NETWORK SETTINGS

To access network settings for the server, in SETTINGS, click on NETWORK. The network
settings dialog will appear.

PRIMARY INTERFACE NIC

Click on the PRIMARY INTERFACE tab to change the settings for NIC port #1 on the server.
The Primary Interface NIC can be configured as Static IP or Dynamic IP. The IP address and
other credentials like subnet mask, default gateway and DNS name servers need to be
provided. For Dynamic IP address configuration the primary NIC is a DHCP client and the
IP address and other credentials are automatically assigned by the user's DHCP server.
The primary NIC is a DHCP client.

SECONDARY NIC

Click on the SECONDARY INTERFACE tab to change the settings for NIC port #2 on the
server. Select the option to ENABLE or DISABLE this port.
The Secondary NIC can be enabled or disabled by the user using the Enable Secondary NIC
checkbox. Note that the secondary NIC is a DHCP server.
59
