Before connecting, operating or adjusting this product, please read the
instructions completely.
For USA assistance, please call: 1-800-211-PANA(7262) or, contact us via the web at:
http://www.panasonic.com/contactinfo
For Canadian assistance, please call: 1-800-561-5505 or visit us at www.panasonic.ca
PP
Operating Instructions
SD Media Storage
Model No.
VW-PT2
VQT1B03
Advertisement
Table of Contents
Related Manuals for Panasonic VW-PT2
Summary of Contents for Panasonic VW-PT2
-
Page 1: Operating Instructions
Model No. Before connecting, operating or adjusting this product, please read the instructions completely. For USA assistance, please call: 1-800-211-PANA(7262) or, contact us via the web at: http://www.panasonic.com/contactinfo For Canadian assistance, please call: 1-800-561-5505 or visit us at www.panasonic.ca VQT1B03... -
Page 2: Information For Your Safety
Dear Customer, We would like to take this opportunity to thank you for purchasing this Panasonic SD Media Storage. Please read these Operating Instructions carefully and keep them handy for future reference. ¬ Information for your safety WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR PRODUCT DAMAGE, ≥... - Page 3 Trade Name: Panasonic Model No.: VW-PT2 Responsible party: Panasonic Corporation of North America One Panasonic Way, Secaucus, NJ 07094 Support Contact: Panasonic Consumer Electronics Company 1-800-272-7262 This device complies with Part 15 of the FCC Rules. Operation is subject to the...
-
Page 4: Table Of Contents
AC adaptor This AC adaptor operates on AC between 100V and 240 V. ≥ In the U.S.A. and Canada, the AC adaptor must be connected to a 120V AC power supply only. ≥ When connecting to an AC supply outside of the U.S.A. or Canada, use a plug adaptor to suit the AC outlet configuration. - Page 5 ≥ Panasonic will in no way be liable for any You can use SD Memory Cards and SDHC damages sustained directly or indirectly Memory Cards of the following capacity on from the use or failure of this product.
-
Page 6: Features
≥ We recommend that you use a This unit is compatible with both SD Panasonic brand SD card. Memory cards and SDHC Memory ≥ A MultiMediaCard cannot be used on cards. You can only use SDHC this unit. Memory cards on devices that are ®... -
Page 7: Accessories
¬ Accessories ¬ Parts identification and handling Check the accessories before using this unit. Battery pack CGA-S303 AC adaptor VSK0681 AC cable K2CA2CA00029 USB cable K2KZ4CB00011 Carrying Case VFC4228 ≥ This unit is a precision instrument so turn off the power and put it in the carrrying case when carrying it. -
Page 8: Charging The Battery
(CGA-S303). ≥ If you use other batteries, we cannot guarantee the quality of this product. 1 Connect the AC cable to the AC ≥ Always use a genuine Panasonic AC adaptor. adaptor. 2 Connect the AC cable to the AC ≥... -
Page 9: Inserting/Removing An Sd Card
¬ Inserting/Removing an battery cover back in its original place after removing the battery. SD card ∫ About the remaining battery ≥ Before inserting/removing an SD power card, be sure to turn the power [OFF]. If the status indicator blinks at intervals of If the SD card is inserted or removed with about 1 second (blinks for about 0.5 the power turned on, this unit may... -
Page 10: Turning The Unit On/Off
≥ We recommend that you use a power is automatically turned off to save Panasonic brand SD card. the battery life. Turn off, then turn on the ≥ The SD card has a write power to resume using the unit. -
Page 11: Copying Data On An Sd Card To The Hdd
≥ If the HDD SAFETY detection switch is ≥ If copying is canceled, the file being copied will be erased. You cannot start activated while this unit is connected to a copying again until all the data has PC, the operation may remain stopped, the finished being erased. -
Page 12: Copying Data On The Hdd Or Sd Card To A Pc
¬ Copying data on the ≥ Even if the system requirements mentioned in these operating HDD or SD card to a PC instructions are fulfilled, some personal computers cannot be used. If you connect this unit to a PC using the ≥... - Page 13 Double-click the Interface USB port folder in [Local Disk] (HDD) or ≥ Use an OS standard driver for operation. [Removable disk] ≥ Even if the system requirements (SD card) containing the saved file. mentioned in these operating instructions are fulfilled, some personal Drag and drop the file onto the computers cannot be used.
-
Page 14: Cautions For Use
¬ Cautions for Use Do not use benzine, paint thinner or alcohol for cleaning the unit. ∫ About this unit ≥ Before cleaning, detach the battery or pull out the AC cable from the AC Jack. Be careful about the following as they may ≥... - Page 15 ≥ Extremely high temperatures or low Put this unit near the outlet to make it easy temperatures will shorten the life of the for the interrupting device (plug) to reach battery. ≥ If the battery is kept in high-temperature, If the battery has excessively discharged high-humidity, or oily-smoky places, the or the battery temperature is extremely terminals may rust and cause...
- Page 16 After use, be sure to eject the SD card, and store it away. ≥ After use, or when storing or carrying the SD card, put it in the storage case. ≥ Do not allow dust, water, or foreign substances to adhere to the terminals on the back of the SD card.
-
Page 17: Troubleshooting
¬ Troubleshooting Problem Check points ≥ Is the battery fully charged? This unit cannot be > Charge the battery using the AC adaptor. (P8) turned on. ≥ If you do not use the unit for approximately 3 minutes, the This unit is turned off power is automatically turned off to conserve the battery automatically. - Page 18 > If you format this unit’s HDD on a PC it will no longer operate properly. Please confirm the latest support information on the following website. (This website is in English only.) http://panasonic.co.jp/pavc/global/cs/e_cam/faq/index.html ≥ The capacity of the HDD is usually displayed as 1 gigabyte The capacity of the HDD equaling 1,000,000,000 bytes.
-
Page 19: Specifications
Operating humidity 10% to 80% Battery operation 4 GB card: Consecutive copying about 9 times time (when using a Panasonic SDHC Memory Card (4 GB) and copying motion picture data) Copy time 4 GB card: About 11 minutes (when using a Panasonic SDHC Memory Card (CLASS2, 4 GB) - Page 20 If your product does not work properly because of a defect in materials or workmanship, Panasonic Consumer Electronics Company or Panasonic Puerto Rico, Inc. (collectively referred to as “the warrantor”) will, for the length of the period indicated on the chart below, which starts with the date of original purchase (“warranty period”), at its option...
- Page 21 THERE ARE NO EXPRESS WARRANTIES EXCEPT AS LISTED UNDER “LIMITED WARRANTY COVERAGE”. THE WARRANTOR IS NOT LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THIS PRODUCT, OR ARISING OUT OF ANY BREACH OF THIS WARRANTY. (As examples, this excludes damages for lost time, travel to and from the servicer, loss of media or images, data or other memory content.
- Page 22 Monday-Friday 9 am-9 pm; Saturday-Sunday 10 am-7 pm, EST For hearing or speech impaired TTY users, TTY : 1-877-833-8855 Accessory Purchases Purchase Parts, Accessories and Instruction Books online for all Panasonic Products by visiting our Web Site at: http://www.pasc.panasonic.com or, send your request by E-mail to: npcparts@us.panasonic.com...
-
Page 23: Request For Service Notice
Mail this completed form and your Proof of Purchase along with your unit to: Panasonic Camera and Digital Service Center 1590 Touhy Ave. Elk Grove Village, IL 60007... - Page 24 5770 Ambler Drive, Mississauga, Ontario L4W 2T3 PANASONIC PRODUCT – LIMITED WARRANTY Panasonic Canada Inc. warrants this product to be free from defects in material and workmanship and agrees to remedy any such defect for a period as stated below from the date of original purchase.
- Page 25 VQT1B03...
- Page 26 Panasonic Consumer Electronics Company, Division of Panasonic Corporation of North America One Panasonic Way, Secaucus, NJ 07094 Panasonic Puerto Rico, Inc. Ave. 65 de Infantería, Km. 9.5, San Gabriel Industrial Park, Carolina, Puerto Rico 00985 C 2006 Matsushita Electric Industrial Co., Ltd.
