- Page 1 CK4L-5000 Ultra-high definition and multi-pictures full color LED video processor User Manual V1.0 Shenzhen Createk Electronic Co., Ltd. http://www.ckdz.com Note: Please read the User Manual carefully before using the products, and keep the manual properly for future reference.
-
Page 2: Table Of Contents
CK4L-5000 User Manual TABLE OF CONTENTS TABLE OF CONTENTS ······························································································································ I 1. SAFETY NOTICE ···································································································································· 1 2. PRODUCT OVERVIEW ························································································································· 2 ··························································································································· 2 2.1. B ASIC FUNCTION ························································································································· 3 2.2. S YSTEM IAGRAM ····························································································································· 3 2.3. F UNCTIONALITY 2.3.1 Flexible display modes: ··································································································· 3 2.3.2 Multiple inputs ····················································································································... - Page 3 CK4L-5000 User Manual 7. TECHNICAL SPECIFICATIONS ······································································································· 21 8. FAQ(FREQUENTLY ASKED QUESTIONS): ················································································· 23 - ii -...
-
Page 4: Safety Notice
CK4L-5000 User Manual 1. SAFETY NOTICE Dangerous There’s high voltage in processor. To avoid danger, please do not open rear cap without authorization. Warning Do not allow liquid, small particles or other objects to get into the device; Do not place the system near fire and water;... -
Page 5: Product Overview
Four(4) spliced DVI outputs can realize max resolution up to 7680x1200, and can open 3-4 video windows if the sending cards are not cascaded ; 2.1. Basic function CK4L-5000 is developed to suit the application for LED screen, its basic functions include: Ø Real-time multiple channel parallel image processing,hardware-based patent technique, no motion smear or sawtooth image;... -
Page 6: System Diagram
2.2. System Diagram CK4L-5000 ultra high definition multi-display full color LED video wall controller can work with up to 4 separate LED screens that could be in different Pitches, such as P4, P6,P10, etc. The videowall is fully scalable, supporting a wide variety of display layouts such common 1x4, 4x1,2x2,1x3,1x2, etc. -
Page 7: Multiple Inputs
CK4L-5000 User Manual screen is not consistent with input signal, the picture will be automatically enlarged or be scaled to fit the LED screen. 2.3.1.2 PIP Mode CK4L5000 support PIP mode, using any input to be background picture (defined as Level 4), the processor allows for the display up to 4 different inputs simultaneously. -
Page 8: Accurate Pixel-Based Capture Technology
B. Switchable memory presets through front control button C. Recall the memory presets through the number buttons on IR controller. 2.3.5 Accurate pixel-based capture technology CK4L-5000 employs the accurate pixel-based capture technology, allowing for any captured content to display full-screen or partially. 3. Hardware structure 3.1 Product elevation... -
Page 9: Hardware Instructional Menu
4. Knob for selection 5. Power supply 4. Hardware instructional menu CK4L-5000 has total 16 front panel buttons (as shown below) , one knob and one power supply,their functions are listed as below: Fig. 4.1Front panel button 4.1 Front panel button overview 1）... -
Page 10: Front Panel Operation
CK4L-5000 User Manual 4.2 Front panel operation Fig. 4.2 Status display when idle In idle status (The equipment is not operated or controlled within 12 seconds.) The status display will show the following information: The 1 line: Equipment model The 2 line: The video wall layout 2x1;... - Page 11 CK4L-5000 User Manual then adjust the Knob Button to choose the desired preset mode, press 【ENTER】 Button to confirm the recall. C. Menu setting Short press 【MENU】 to enter menu setting interface: Fig. 4.3 Menu setting- 1 level menu level menu (sub-menu), press 【CANCEL】to exit the Press【ENTER】to proceed to 2...
-
Page 12: The Instruction For Control Software Operation
5. The instruction for control software operation 5.1. Software installation CK4L-5000 adopts user-friendly design. Its control software requires no installation and the volume is small. The root folder includes following files, you can copy it to any place of - 9 -... -
Page 13: Software Startup
CK4L-5000 User Manual the control computer and then double-click it to execute file program. It saves tedious software installation steps and time. Even computer entry-level users can operate it quickly and easily. Figure 5.1 Folders of control software system Program operating environment: CPU: more than P4;... -
Page 14: Software Operation
CK4L-5000 User Manual Figure 5.3 Communication connection interface when the serial port is already occupied, it would pop-up prompt message as shown in the picture below. The user should check the serial port connection and application program, then release the current serial port and reconnect. -
Page 15: Black Screen On/Off
CK4L-5000 User Manual Figure 5.5 Disconnect the communication connection 5.3.2 Black screen On/Off The “Black screen ON/OFF” enables the switching between the black screen and signal display, the function is equal to the front panel button【 BLACK 】 . Figure 5.6 Close the black screen mode 5.3.3 Memory preset mode... -
Page 16: Video Window Operation
CK4L-5000 User Manual B）Mode recall： Click the number button of saved memory of preset, it will recall the window position, size and input signal of the mode.If the corresponding number button does not save any memory of preset, it will pop up a warning dialog box, as shown in the figure below: Figure 5.9 Prompt for no saved mode... - Page 17 CK4L-5000 User Manual Move the mouse pointer on the video window, then press and drag it to move the window to a appropriate position, and then loose it. Move the mouse pointer to the bottom right of the window, and then drag it to change the window size when it turns into a two-way arrow.
- Page 18 CK4L-5000 User Manual Figure 5.13 Signal sources switching （4）Full screen display Click the right mouse button in the window and select “Full Screen” in the pop up menu. Figure5.14 Full screen display （5）Open and close the video window Open the video window:Click the right mouse button and and select “Close window” in the pop up menu.
-
Page 19: Toolbar For System Settings
CK4L-5000 User Manual Figure 5.16 Shortcut buttons to open the video window （6）Adjust coordinate value It is available to display and set current window’s coordinates value and width&height. “StartX” represents the start coordinate in the direction of X,and the “startY” represents the start coordinate in the direction of Y. - Page 20 CK4L-5000 User Manual Figure 5.20 The window effect after pressing the “reset” button (3) Color settings The setting is for the adjustment and reset of output brightness,saturation and contrast. Figure 5.21 The dialog box for color setting (4)Output settings Click the button “Output”,It pops up a window for screen parameters setting. As show in...
-
Page 21: Pixel Adjustment
CK4L-5000 User Manual window for screen parameters setting Figure 5.22 The A、Setting wizard According to the setup wizard, the users can complete screen parameters setting step by step by instructions. B、Splice style setting Set output resolution and video wall layout,such as 1×2、1×3、2×2 etc.The layout are vary according to different application. -
Page 22: System Menu
CK4L-5000 User Manual Figure 5.23 Pixel adjustment Select corresponding sending card,and click the window need to adjust,then adjust the video window size and location in pixel level. 5.5 System menu There are four menus in the control software interface: 【 system】 , 【 Setting】 , 【 Language】 、... -
Page 23: Communication Port
CK4L-5000 User Manual 图 5.24 Figure 5.24 Submenus of system menu Figure 5.25 About CK4L-5000 6. Communication port 6.1 RS232 Connection This equipment offers standard DB9 RS-232 serial controlling port. It can be controlled by any other third party control device. RS232 pin chart is as follows:... -
Page 24: Technical Specifications
CK4L-5000 User Manual Mode recall protocol code Users can the use RS232 serial command to simple recall the saved inner memory of preset, or program it into the controlling device to realize a third party controlling easily. The protocols are as follows: Control：RS232... - Page 25 CK4L-5000 User Manual Model 4L5000 Full color LED Video processor DVI-I，female，24+5；D-sub，female， Connector 15pin DVI/VG Resolution 1024*768@60hz~2048*1080@60hz Signal output Color depth 32bits Sync HV independent sync Connector D-sub，female，15pin Resolution 640*480@60hz~1920*1200@60hz 32 位 Color depth Sync HV independent sync Connector Resolution PAL/NTSC automatic identification...
- Page 26 CK4L-5000 User Manual Working -20℃ ~60 ℃ Working temperature Environment Working 5-95% humidity Product Standard 1UCase dimension Product weight Net weight::About 2.5kg Certificate Figure 7.14 4L5000 Technical specifications 8. FAQ(Frequently asked questions): 1. Can not startup the machine (power indicator does not light) 1) To confirm whether the power cord has damaged.
- Page 27 CK4L-5000 User Manual 5.Input image appears black frame or shake 1) To confirm whether the VGA cable is in good condition, whether there is any interference around. 2) To confirm whether the LED pixel is correspond to 4L-50000 output setting.
