- Page 1 HDMI Converter and HDMI Converter/Extender Product Manual Thinklogical, LLC ® 100 Washington Street Milford, Connecticut 06460 U.S.A. Telephone: 1-203-647-8700 Fax: 1-203-783-9949 www.thinklogical.com...
- Page 2 Extend Distribute Innovate Copyright Notice Copyright © 2012. All rights reserved. Printed in the U.S.A. Thinklogical, LLC® 100 Washington Street Milford, Connecticut 06460 U.S.A. Telephone: 1-203-647-8700 All trademarks and service marks are property of their respective owners. Subject: SDI to HDMI Converter Product Manual Revision: Rev C, July 2012 SDI to HDMI Converter, Rev.
-
Page 3: Table Of Contents
Table of Contents Preface Conventions Used in this Manual Introduction 1.1 Contents 1.2 Product Overview System Features 2.1 General System Features 2.2 Technical Specifications Connecting the SDI to HDMI Converter 3.1 RS-232 Pin Out 3.2 User Menu Configurations Regulatory and Safety 4.1 Safety Requirements 4.1.1 Symbols Found on Product 4.2 Regulatory Compliance... -
Page 4: Preface
When you receive your Thinklogical SDI to HDMI Converter, you should find the following items: ® SDI to HDMI Converter (SDC-000001) or • SDI to HDMI Converter/Extender (SDC-000001-LC) AC/DC adapter universal input 90-264 VAC – PWR-000022-R • SDI to HDMI Converter product manual. •... -
Page 5: Product Overview
SDI signal to HDMI. The unit is full SMPTE compliant, including the active loop out port. FIGURE 1: Top View of SDI to HDMI Converter (P/N SDC-000001) FIGURE 2: Top View of SDI to HDMI Converter/Extender (P/N SDC-000001-LC) SDI to HDMI Converter, Rev. C... -
Page 6: System Features
SDI signal to HDMI. The SDI to HDMI Converter is full SMPTE compliant, including the active loop out port. The SDI to HDMI Converter/Extender has a fiber output that is fully compatible with our Velocity line of receivers as well as our VX routers for a comprehensive conversion and extension solution. -
Page 7: Technical Specifications
2.2. Technical Specifications Frame Rate Formats Supported: Progressive, Interlaced, PsF Function Video Standards Supported Formats SD-SDI SMPTE 259M PAL and NTSC HD-SDI SMPTE 292M All standard HD-SDI compatible formats All SMPTE 425 level A and B compatible 3G SDI SMPTE 424M, 425M, Level A and B formats Storage Temperature 0 to 50 deg C , 5 –... -
Page 8: Connecting The Sdi To Hdmi Converter
3. Connecting the SDI to HDMI Converter RS-232 Pin Out User Menu Configurations: The IEX3 has many configuration options and this document will cover these options in detail. Every configuration can be set regardless of the user interface (e.g. RS-232, RS-422, Front Panel Display, Web Interface). - Page 9 MAIN MENU: Set Input Select Note: A valid input must be applied in order for the configuration to be used. Single Link Input This option forces a re-configure of the unit. A valid signal needs to be present. Enable Loop Output This will enable the video signal applied to input 1 to be looped back out of the IEX3.
- Page 10 Adapt. Contrast Enhancer Selects the menus for the Adaptive Contrast Enhancer (ACE) video processing functions. 3D Control Menu Selects the menu for output 3D processing formats. MAIN MENU: Audio Info and Setup Enable Audio Output Enables the embedded audio output from the selected input. Disable Audio Output Mutes all embedded audio output channels.
- Page 11 MAIN MENU: System Settings Ethernet Settings Settings for the network interface. Default Settings: IP Address – 192.168.75.200 Mask – 255.255.255.0 Gateway – 0.0.0.0 Enable HDMI Output Video Mode Enables the HDMI output to be in true HDMI mode. Enable DVI Output Video Mode Enable this option if the sink device is a true DVI monitor/projector.
- Page 12 Mosq. Noise Reducer EN Enables the Mosquito (Ringing) Noise Reducer. Block Noise Reducer EN Enables the Block (8x8) Noise Reducer. Non Std Block Noise Det EN Enables the Non-Standard Block Detection. Enable All CAR Blocks Enables All the above (A,B,C,D) Noise Reduction Blocks. Disable All CAR Blocks Disables All the Noise Reduction Blocks.
- Page 13 Noise Reducer 3D Adapt Sets the Noise Reducer for 3D Adaptive (Temporal) mode. Noise Reducer Default Sets the Noise Reducer for Default mode. Noise Reducer Automatic Sets the Noise Reducer for Automatic mode. MAIN MENU: Video Processing Setup SUB-MENU: Picture Control Set All Levels Default Restores Contrast, Brightness, Tint, Black, Color Temp levels to defaults.
- Page 14 MAIN MENU: Video Processing Setup SUB-MENU: Color Management Unit Selects the menus for Color Management Unit (CMU) video processing functions. Hue Saturation Menu Video Hue Saturation Menu Hue Saturation ENABLE Hue Saturation DISABLE Intelligent Saturation ENABLE Intelligent Saturation DISABLE Set HUE Saturation Level Set HUE Global Sat.
- Page 15 MAIN MENU: Video Processing Setup SUB-MENU: Adapt. Contrast Enhancer Selects the menus for Adaptive Contrast Enhancer (ACE) video processing functions. ACE PRESET OFF ACE PRESET LOW ACE PRESET MEDIUM ACE PRESET HIGH ACE PRESET RANGE 0-255 ACE PRESET RANGE 16-235 ACE Brightness Menu Brightness DISABLE Brightness DEFAULT...
-
Page 16: Regulatory And Safety
Markings and labels on the product follow industry-standard conventions. Regulatory markings found on the products comply with requirements. 4.2 Regulatory Compliance Thinklogical products are designed and made in the USA. Our products have been tested by a ® nationally recognized testing laboratory and found to be compliant with the following standards (both domestic USA and many international locations). -
Page 17: European Union Declaration Of Conformity
Telephone 1-203-647-8700 Product name SDI to HDMI Converter (Part number SDC-000001) SDI to HDMI Converter/Extender (Part number SDC-000001-LC) This product complies with the requirements of the Low Voltage Directive 72/23/EEC and the EMC Directive 89/336/EEC. 4.2.2.2 Standards with which the Products Comply... -
Page 18: Supplementary Information
The user may notice degraded audio performance in the presence of electromagnetic fields. 4.2.4 Product Serial Number Thinklogical products have a unique serial number, imprinted on a small silver label that is ® placed on the bottom of the chassis. The serial number includes a date-code. The format for the date-code is two digits for the month;... -
Page 19: How To Contact Us
– Information about Thinklogical and our products. ® sales@thinklogical.com – Sales Department - orders, questions or issues. support@thinklogical.com – Product support, technical issues or questions, product repairs and request for Return Authorization. SDI to HDMI Converter, Rev. C... -
Page 20: Telephone
(ii) modifications to or repairs of the product that are made by any party other than Thinklogical or a party acting on Thinklogical’s behalf, or (iii) combination of the product with third party products that is not consented to by Thinklogical. -
Page 21: Our Address
3. Pack the product in all of its original packing, if possible, and write the RMA number on the box. 4. Return the product to: Thinklogical, LLC ® Attn: RMA# [Insert the RMA# issued to you, by Thinklogical, here.] 100 Washington Street Milford, CT 06460 USA Note: Extended warranties are available from Thinklogical at an additional cost. -
Page 22: Appendix A: Application Diagrams
Appendix A- Application Diagrams Thinklogical conversion application using SDI to HDMI Converter with fiber extension, VX80 ® Router, 3 AV+ Receiver, HDMI to SDI Converter SDI to HDMI Converter, Rev. C July, 2012... - Page 23 Thinklogical conversion application using HDMI to SDI Converter, HDX80 Router, SDI to HDMI ® Converter SDI to HDMI Converter, Rev. C July, 2012...
- Page 24 Receiver HDMI/DVI Source HDX80 Router Pan/Tilt/Zoom Controller HDMI Converter HDMI Converter Thinklogical conversion application using HDMI to SDI Converter with fiber output, HDX80 ® Router, SDI 3G+ Receiver, SDI to HDMI Converter SDI to HDMI Converter, Rev. C July, 2012...
-
Page 25: Appendix B: Quick Start Guide
Appendix B- Quick Start Guide SDI to HDMI Converter, Rev. C July, 2012... -
Page 26: Appendix C: Gui
APPENDIX C: GUI The Graphical User Interface (GUI) for the SDI to HDMI Converter was developed to easily create, set and recall custom configurations. There are 6 main menus that allow you to configure the Input/Output, Video Processor, Audio, User Configurations, Xtreme 3G and System Information. - Page 27 Video Processor > Video Control The Video Control sub-menu allows you to control DeInterlacer, Noise Reducer, Compression Artifact Reducer, Edge Enhancer, and Adaptive Contrast Enhancer. SDI to HDMI Converter, Rev. C July, 2012...
- Page 28 Video Processor > Picture Control The Picture Control sub-menu allows you to control Hue Saturation, Advanced Color Remapping, Flesh Tone Correction and Color Temperature. You can also reset all levels back to the factory default. SDI to HDMI Converter, Rev. C July, 2012...
- Page 29 Audio The Audio menu allows you to select which output audio channel is sourced with any input audio channel. It also allows you to enter an audio delay (from -50 ms to +50 ms) when needed. SDI to HDMI Converter, Rev. C July, 2012...
- Page 30 User The User menu allows you to save your current configuration by name or restore factory configuration. You can also use the drop down menu to “Select Config Name” and set power on configuration (which sets the current configuration to be the default power on configuration), restore factory configuration and delete the selected configuration.
- Page 31 Fiber Link The Fiber Link menu is valid only if the Optical Module Option is installed. This menu allows you to view the Thinklogical Velocity Module and SFP information of the unit in use. SDI to HDMI Converter, Rev. C...
-
Page 32: System Info
System Info The System Info menu allows you to view information for the inputs and outputs as well as Genlock and software and firmware versions. SDI to HDMI Converter, Rev. C July, 2012...
