Summary of Contents for Giantec VPC6600 Series
- Page 1 VPC6600 Series 2-DIN Vehicle PC Hardware Manual Hardware Manual October 2011, Ver. A.2 VPC6600 Series 2-DIN Vehicle PC Hardware Manual A.2...
-
Page 2: Copyright
This manual is only written for the VPC6600 2DIN Vehicle PC series product with supporting Windows based operating system use. The appropriate models for this user’s manual are in the following list: VPC6600 series VPC6600 Series 2-DIN Vehicle PC Hardware Manual A.2... -
Page 3: Safety Notice
8. Do not disassemble and/or modify this unit. It may cause an accident, fire or electric shock. Please contact your local authorized service agent for inspection and/or repair if you felt the unit is malfunctioning. VPC6600 Series 2-DIN Vehicle PC Hardware Manual A.2... - Page 4 5. Please make sure the rear seat display shall installed at a place or location where the driver is not able to see or getting distraction with. 6. Please to comply the local laws and regulations for installing and/or operating an audio/video combo head unit within vehicle. VPC6600 Series 2-DIN Vehicle PC Hardware Manual A.2...
-
Page 5: Technical Support Information
This warranty does not cover any failure resulting in loss to software, data, lost profits, lost savings, any incidental damages or other economic consequential damages due to accident, abuse, misuse, negligence and acts of God. VPC6600 Series 2-DIN Vehicle PC Hardware Manual A.2... -
Page 6: Packing List
1 x CD (User Manual & Driver CD) External cable kit with multi-lock connectors in 4 pieces (in a inner box) If any of these items are missed or damaged, contact your distributor or sales representative immediately. VPC6600 Series 2-DIN Vehicle PC Hardware Manual A.2... -
Page 7: Table Of Contents
1.3.6 In-Car Entertainment 1.4 Front Panel 1.5 Rear Panel 1.5.1 Connector A 1.5.2 Connector B 1.5.3 Connector C 1.5.4 Connector D 1.6 Side View 1.7 Model View 1.8 Dimension View 1.9 Environment VPC6600 Series 2-DIN Vehicle PC Hardware Manual A.2... - Page 8 2.1.7 Illumination Control Appendix A: Pin Definition for MultiLock 1. Connector A 2. Connector B 3. Connector C 4. Connector D Appendix B: Hard Disk Assembly Instruction Appendix C: Overall Rear I/O Connection Diagram VPC6600 Series 2-DIN Vehicle PC Hardware Manual A.2...
-
Page 9: Chapter 1: Introduction
18 AM /27 FM Station Presets 1.2.3 MultiLock Connection Standard vehicle use Secure data transferring Easy to connect and disconnect 1.2.4 Windows O/S Microsoft Windows XP Embedded Support Windows bases application VPC6600 Series 2-DIN Vehicle PC Hardware Manual A.2... -
Page 10: Multimedia Graphic User's Interface
Internet connection Web browse 1.2.8 Bluetooth Input device connectivity Support hands-free phone features 1.2.9 Smart Power Intelligent power control system Automatically power on/off with delayed time function VPC6600 Series 2-DIN Vehicle PC Hardware Manual A.2... -
Page 11: General Specification
Maximum operating environment temperature: -20c to +60c Input methods Touch screen (4 wire resistance type) 1* Video channel input for parking rear camera 1* RGB Input Video Input 1* LVDS input 1* Video channel input VPC6600 Series 2-DIN Vehicle PC Hardware Manual A.2... -
Page 12: Carrier Board For I/O
Optional OS 1 Windows XP Embedded Optional OS 2 Linux Language Support Multi-Language Dual Zone Display Dual Independent display and control (under OS 1) Welcome Screen Support customized welcome screen (MOQ Required) VPC6600 Series 2-DIN Vehicle PC Hardware Manual A.2... -
Page 13: User Interface
Up to 8 cellular phones capability Telephony Support Phonebook reading from CVS file. Received/Missed/Dialed calls list Option : External USB Devices : can play stereo audio from external devices: PDA's, Cellular, etc. Bluetooth Support Hands free VPC6600 Series 2-DIN Vehicle PC Hardware Manual A.2... -
Page 14: Front Panel
VGA display. On the right hand side, there is a Power Button to turn On/Off the Car PC. Below the Eject / Mute Button, there is an LED indicator for HDD. It blinks when you are accessing DVD/CD/USB or HDD. VPC6600 Series 2-DIN Vehicle PC Hardware Manual A.2... -
Page 15: Rear Panel
For the best performance and reliable connection, please do use the MultiLock connector for both ends. The following sections list each of the external I/O connectors with detailed function. VPC6600 Series 2-DIN Vehicle PC Hardware Manual A.2... -
Page 16: Connector A
1.5.2 Connector B The VPC6600 series provides 1 USB port on front panel and maximum up to 4 more USB ports for connecting external USB devices with Multi-Lock connector from the rear panel. These USB ports are USB 2.0 compliant. They can also be disabled from the system BIOS setup. -
Page 17: Connector C
VPC6600 can play audio/Video from connected analog devices. 1.5.3.4 Line _ Out _ Center, Subwoofer, RL, RR, FL & FR VPC6600 provides 5.1 Channel audio outputs with this connection. User can follow the diagram to connect related cables VPC6600 Series 2-DIN Vehicle PC Hardware Manual A.2... -
Page 18: Connector D
1.5.4.5 Rear R, Rear L, Front R & Front L A standard 4 channel stereo output which is for a non 5.1 channel car stereo connection. VPC6600 Series 2-DIN Vehicle PC Hardware Manual A.2... -
Page 19: Side View
Side View (Right hand side) (Left hand side) Model View (DVD Model) (Non DVD Model) Dimension View VPC6600 Series 2-DIN Vehicle PC Hardware Manual A.2... -
Page 20: Environment
Shock: Shock (half-sine wave) 400 G (2ms), 200 G (1ms) Storage Temperature: -30°C ~ +85°C Operating Temperature: -20°C ~ +60°C Relative Humidity: 5% ~ 90% ESD Protection: IEC 61000-4-2 LEVEL 4 (ESD) Protections. 8KV Certification: TBD VPC6600 Series 2-DIN Vehicle PC Hardware Manual A.2... -
Page 21: Chapter 2: Installation For External Device
Once the USB devices or SD card is detected, Media Monsuta will check them as one of storage (refer to photo III) of VPC6600. While playing movie/music/photo files, you may select files from those devices via Media Monsuta GUI. (Photo I) (Photo II) USB DISK (Photo III) VPC6600 Series 2-DIN Vehicle PC Hardware Manual A.2... -
Page 22: Audio Output
USB port from the cables), and then install its driver as you would normally install it under Windows environment. Note: The GPS receiver is an optional accessory for VPC6600. Please contact your sales representative to acquire the device if navigation function is required. VPC6600 Series 2-DIN Vehicle PC Hardware Manual A.2... -
Page 23: Parking Brake Control
The result will be seen on the main page of Media Monsuta User Interface. When you short the two wires, you will see some disabled icons on this UI are enabled. (For more information, please refer to Media Monsuta operation manual) VPC6600 Series 2-DIN Vehicle PC Hardware Manual A.2... -
Page 24: Aux Input
2. Connect reversing switch “R” to “REAR TURN" (color: brown and white mixed) (Photo I) Note: If you are testing in lab, you may connect the “REAR TURN" (brown and white mixed) wire to +12V wire (blue and white mixed) VPC6600 Series 2-DIN Vehicle PC Hardware Manual A.2... -
Page 25: Illumination Control
The feature is to prevent the driver distracted when driving in the dark. Note: If you are testing in lab, you may connect “Side Marker” to “SYS +12V 0.5A” to soften the back light of the LCD. VPC6600 Series 2-DIN Vehicle PC Hardware Manual A.2... -
Page 26: Appendix A: Pin Definition For Multilock
RESERVE RESERVE RESERVE RESERVE 2. Connector B Connector B (Multi-20) PIN No# Name PIN No# Name USB0-GND USB1-GND USB0-D- USB1-D- USB0-D+ USB1-D+ USB0-PW USB1-PW USB2-GND USB3-GND USB2-D- USB3-D- USB2-D+ USB3-D+ USB2-PW USB3-PW VPC6600 Series 2-DIN Vehicle PC Hardware Manual A.2... -
Page 27: Connector C
PIN No# Name PIN No# Name BATT+ REMOTE ILLUMINATION REVERSE GEAR / GEARING LIGHT PARKING BREAK REAR R- FRONT L- REAR R+ FRONT L+ FRONT R+ REAR L- FRONT R- REAR L+ VPC6600 Series 2-DIN Vehicle PC Hardware Manual A.2... -
Page 28: Appendix B: Hard Disk Assembly Instruction
Appendix B: Hard Disk Assembly Instruction 1. Unscrew the 3 screws as picture shows 2. Remove the top cover with pointed direction as picture shows VPC6600 Series 2-DIN Vehicle PC Hardware Manual A.2... - Page 29 3. Unscrew the 4 screws and lift up the DVD bracket as picture shows 4. For DVD model: disconnect the DVD cable and flip over the DVD bracket as picture shows For Non DVD model: flip over the DVD bracket as picture shows VPC6600 Series 2-DIN Vehicle PC Hardware Manual A.2...
- Page 30 5. Flip over the HDD to bottom side up, secure the HDD with 4 screws on the HDD holder, connect the HDD cable as picture shows 6. Reconnect the DVD cable and place down the DVD bracket with 4 screws to secure in place as picture shows VPC6600 Series 2-DIN Vehicle PC Hardware Manual A.2...
- Page 31 7. Place the top cover back with pointed direction as picture shows 8. Secure with 3 screws on the top cover as picture shows VPC6600 Series 2-DIN Vehicle PC Hardware Manual A.2...
-
Page 32: Appendix C: Overall Rear I/O Connection Diagram
Appendix C: Overall Rear I/O Connection Diagram VPC6600 Series 2-DIN Vehicle PC Hardware Manual A.2...
