Instructions for installation,
use and maintenance
GAS KITCHENS
K2FZ · K4FZ · K4FZS · K6FZ · K8FZ
K4FZFCG · K4FZSFCG · K6FZFCG · K8FZFCG
K4FZFG · K4FZSFG · K6FZFG · K8FZFG
K4FZFCE · K4FZSFCE · K6FZFCE · K8FZFCE
K4FZFE · K4FZSFE · K6FZFE · K8FZFE
K6FZFGA
B4FZ · B6FZ · B8FZ
OP2FZ · OP4FZ · OP6FZ · OP8FZ
© COPYRIGHT 2004 GIGA GRANDI CUCINE SRL
Advertisement
Table of Contents
Related Manuals for GIGA K2FZ
Summary of Contents for GIGA K2FZ
-
Page 1: Instructions For Installation
03/2006 Instructions for installation, use and maintenance GAS KITCHENS K2FZ · K4FZ · K4FZS · K6FZ · K8FZ K4FZFCG · K4FZSFCG · K6FZFCG · K8FZFCG K4FZFG · K4FZSFG · K6FZFG · K8FZFG K4FZFCE · K4FZSFCE · K6FZFCE · K8FZFCE K4FZFE · K4FZSFE · K6FZFE · K8FZFE K6FZFGA B4FZ ·... - Page 2 CHARACTERISTICS Supplied by: Date: Customer Service: e-mail 063_03 - GAS KITCHENS 03/2006 2 · 22...
- Page 3 INDEX Diagram 6 Instructions for use 6.1 Safety, cleaning and repair rules Features of the appliances 6.2 Start-up Technical data 6.2.1 Lighting and disconnecting open flame burner 6.3 Lighting and shutting down a gas oven 4 Installation instructions 6.3.1 Lighting the pilot (gas oven GN 1/1) 4.1 Safety rules 6.3.2 Lighting the pilot (gas oven GN 2/1 and MAXI) 4.2 Structure, framework and safety devices of the appliances...
- Page 4 K4FZFG K4FZFCE K4FZFE 3/4" K2FZ 3/4" 3/4" 100 150 K4FZ - K4FZFCG K4FZS - K4FZSFCG K2FZ - OP2FZ K4FZFG - K4FZFCE - K4FZFE K4FZSFG - K4FZSFCE - K4FZSFE 3/4" 3/4" 3/4" 3/4" B4FZ 4.0 kW Ø 100 mm 6.0 kW 3/4"...
- Page 5 1 - DIAGRAM 1200 K6FZFCG K6FZFG K6FZFCE K6FZFE 3/4" K6FZFGA 3/4" 100 150 1094 B6FZ 3/4" 3/4" 3/4" K6FZ - K6FZFCG K6FZFG - K6FZFCE - K6FZFE K6FZFGA 1200 OP6FZ 1094 OP6FZ 4.0 kW Ø 100 mm 6.0 kW Ø 120 mm 9.5 kW Ø...
- Page 6 1 - DIAGRAM 1600 K8FZFCG K8FZFG K8FZFCE 3/4" K8FZFE 3/4" 100 150 1494 3/4" B8FZ 3/4" 3/4" K8FZ - K8FZFCG K8FZFG - K8FZFCE - K8FZFE 1600 OP8FZ 1494 OP8FZ 4.0 kW Ø 100 mm 6.0 kW Ø 120 mm 9.5 kW Ø...
-
Page 7: Characteristics Of The Appliances
DELL'INSTALLAZIONE E DELL'UTILIZZAZIONE DELL'APPARECCHIO. L'APPARECCHIO DEVE 20 mbar ESSERE INSTALLATO DA PERSONALE QUALIFICATO. 3 - TECHNICAL DATA Model Description Dimensions in mm. (LxDxH) K2FZ 2 burners - open compartment 400 x 900 x 900/970 51BQ2899 OP2FZ 2 burners, embossed 400 x 900 x 270/340 51BQ2899 K4FZ •... - Page 8 Nominal thermal power 12.0 Minimum thermal power 0.75 Overall thermal power (gas) Hour consumption G30/G31 kg/h K2FZ • OP2FZ 13.9 1,47 1,09 K4FZ • K4FZFE • K4FZFCE • B4FZ • OP4FZ 29.8 3,15 2,33 K6FZ • K6FZFE • K6FZFCE • B6FZ • OP6FZ 40.2...
-
Page 9: Installation Instructions
4 - INSTALLATION INSTRUCTIONS 4.1 Safety rules and steel (for MAXI), is in two pieces. The smoke collector is in aluminised sheet metal and the protection grill is in enamelled cast iron. • Only a local gas utility technician is authorized to carry out gas installations and connections. -
Page 10: Installation
4 - ISTRUZIONI PER LA MESSA IN OPERA If the type of gas indicated on the data plate of the appliance does 4.3.6 Smoke extraction not correspond to the gas which is present, refer to the paragraph These kitchens are type A appliances, thus no smoke extraction sys- "Conversion and adaptation". -
Page 11: Operation Control
5 - SET-UP FOR OPERATION Fig. 1 5.1.4 Power check with volumetric method 5.1.6 Check of pilot flame Using a gas meter and a stopwatch, you can read the volume of gas For proper regulation, the pilot flame must surround the thermo- output per time unit. - Page 12 5 - SET-UP FOR OPERATION Fig. 2A Fig. 2B Fig. 2C 063_03 - GAS KITCHENS 03/2006 12 · 22...
-
Page 13: Maintenance
5 - SET-UP FOR OPERATION 5.1.9 Operator training primary air. See the table "TECHNICAL DATA". • Explain and show the user how the machine works according to the instructions, and hand him this manual. 5.1.17 Replacement of nozzle of gas oven GN 1/1 (Fig. 2B) and gas oven MAXI (Fig. - Page 14 5 - SET-UP FOR OPERATION Fig. 3A Fig. 3B 5.3.3 Plug of gas oven (Fig. 2A/2B - Pos. 6) 5.3.8 Heating elements for electric oven GN 1/1 (Fig. 4B) Unscrew the fastening screws and remove the lower panel, extract Unplug the appliance from the electrical mains! the ignition wire and unscrew the screws (15).
-
Page 15: Safety, Cleaning And Repair Rules
6 - INSTRUCTIONS FOR USE 6.1 Safety, cleaning and repair rules any non-compliance with the provisions contained in this manu- • This appliance is used for the preparation of meals at industri- 6.2 Start-up al level. Usage and cleaning can be carried only by expert per- sonnel. -
Page 16: Turning The Appliance Off In Case Of Breakdown
6 - INSTRUCTIONS FOR USE Fig. 4B 6.3.3 Lighting gas oven GN 1/1 (Fig. 3B) In this position the top heating element (from above) and the bottom heating element (from below) are on, and at the Turn on the switch located up the line from the unit. Press the knob same time the fan is in operation (convection). -
Page 17: Appliance Care And Frequency Of Maintenance
6 - INSTRUCTIONS FOR USE 6.7 Appliance care and frequency of maintenance • contact with non-ferrous metals (element build up) • lack of oxygen (i.e. no air inlet, water lacking oxygen). Attention! When cleaning, carefully avoid washing the appliance with direct water jets or high-pressure 6.8.2 Warnings and advice for maintenance of stain- water! less steel appliances... - Page 18 6 - INSTRUCTIONS FOR USE 6.8.3 The 2002/96/EC (WEEE) Directive: information to users This informational note is meant only for owners of equipment marked with the symbol shown in Fig. A on the adhesive label featu- ring the technical specifications applied on the actual product (the label also giving the serial number).
-
Page 19: Appendix: Electrical Diagrams
7 - APPENDIX: ELECTRICAL DIAGRAMS K4FZFCE - K4FZSFCE - K6FZFCE - K8FZFCE Terminal board Grill heating element Commutator Bottom heating element Green indicator light Fan heating element Green indicator light Motorized fan Top heating element Thermostat Grill heating element 063_03 - GAS KITCHENS 03/2006 19 ·... - Page 20 7 - APPENDIX: ELECTRICAL DIAGRAMS K4FZFCE - K4FZSFCE - K6FZFCE - K8FZFCE L 2 L 3 400 V 3N ~ 8.48 A R1/R2 L1 L 2 L 3 230 V 3 ~ 14.75 A R1/R2 230 V ~ 25.7 A Connected power: 5.9 kW 230/400 Terminal Indicator light (power)
- Page 21 7 - APPENDIX: ELECTRICAL DIAGRAMS K4FZFE 4 - K4FZSFE 4 - K6FZFE 4 - K8FZFE 4 R1/R2 L1 L 2 L 3 230 V 3 ~ 14.75 A Terminal board Switch R1/R2 Thermostat Temperature limiter Green indicator light Orange indicator light Upper heating elements 230 V ~ 25.7 A Lower heating elements...
- Page 22 IF THE INSTRUCTIONS CONTAINED IN THIS MANUAL ARE NOT OBSERVED. GIGA GRANDI CUCINE S.r.l. - Via Pisana, 336 - Loc. Olmo - 50018 SCANDICCI (FI) - ITALY - Tel. +39 055 722 33 (11 linee r.a.) - Fax +39 055 7310 056 - www.gigagrandicucine.it -...
