angle of view 1080 1920 * 1080 16:9 wide 1080p Full HD 15 frame/sec 116° horizontal angle of view 1920 1280 * 720 16:9 wide HD 30 frame/sec 68°...
- Page 41 User setup program (Acceleration sensor sensitivity / Driving mode and Parking mode) Note The acceleration sensor settings comprise two modes. Shock Sensitivity in Driving Mode is for sensitivity to impact while driving. Shock Sensitivity in Parking Mode is for sensitivity to impact when parked.
- Page 42 User setup program (Into Parking Mode) Note This mode is used for accessing Parking mode. You can select “Manual” or “Auto” to access Parking mode. If you set it to “Manual”, you need to press the ▼ button for 1 second to access Parking mode. If you set it to “Auto”, the mode will be change to Park- ing mode automatically if there is no movement of the vehicle for 10 minutes.
- Page 43 User setup program (Motion Detection in Parking Mode) Note You can set the motion detection value. The motion sensitivity is divided into 5 levels: OFF, Sensitive and Insensitive. You can set the motion sensitivity. (Set it to “Insensitive” if you wish to record only when there is a big change.)
- Page 44 User setup program (Brightness at night) Note You can set the brightness at night. The setting is divided into 3 levels: Normal, Medium and Bright. You can set the brightness. (If you set it to 'Bright”, color degradation or color noise may occur.)
- Page 45 User setup program (Audio Settings) Note The speaker volume is used for adjusting the volume of the alarms that occur during booting and recording. [5 levels: OFF,1, 2, 3 and 4] Voice recording is used for recording the surrounding sounds that occur during recording. [Use/ No]...
- Page 46 User setup program (Setting System Time and Initialize) Note The Time Setting button is used for setting the date and time displayed on video during recording. The Initialize button is used for setting the user set values back to the default values. The OK button is used for changing settings and initializing.
-
Page 47: View Recorded Video And Pictures
View video and pictures View with Micro SDHC Remove the Micro SDHC memory card from the black box and put into the micro SDHC adapter. [The Micro SDHC adapter is provided]. Use the memory card reader for the connection with a PC. When you connect micro SDHC card to a PC, it is executed as a removable disk. - Page 48 View video and pictures View with the black box Connect the black box to the PC with the USB cable. [The black box boots up with USB 5V without additional power.] If you press the ▽ button for 2 seconds after booting in accordance with the voice guidance, the black box switches to USB mode and is executed as a removable disk.
-
Page 49: Additional Information
Chapter 4 Additional Information 4-1. Specifications ..........50 4-2. Customer support ........51 • FAQ... -
Page 50: Specifications
Specifications Item Specifications Remarks Model name Fine Digital CR-200HD Color/ Dimensions/ Weight White/ 39 mm x 64 mm x 50 mm/ 88 g Deco Memory capacity Micro SDHC 4 GB/ 8 GB/ 16 GB Class 6 recommended Normal recording Supported Records video in 3 minute intervals. -
Page 51: Customer Support
Customer support - FAQ ● Check if the power is connected. [Cigarette jack cord] ● Check if the battery is charged. The black box does not turn on. ● If the product is not working at all, press the RESET button with the tip of a clip. (Resetting only blocks power, and thus does not affect the product and stored video.) ●... - Page 52 Fine Digital's black box. When you replace the Micro SDHC card, purchase an original memory external memory card. card at a shopping mall or authorized agency. [Fine Digital Inc. is not liable for any damage incurring from using a non-original memory card.]...
