gobandit Action Camera User Manual page 3

13
14
15
16
17
DISPLAY
1
2
3
4
5
6
wiFi
1080p
HD
7
S D
8
9
AVg
mph
MAx km/h
Link
13. Anti fog Inserts department
14. Mini-HDMI port
15. Battery slot
16. microSD card slot
17. Clamp / Door lock
18. Safety leash hook
18
1. Battery status:
when charging segments scrolling
2. GPS status:
10
blinking = searching
solid = GPS available
3. Upper display
11
Screen:
4.
elapsed time/remaining time
Lower display
5.
6. Wi-Fi On
12
7. Video mode
13
8. 1080p, HD or SD video resolution
9. Picture mode
10. SD card error / SD card full warning
14
11. Recording (flashing)
15
12. Speed: in km/h or mph
13. Screen: average and max speed
16
14. Altitude: in m or ft
17
15. Altitude icon
16. Speed Icon
17. ANT+ Link
(only gobandit LIVE camera)
(only gobandit LIVE camera)
3
