- Page 1 High Efficiency Midrange Speaker MODEL XTX64 XTX68 XTX84 XTX88 XTX104 XTX108 OWNER’S MANUAL...
- Page 2 RESPONSE AND IMPEDANCE CURVES, 1W/1M SPL vs Freq SPL vs Freq dBSPL dBSPL 20 Hz 20 Hz 1: XTX64-SPL-2012.12.15 1# 5: XTX84-SPL-2012.12.15 3# XTX64/XTX68 XTX84/XTX88 Data Measured: Dec 15, 2012 Sat 3:41 pm Data Measured: Dec 15, 2012 Sat 4:04 pm 4.5.0.351...
- Page 3 TEMPLATE FOR XTX64 / XTX68 45º SPEAKER PARAMETER Max Music MODEL FO(Hz) Vas(Liter) SPL(dB) Power(W) XTX64 5.477 0.777 0.68 97.3 1000 5.477 0.777 0.68 97.4 1000 XTX68...
- Page 4 TEMPLATE FOR XTX84/ XTX88 45º SPEAKER PARAMETER MODEL FO(Hz) Vas(Liter) SPL(dB) Power(W) XTX84 4.52 0.54 0.48 98.1 1200 XTX88 4.52 0.54 0.48 98.2 1200...
- Page 5 TEMPLATE FOR XTX104 / XTX108 45º SPEAKER PARAMETER MODEL FO(Hz) Vas(Liter) SPL(dB) Power(W) XTX104 7.11 0.43 16.8 99.6 1600 7.11 0.43 99.5 1600 XTX108 16.8 Speaker System Orion Car Audio...
