Summary of Contents for Direct power BP24L20
- Page 2 SAFETY AND OPERATING MANUAL 24L COMPRESSOR BP24L20...
- Page 3 Please retain this handbook in case you need to refer to any of the information in the future. Your Direct Power power tool comes with a 12-month guarantee, so should it develop a fault within this period contact Screwfix Direct Ltd on Freephone 0500 41 41 41.
-
Page 4: Safety Instructions
SAFETY INSTRUCTIONS WARNING! Read all instructions. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. SAVE THESE INSTRUCTIONS 1) Work area a) Keep work area clean and well lit. Cluttered and dark areas invite accidents. b) Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases or dust. - Page 5 5) Service a) Have your power tool serviced by a qualified repair person using only identical replacement parts. This will ensure that the safety of the power tool is maintained. 24L COMPRESSOR BP24L20...
- Page 6 ADDITIONAL SAFETY INSTRUCTIONS FOR YOUR COMPRESSOR 1. Warning! If not used and maintained correctly this compressor when used with some pneumatic tools can cause serious injury and death. Before attempting to operate this machine, it is important that you read, understand and follow these instructions very carefully.
- Page 7 SYMBOLS Read the manual Warning Caution! Hot surface Wear ear Wear eye and protection dust protection 24L COMPRESSOR BP24L20...
- Page 8 1 ON/OFF PRESSURE SWITCH 2 AIR OUTLET PRESSURE REGULATOR 3 AIR OUTLET PRESSURE REGULATOR LOCK RING 4 AIR OUTLET PRESSURE GAUGE 5 AIR OUTPUT QUICK RELEASE CONNECTOR (REGULATED) 6 AIR OUTPUT QUICK RELEASE CONNECTOR (NON REGULATED) 7 AIR RECEIVER TANK 8 AIR RECEIVER PRESSURE GAUGE 9 PRESSURE RELIEF SAFETY VALVE 10 AIR PUMP MOTOR...
-
Page 9: Noise Data
TECHNICAL DATA Voltage: 230V~50Hz Input power: 2.0HP Receiver capacity: CFM: 7.66 FAD @ 90 psi: 76L/min Maximum pressure: 115 psi Net weight: 25 kgs NOISE DATA As stated on the machine 24L COMPRESSOR BP24L20... - Page 10 OPERATION INSTRUCTIONS Warning: Before using this compressor be sure to read the instruction manual carefully. 1. ASSEMBLY Insert the rubber foot into the receptacle on the bottom of the air receiver tank (See Fig.2). Fit the 2 wheels as shown in Fig.3. Fig 2 Remove the bung (if fitted) from the air inlet on the cylinder head and screw in the air filter (See...
-
Page 11: Overload Protection
Fig.6). Check that the water drain cock is closed (See Fig.7). Connect the compressor to a suitable 13A mains supply. Switch on the compressor by pulling up the ON/OFF switch (See Fig.8). The compressor will now start. Fig 8 24L COMPRESSOR BP24L20... - Page 12 When the air receiver tank is pressurised to its working capacity the compressor will automatically switch off. When the compressor switches off there will be the sound of leaking air while the pressure regulating system is depressurised, this will last for only a few seconds and is quite normal.
-
Page 13: Environmental Protection
CAUTION. Water must never come into contact with the compressor. SPARES HELPLINE 01302 721791 ENVIRONMENTAL PROTECTION Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with your Local Authority or retailer for recycling advice. 24L COMPRESSOR BP24L20... - Page 14 PLUG REPLACEMENT The fuse in the main plug of your compressor should always be replaced with one of identical rating. Check the voltage given on your compressor matches the supply voltage. The compressor is supplied with a fitted plug, however if you should need to fit a new plug follow the instruction below.
- Page 15 24L COMPRESSOR BP24L20...
- Page 16 Declaration of Conformity We, Importer Direct Power Yeovil BA 22 8RT Declare that the product 24L Compressor BP24L20 Complies with the essential health and safety requirements of the following directives: 89/336/EEC - EMC Directive. 2006/95/EC - Low Voltage Directive. 98/37/EEC - Machinery Directive.
