CK4L3000B(S)
Full color LED video
processor

User Manual

V1.0
SHENZHEN CREATEK ELECTRONIC CO.,LTD
http://www.ckdz.com/
Note: Please read the User Manual carefully before using the products, and keep the
manual properly for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CK4L3000B(S) and is the answer not in the manual?

Questions and answers

Related Manuals for CKDZ CK4L3000B(S)

Summary of Contents for CKDZ CK4L3000B(S)

  • Page 1: User Manual

    CK4L3000B(S) Full color LED video processor User Manual V1.0 SHENZHEN CREATEK ELECTRONIC CO.,LTD http://www.ckdz.com/ Note: Please read the User Manual carefully before using the products, and keep the manual properly for future reference.

  • Page 2: Table Of Contents

    CK4L3000B(S) User Manual TABLE OF CONTENTS TABLE OF CONTENTS ......................... I 1. SAFETY NOTICE ..........................1 2. HARDWARE STRUCTURE ......................2 2.1 P ........................2 RODUCT ELEVATION 2.2 R ........................2 EAR PANEL DIAGRAM 2.3 F ........................3 RONT PANEL DIAGRAM 3.

  • Page 3: Safety Notice

    CK4L3000B(S) User Manual 1. SAFETY NOTICE Dangerous There’s high voltage in processor. To avoid danger, please do not open rear cap without authorization. Warning Do not allow liquid, small particles or other objects to get into the device; Do not place the system near fire and water; Do not block any vents.

  • Page 4: Hardware Structure

    CK4L3000B(S) User Manual 2. Hardware structure 2.1 Product elevation Fig.2.1 Product elevation 2.2 Rear panel diagram 12 13 Fig. 2.2 Rear panel diagram Interface specification: 1、Ground; 2、DVI I: 1 channel DVI signal input; 3、DVI LOOP OUT: 1 channel DVI signal loop out (only for the DVI input signal); 4、VGA IN: 1 channel VGA analog signal input 5、HDMI IN: 1channel HDMI HD digital signal input 6、...

  • Page 5: Front Panel Diagram

    CK4L3000B(S) User Manual 13、Status indicator light: ACTIVE1, ACTIVE2, it blinks in normal working condition; POWER: it stays lit after power on. 14、Power supply switch 15、Power interface: AC100-240 v 50Hz 16、Sending card: Can built-in two sending cards (optional) 2.3 Front panel diagram Fig.
  • Page 6 CK4L3000B(S) User Manual 3)、 【VGA】:Select computer analog VGA signal input; 4)、 【DVI】:Select DVI computer digital signal input; 5)、 【HDMI】: Select HDMI high definition digital signals input; 6)、 【SDI/STP】:Select SDI digital video signal input or press the button to change step value among 1/10/100 after you enter the setting option.

  • Page 7: Function Setting

    CK4L3000B(S) User Manual 13） 、 【↑/Save】 ：After entering setup menu, press this to go back to previous item. Or: Push the button to save current mode into memory. 14） 、 【↓/Load】 ：: After entering setup menu, press the button to go to next item. Or: to recall the saving modes.
  • Page 8 CK4L3000B(S) User Manual Note: This part requires professional skill on LED video processor; all the settings have been configured before shipment. It is not recommended to make function setting unless you have got training course from our company. 1） Setup menu Double-press【Setup】, status display will prompt “*SETUP?”, press【Enter】to move into the first sub-menu item which is “language selection”...
  • Page 9 CK4L3000B(S) User Manual to take effect. 3） Output image setting The video processor outputs the images through DVI OUT and DVI/VGA OUT connectors. The system can support various resolution outputs and you can go into item #6 (Resolution Out) to select the settings the output format as shown below: LED video processor Model 1024×768_60Hz...
  • Page 10 CK4L3000B(S) User Manual shown in below table. Item Name Name Parameters OutputHstart Hor_Str OutputWidth Hor_Width OutputVstart Vert_Str OutputHeight Vert_Height Fig. 3.8 Correspondence table The initial coordinate (0,0) is defined from the top left corner. According to the size of LED screen (Horizontal pixels and Vertical pixels), you can calculate the start and end coordinate of outputs image.
  • Page 11 CK4L3000B(S) User Manual For example: If video Input/Output resolutions are both set at 1024*768 but in fact that the resolution of LED panel is 384*288, we can set the below parameters to scale the 1024*768 picture to 384*288 area in order to obtain full-screen display on the LED screen. Item Name Function PIP OutputWidth...

  • Page 12: Built-In Sending Card

    CK4L3000B(S) User Manual Note: Pressing【Setup】under any setting process will lead to jump to the item#16. 4. Built-in Sending card Loose the screw and take out the metal plate. Connect the sending card to the interface of the metal plate and insert it back to the case. Notice: make sure the sending card is connected to the PCI slot (white in color) which inside the case tightly.

  • Page 13: How To Open The Control Software

    CK4L3000B(S) User Manual Hard disk: more than 40G. (1) 【en-US】sub-file: “Full color LED image processor. resources.dll”, lack of the file will not be able to use English language; (2) 【dmdll.dll】:Application configuration file (3) 【dmdll_multi.dll】:Application configuration file (4) 【InSid Mode. mode】: This is a mode storage file with 16 presets memory. (5) 【3000B.exe】: Double click the file to operate control software.

  • Page 14: How To Operate Control Software

    CK4L3000B(S) User Manual You will see the main interface as below after the successful launch of software. Fig 5.4 Control software interface 5.3 How to operate control software 5.3.1 Connect and disconnect Click (disconnect) button in software connection area, and the communication between processor and control device will disconnect instantly.

  • Page 15: Ip Control Setting

    CK4L3000B(S) User Manual Fig. 5.7 Picture capture Move the mouse to the bottom right corner, there will appear a cursor as shown on above picture. Users can drag and drop the box to define the captured area by changing window location and size.

  • Page 16: Output Resolution

    CK4L3000B(S) User Manual Fig 5.9 IP setting for device When there is no connected device or occurs abnormal connection, it will pop up the following prompt message: Fig. 5.10 Failure prompt 2、Click to open the window as shown in figure below, here user can make the TCP/IP communication setting manually or automatically.

  • Page 17: Coordinate Operation

    CK4L3000B(S) User Manual Fig. 6.12 Output resolution selection As shown, the video processor offers 13 kinds of output resolution; users can choose to fit the size of LED display. 5.3.5 Coordinate operation Manual input window size, position coordinate or capture picture size, coordinate value, and click【send】.
  • Page 18 CK4L3000B(S) User Manual There are total five options for layouts, the effects are as followings: Fig. 6.17 Layout effects 5.3.6.2 Adjustment of the window position and size Left click the mouse, and then drag it to the size you want; moving the mouse to the window’s right /bottom or right-bottom corner, you can adjust the window size when the mouse changes to a two-way arrow.
  • Page 19 CK4L3000B(S) User Manual Input signal selection Fig 5.19 Click the right mouse button and select input signal in the secondary menu of【signal select】(signal selection); 5.3.6.4 Image parameters Selecting【Image Property】(Image parameters)in right-mouse menu, it will pops up adjustment options. The system has three kinds of options: Brightness, contrast, Saturation.

  • Page 20: Saving Mode Operation

    CK4L3000B(S) User Manual 5.3.6.6 Shut or add window Right click source box and select the secondary menu【Shut this window】, the device will close the current video window. Right click source box and select the secondary menu【Add window】, the device will add one more window as sub-window to the current main window.
  • Page 21 CK4L3000B(S) User Manual Selecting【Mode cycle】 in【Menu 】, and it would pop-up a dialog box, as the picture shows below: Fig. 5.24 Mode setting The 【Save Mode 】list all saved modes. Double click a mode to add it to cycle list, and then set cycle interval time.

  • Page 22: Technical Specification

    CK4L3000B(S) User Manual As shown in above picture, right click on the correspondent mode, an option list will pop out, choose the desired options: Rename, Add to cycle, Remove. 6. Technical Specification 6.1 Input signal technical specifications table: 3×Composite 1×YPbPr/YUV/YCbCr 1×VGA（RGBHV）...

  • Page 23: Output Signals Technical Specifications

    CK4L3000B(S) User Manual Composite：BNC SDI/ HDSDI：BNC Fig. 6.1 Input signals technical specifications 6.2 Output signals technical specifications 1×DVI LOOP OUT 1×DVI/VGA OUT Type/Quantity 1×DVI2 OUT 1×SDI/HD-SDI 1024×768@60Hz、1024×768@50Hz 1280×720@60Hz、 1366×768@60Hz、1366×768@50Hz VGA/DVI 1280×1024@60Hz Resolution 1400×1050@60Hz、1920×1200@60Hz 1600×1200@60Hz、1920×1200@50Hz 1920×1080@60Hz、1920×1080@50Hz 2048×768@60Hz R、G、B = 0.7 V （p_p）/ 75Ω VGA Impedance DVI LOOP OUT：24+5 DVI_I DVI/VGA OUT：24+1 DVI_D...
  • Page 24 CK4L3000B(S) User Manual Fig.7.1 Open the “dotNetFX35. Exe “installation program in CD Fig. 7.2 Installation program start to install ② Select "I have read and accept the terms in the license agreements", and then click “installation"; Fig. 7.3 select agree and install ③...
  • Page 25 CK4L3000B(S) User Manual Fig.7.4 the data needed for download installation ④ After the download is complete, the program starts to install. As shown in the picture below: Fig. 7.5 Download all and start to install ⑤ To exit after the program installation is complete, as shown in the picture below: - 23 -...
  • Page 26 CK4L3000B(S) User Manual Fig. 7.6 Exit installation Serial port operation failure, can not to control processor Possible reasons: A、LED Control software doesn't open serial port; B、Serial port has been damaged; C、The serial port that adopts USB switch to RS232 is not installed properly;...
  • Page 27 CK4L3000B(S) User Manual A、To check whether the input signal source is normal; (To detect by connecting the input signal source to the display device directly) B、To confirm whether AV/VGA/DVI/YPbPr channel input are normal; Using control software or front panel buttons to detect channel switching; C、To confirm the output of the processor connected to the display device properly, and the input signal is connected properly.
  • Page 28 CK4L3000B(S) User Manual D、Enter into display card advanced menu, then change the scanning mode to overscan. E、Change the computer input signal to appropriate resolution; Attentions: 1 The above listed is the common failure in after-sales maintenance. If you find the device failure phenomena are not in above range.
  • Page 29 SHENZHEN CREATEK ELECTRONIC CO.,LTD Address：3/4 F, Block 4, Honghui Industrial Park, Liuxian 2nd Rd., Xin'an Street, Bao'an District, Shenzhen, China Postalcode：518000 Tel：0755-26643017 Fax：0755-26644342 Website：http://www.ckdz.com Service Hotline：400-039-0399...
