Sly Electronics MP3 Player User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MP3 Player and is the answer not in the manual?

Questions and answers

Related Manuals for Sly Electronics MP3 Player

Summary of Contents for Sly Electronics MP3 Player

  • Page 2: Table Of Contents

    3、 The software, hardware or instruction manual are subject to change and improvement should without notice .All rights reserved. Reminder :Thank you for choosing the MP3 player! Please read the following user manual carefully to ensure easy to operation of the player.
  • Page 3 2.3 Disconnect USB port setting………………………………………………………………………………………………………………...7 3. Basic operation…………………………………………………………………………………………………………………………………..9 3.1 Button and function………………………………………………………………………………………………………………………….9 3.2. Operation of ON/OFF……………………………………………………………………………………………………………………..10 4. How to use your MP3 player……………………………………………………………………………………………………………………10 4.1 Play MP3 file…………………………………………………………………………………………………………………………………10 4.2 Lock function…………………………………………………………………………………………………………………………………10 5. Software update method………………………………………………………………………………………………………………………...11 6. Familiar fault solutions…………………………………………………………………………………………………………………………..13 7.Detailed Specifications…………………………………………………………………………………………………………………………...14...
  • Page 4 Attention Please do not use the player with earphone while driving an vehicle or riding a bicycle, It is not only dangerous, but also against the law. And please keep your volume down when crossing streets. Please insert earphone into earphone jack before opening the player in order to avoid spoiling the earphone, By this way, player can be taken good care.

  • Page 5: System Request

    Real capacity range after stored firmware 128MB 122MB~128MB 73MB～127MB 256MB 244MB~256MB 191MB～255MB 512MB 488MB~512MB 428MB～511MB 953MB~1000MB 879MB～999MB 1907MB~2000MB 1804MB～1999MB System request System requirements of MP3 player Microsoft ® Windows98SE/2000/Me/XP Pentium 200MHZ or greater USB port supported 120MB of available hard disk space...

  • Page 6: Instruction

    Mouse installed CD-ROM driver 1. Installation instruction 1.1.Install the driver for Windows operating system 98SE...

  • Page 7: Installation The Battery

    1.2 Installation battery Install one LR03 AAA size 1.5V alkaline or 1.2V NiMH battery properly upon indicator on the player. Press the button to power the player on and enter the MP3 standby mode. 2. Connect to the PC and download 2.1 Connecting to a PC Before operating, please make sure the player is power off.
  • Page 8 Reminder: the root directory of player can only hold no more than 99 pieces files, the subdirectory of player can only hold no more than 99 pieces files. 2.3 Disconnect USB port setting A. Remove USB device" Double click the icon “safely remove the hardware“ B.Select “USB Mass Storage device”...

  • Page 9: Basic Operation

    C.Select OK to ensure it is safely remove the hardware from the PC. Warning: An error might occur if remove the connection of the USB cable when transferring data. After data transferred and “Safe to remove hardware ”window appeared the player can be removed from PC safely! While the USB cable is operating, other keys on the player are unavailable.

  • Page 10: Operation Of On/Off

    On the tune off Menu，press key，The player start work after the indicator light glitter for 5 seconds On the play Menu or pause Menu, the player save the data and get into power off menu. 4.How to use your MP3 player 4.1 Play MP3 file A.

  • Page 11: Software Update Method

    Firstly, please find out the “Factory4.exe” progress in the compress bag and then double click the “Factory4.exe” icon. Hold and press the “V+” button and plug the MP3 Player in the PC USB port. Then there will be a yellow ring display in the NO.1 blank shown as picture 2.
  • Page 12 When the yellow ring changed to be a green tick, the upgrade will be successeful shown as picture 4. Firmware Feature Remind：Please copy the files of player to somewhere, because the player will format itself automatically after the process update. Please go to website to get some information about firmware upgradeable and the way of format for player...

  • Page 13: Familiar Fault Solutions

    6. Familiar fault solutions No sound at playing. Low volume or no music inside the Adjust volume, or download the file. memory. Please recharge the battery. Battery is out of power. Download other music files. MP3/WMA music file is destroyed. Can not download HOLD key is on the lock position.

  • Page 14: Detailed Specifications

    7. Detailed Specifications Bit rate: 32~320Kbps S/N ratio: >85dB Distortion: <0.05% USB port: USB 2.0 full speed Memory size: 128M/256M/512M Dimension: 86.2*26*18mm Output power: 5mW*2 Weight:18.5g Battery life: >9 hours, low consume Frequency: >80(1KHZ) Operation conditions: Humidity <85%,-5~40 degree File-saving condition: Humidity <90%,Normal temperature Getting Started:2GB:1000 songs 4GB:2000 songs...
