Page 1: Instructions For Installation
011_03 07/2009 Instructions for installation, use and maintenance GAS KITCHENS K2F · K4F · K4FS · K6F · K8F K4FFE · K4FSFE · K6FFE · K8FFE K4FSFCE K4FSFCG K4FFG · K4FSFG · K6FFG · K8FFG K6FFGA B4F · B6F · B8F OP2F ·... - Page 2 CHARACTERISTICS Supplied by: Date: Customer Service: e-mail 011_03 - GAS KITCHENS 07/2009 2 · 22...
- Page 3 INDEX Diagram 6 Instructions for use 6.1 Safety, cleaning and repair rules Features of the appliances 6.2 Start-up Technical data 6.2.1 Lighting and disconnecting open flame burner 6.3 Lighting and shutting down a gas oven 4 Installation instructions 6.3.1 Lighting the pilot (gas oven GN 1/1) 4.1 Safety rules 6.3.2 Lighting the pilot (gas oven GN 2/1 and MAXI) 4.2 Structure, equipment and safety devices of the appliances...
- Page 4 1 - DIAGRAM K4FFG K4FFE 3/4" 3/4" 3/4" 100 150 K4FS - K4FSFCG K2F - OP2F K4FFG - K4FFE K4FSFG - K4FSFCE - K4FSFE 3/4" 3/4" 3/4" 3/4" 4.3 kW Ø 80 mm 6.4 kW 3/4" Ø 100 mm 8.3 kW Ø...
- Page 5 1 - DIAGRAM 1200 K6FFG K6FFE K6FFGA 3/4" 3/4" 100 150 1094 3/4" 3/4" 3/4" K6FFG - K6FFE K6FFGA 1200 OP6F 1094 OP6F 4.3 kW Ø 80 mm 6.4 kW Ø 100 mm 8.3 kW Ø 120 mm 011_03 - GAS KITCHENS 07/2009 5 ·...
- Page 6 1 - DIAGRAM 1600 K8FFG K8FFE 3/4" 3/4" 100 150 1494 3/4" 3/4" 3/4" K8FFG - K8FFE 1600 OP8F 1494 OP8F 4.3 kW Ø 80 mm 6.4 kW Ø 100 mm 8.3 kW Ø 120 mm 011_03 - GAS KITCHENS 07/2009 6 ·...
-
Page 7: Characteristics Of The Appliances
2 - CHARACTERISTICS OF THE APPLIANCES These appliances are used for professional purposes. Installation, The data plate is located on the front part of the appliance (on the repair and use must be carried out by expert personnel. control panel). These instructions for installation are for our gas kitchens set up for the category in the table on page 8. - Page 8 26.5 Nominal thermal power 12.0 Minimum thermal power 0.75 Overall thermal power (gas) Hour consumption G30/G31 kg/h K2F • OP2F 11.2 1,19 0,88 K4F • K4FFE • B4F • OP4F 28.3 2,99 2,21 K6F • K6FFE • B6F • OP6F 39.5...
-
Page 9: Installation Instructions
4 - INSTALLATION INSTRUCTIONS 4.1 Safety regulations The smoke collector is in aluminised sheet metal and the protection grill is in enamelled cast iron. • Only a local gas utility technician is authorized to carry out gas installations and connections. The statutory regulations (applied Gas version GN 1/1 ventilated in Germany VDE, Austria ÖVE, Switzerland SEV, etc.) and connec- The tubular burners are in stainless steel and are resistant to ther-... -
Page 10: Set-Up For Operation
4 - INSTALLATION INSTRUCTIONS 4.3.2 Statutory regulations and technical requirements 4.3.6 Smoke extraction During installation of the appliance, the following regulations must These kitchens are type A appliances, thus no smoke extraction sys- be adhered to: tem is required. • relevant legal directives; For the ventilation of the room where the appliance is installed, refer to related legislation. -
Page 11: Oven
5 - SET-UP FOR OPERATION Fig. 1 12 13 11 Bruciatori Burners X - Y X - Y Bruciatore Burner Z 5.1.3 Checking the input pressure (Fig. 1) WARNING Input pressure should be measured using a fluid measuring gauge There is no pre-adjustment device for the nominal (e.g. - Page 12 5 - SET-UP FOR OPERATION Fig. 2A Fig. 2B Fig. 2C 011_03 - GAS KITCHENS 07/2009 12 · 22...
-
Page 13: Maintenance
5 - SET-UP FOR OPERATION 5.1.8 Operation Control 5.1.14 Replacement of pilot nozzle for gas oven GN 2/1 (Fig. 2A) • Start the appliance in accordance with the instructions. Remove the front/lower panel by removing the fastening screws. • Check that the appliance does not have any leaks by using a leak- detecting spray. -
Page 14: Replacing Parts
5 - SET-UP FOR OPERATION Fig. 3A Fig. 3B 5.3 Replacing parts 5.3.7 Heating elements for electric oven GN 2/1 (Fig. 4A) Unplug the appliance from the electrical mains! All parts must be replaced by authorized technicians The lower heating element is placed under the bottom. The upper only! heating element is attached to the top of the cooking chamber. -
Page 15: Safety, Cleaning And Repair Rules
6 - INSTRUCTIONS FOR USE 6.1 Safety, cleaning and repair rules changing its essential features. The manufacturer declines all responsibility for any non-compliance with the provisions contained in this manual. • This appliance is used for the preparation of meals at industri- al level. -
Page 16: Turning The Appliance Off In Case Of Breakdown
6 - INSTRUCTIONS FOR USE Fig. 4B Shutdown In this position the "grill" heating element is on, located in the upper part of the oven. To shut off the main burner, turn the knob to the spark position. As in the previous position with the fan on (convection). Only the pilot flame will remain lit. -
Page 17: Appliance Care And Frequency Of Mainte- Nance
6 - INSTRUCTIONS FOR USE 6.6.1 What to do in case of failure or prolonged period the steel, concentrated or at high temperatures. These active sub- of disuse stances include for instance: When the appliance is not to be used for a long time, clean thor- •... -
Page 18: Instructions For Use
6 - INSTRUCTIONS FOR USE 6.8.3 The 2002/96/EC (WEEE) Directive: information to users This informational note is meant only for owners of equipment marked with the symbol shown in Fig. A on the adhesive label featuring the techni- cal specifications applied on the actual product (the label also giving the serial number). -
Page 19: Appendix: Electrical Diagrams
7 - APPENDIX: ELECTRICAL DIAGRAMS K4FSFCE 5 4 3 Terminal board Grill heating element Commutator Bottom heating element P8 P7 P6 P5 P4 P3 P2 P1 Green indicator light Fan heating element Yellow indicator light Motorized fan Top heating element Thermostat 011_03 - GAS KITCHENS 07/2009... - Page 20 7 - APPENDIX: ELECTRICAL DIAGRAMS K4FFE - K4FSFE - K6FFE - K8FFE L 2 L 3 400 V 3N ~ 8.48 A R1/R2 L1 L 2 L 3 230 V 3 ~ 14.75 A R1/R2 230 V ~ 25.7 A Connected power: 5.9 kW 230/400 Terminal Indicator light (power)
- Page 21 7 - APPENDIX: ELECTRICAL DIAGRAMS K4FFE 4 - K4FSFE 4 - K6FFE 4 - K8FFE 4 R1/R2 L1 L 2 L 3 230 V 3 ~ 14.75 A Terminal board Switch R1/R2 Thermostat Temperature limiter Green indicator light Orange indicator light Upper heating elements 230 V ~ 25.7 A Lower heating elements...
- Page 22 IF THE INSTRUCTIONS CONTAINED IN THIS MANUAL ARE NOT OBSERVED. GIGA GRANDI CUCINE S.r.l. - Via Pisana, 336 - Loc. Olmo - 50018 SCANDICCI (FI) - ITALY - Tel. +39 055 722 33 (11 linee r.a.) - Fax +39 055 7310 056 - www.gigagrandicucine.it -...
