- Page 1 4CH All-Around View System AVS-2704C Manual Version 1.2...
- Page 3 Statement The information of the product in this manual is subject to change without prior notice and does not represent a commitment on the part of vendor, who assumes no liability or responsibility for any errors that may appear in this manual. This manual contains materials protected under International Copyright Laws.
- Page 4 AVS-2704C Panel and Pin Definitions AVM Body appearance: 6 6 6 6 6 6 6 6 1 1 1 1 1 1 1 1 2 2 2 2 2 2 2 2 3 3 3 3 3 3 3 3...
- Page 5 AVS-2704C Accessory (1)An infrared remote control (2)A dedicated video audio composite cable, please connect it to the J3 position defined on the AVM pin 1 1 1 1 1 1 1 1 2 2 2 2 2 2 2 2...
- Page 6 (3)Turn right/ Turn left/ Backward signal control for screen display switch ，please connect it to the J4 position defined on the AVM pin 1 1 1 1 1 1 1 1 2 2 2 2 2 2 2 2 1 1 1 1 1 1 1 1 TX/RX/GND, support touch screen controller 2 2 2 2 2 2 2 2 Turn right/ Turn left/ Backward signal control for screen display switch...
- Page 7 AVS-2704C Quick Start Main screen after powered on: Left side of (Green section) Right side of (Blue section) main main screen: screen : CH1: Represents the (1) Display system time view in front of the car CH2: Represents the (2) Enlarged view of a...
- Page 8 Enter main menu: 1.Record Setting: I. Auto Record : Automatic recording switch (ON / OFF) II. FPS : Settings for the number of pages to record, in NTSC environment ( 30 / 15 / 10 / 7.5 / 6 / 5 / 3 / 2fps ) III.Record Size : Video record size (1/2 / 5 / 10 min)
- Page 9 2. Playback: (The video will pause recording during playback) I. Select the time point to view from the list II. Press the “ENTER” button to start playback III. Functions such as “Playback/Pause/Fast Forward/Fast Rewind/Stop/Switch between Split Screens”, etc., can be controlled through the remote control...
- Page 10 Note: When the SD is without any video data inside, the message will be shown as below:...
- Page 11 3.Time Setting:When the time adjustment is initiated, the video recording will be paused then the system time can be adjusted. (Note: The video will pause recording during time adjustment)
- Page 12 4.Advanced: I. Format : Format SD card (Please note, all your data will be lost after formatting)
- Page 13 Note: The column will be gray and uselessness if the SD do not insert. As graphically demonstrated in the picture below:...
- Page 14 II. Power Off : Automatic shutdown or delayed shutdown ( 1 minute/ 3 minutes/ 5 minutes)
- Page 15 III. Language : Currently three languages are provided: Simplified Chinese / Traditional Chinese / English...
- Page 16 IV. Camera Setting : Detailed adjustments of “brightness/contrast/hue/saturation” for each camera can be done individually...
- Page 17 Entering this setting, long press "FUNC" button on remote control, the modified value can be save to default, as follows: Entering this setting, long press "SEARCH" button on remote control can load user default, as follows:...
- Page 18 V. AVM Display Adjustment : Adjust the front, back, left and right positions of each camera’s display view individually through software functions to save time on manual camera installation and adjustments. It must input the authorized code for video angle modification. The default authorized code is 1111.
- Page 19 Operating method: (1) To adjust the Camera ID please use the remote control to select: FRONT/REAR/ LEFT/RIGHT (2) Zaxis rotation: Zaxis as the center, clockwise or anti-clockwise rotation, Value: +32~-32, default:0 (3) Yaxis rotation: Yaxis as the center, clockwise or anti-clockwise rotation, Value: +32~-32, default:0 (4) Xaxis rotation: Xaxis as the center, clockwise or anti-clockwise rotation, Value:+32~-32, default:0...
- Page 20 Entering this setting, long press "FUNC" button on remote control, the modified value can be save to default. Entering this setting, long press "SEARCH" button on remote control can load user default.
- Page 21 VI.Scale & Move Setting : In order to avoid initial value of different display make screen offset, this option can let user adjust scale & move setting by self. It must input the authorized code for modification. The default authorized code is 1111, the way of change password is same as "AVM Display Adjustment".
- Page 22 VII. System Info : System information, includes model number / firmware version / video format / memory card space...
- Page 23 VIII.Shutdown System: AVM will immediately boot when ACC starts, if do not want to use in driving, you can select this option to shutdown system.
