- Page 2 SAFETY AND OPERATING MANUAL 6L COMPRESSOR BP6L15...
- Page 3 Please retain this handbook in case you need to refer to any of the information in the future. Your Direct Power power tool comes with a 12-month guarantee, so should it develop a fault within this period contact Screwfix Direct Ltd on Freephone 0500 41 41 41.
-
Page 4: Safety Instructions
SAFETY INSTRUCTIONS WARNING! Read all instructions. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. SAVE THESE INSTRUCTIONS 1) Work area a) Keep work area clean and well lit. Cluttered and dark areas invite accidents. b) Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases or dust. - Page 5 5) Service a) Have your power tool serviced by a qualified repair person using only identical replacement parts. This will ensure that the safety of the power tool is maintained. 6L COMPRESSOR BP6L15...
- Page 6 ADDITIONAL SAFETY INSTRUCTIONS FOR YOUR COMPRESSOR 1. Warning! If not used and maintained correctly this compressor when used with some pneumatic tools can cause serious injury and death. Before attempting to operate this machine, it is important that you read, understand and follow these instructions very carefully.
- Page 7 SYMBOLS Read the manual Warning Caution! Hot surface Wear ear Wear eye and protection dust protection 6L COMPRESSOR BP6L15...
- Page 8 1 ON/OFF PRESSURE SWITCH 2 AIR OUTLET PRESSURE REGULATOR 3 AIR OUTLET PRESSURE REGULATOR LOCK RING 4 AIR OUTLET PRESSURE GAUGE 5 AIR OUTPUT QUICK RELEASE CONNECTOR 6 AIR RECEIVER TANK 7 AIR RECEIVER PRESSURE GAUGE 8 PRESSURE RELIEF SAFETY VALVE 9 AIR PUMP MOTOR 10 CARRYING HANDLE 11 RUBBER FOOT...
-
Page 9: Noise Data
TECHNICAL DATA Voltage: 230V~50Hz Input power: 1.5HP Receiver capacity: CFM: 5.68 FAD @ 90 psi: 54L/min Maximum pressure: 115 psi Net weight: 13.5 kgs NOISE DATA As stated on the machine 6L COMPRESSOR BP6L15... - Page 10 OPERATION INSTRUCTIONS Warning: Before using this compressor be sure to read the instruction manual carefully. 1. ASSEMBLY Remove the bung (if fitted) from the air inlet on the cylinder head and screw in the air filter (See Fig.2). Fig 2 This is an “oil less”...
-
Page 11: Overload Protection
When the compressor switches off there will be the sound of leaking air while the pressure regulating system is depressurised, this will last for only a Fig 6 6L COMPRESSOR BP6L15... - Page 12 few seconds and is quite normal. Check all valves and regulators for leaks. 5.CONNECTING HOSES AND ACCESSORIES Warning! Do not operate accessories at an air pressure greater than the maximum rated air pressure for the accessory. Connect a hose to the compressor using the hose to compressor quick release connector (See Fig.7).
-
Page 13: Environmental Protection
CAUTION. Water must never come into contact with the compressor. SPARES HELPLINE 01302 721791 ENVIRONMENTAL PROTECTION Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with your Local Authority or retailer for recycling advice. 6L COMPRESSOR BP6L15... - Page 14 PLUG REPLACEMENT The fuse in the main plug of your compressor should always be replaced with one of identical rating. Check the voltage given on your compressor matches the supply voltage. The compressor is supplied with a fitted plug, however if you should need to fit a new plug follow the instruction below.
- Page 15 6L COMPRESSOR BP6L15...
-
Page 16: Declaration Of Conformity
Declaration of Conformity We, Importer Direct Power Yeovil BA 22 8RT Declare that the product 6L Compressor BP6L15 Complies with the essential health and safety requirements of the following directives: 89/336/EEC - EMC Directive. 2006/95/EC - Low Voltage Directive. 98/37/EEC - Machinery Directive.
