Rayovac Multi-System Charger 3-1 User Manual page 4

.
battery compartment (Figure 3) and AAs (due to their
larger size) fit into the upper portion of the
compartment. (Figure 4). Your Rayovac Multi-System
Charger will charge up to four Ms or AAAs at a time.
Each of the four battery compartments only holds one
battery at a time.
3. Close the charge cover.
4. Plug the Charger directly into any
wall socket (standard 220-240 volt
AC outlet).
5. Look for the green LED light to go
on (Figure 5). The light indicates
the battery in that compartment
is inserted correctly and taking a
charge.
check to ensure:
Figure 3
Occasionally, a Rayovac Rechargeable Alkaline Battery
inserted correctly may not cause the charging light to go
on. Leave it in the Charger, and check it in one hour.
If the light still does not go on, discard the battery.
fully charged. Unplug the Charger before removing
batteries. Batteries will charge overnight.
not on,
go
Positive(+) sign on battery
matches (+) sign on the
Charger.
Battery is properly seated in
the compartment.
Charger is fully plugged into
electrical wall outlet.
Battery needs charging (it may already be
fully charged).
The compartment is not empty (empty
compartments will not light green LED).
The green LED lights will go out when batteries are
Green
Lights
Figure 5
