Digital Video Recorder

ADR-7104

Quick Installation Guide

Version 1.0
Copyright © 2007 2SAN INC.
Release: September 2007

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ADR-7104 and is the answer not in the manual?

Questions and answers

Related Manuals for 2SAN ADR-7104

Summary of Contents for 2SAN ADR-7104

  • Page 1: Digital Video Recorder

    Digital Video Recorder ADR-7104 Quick Installation Guide Version 1.0 Copyright © 2007 2SAN INC. Release: September 2007...
  • Page 2 2SAN is the trademark of 2SAN Inc. Windows is the trademark of Microsoft Corporation. All brands and trademarks are the properties of their respective owners.
  • Page 3 Member nations already established their free of charge recycle systems of WEEE before August 13, 2005. Accordingly, 2SAN has to be responsible for recycling all products exported to Germany. You can return your 2SAN product that needs recycling to a local collector.
  • Page 4 Los paises miembros ya han establecido su sistema de reciclaje gratuito de RAEE antes del 13 de Agosto del 2005. Por este motivo 2SAN es el responsable del reciclaje de todos los productos exportados a Alemania. Usted puede devolver su producto 2SAN a un punto de recogida local cuando desee reciclarlo.

  • Page 5: Table Of Contents

    Table of Contents 1. PRODUCT OVERVIEW ......................6 2. PACKAGE CONTENTS......................6 3. PRODUCT SPECIFICATION ....................6 4. QUICK INSTALLATION ......................7 5. APPEARANCE ......................... 11 6. TIME SETTING ........................14 7. RECORD ...........................15 8. PLAYBACK..........................15...

  • Page 6: Product Overview

    Digital technology for DVR (Digital Video Recorder) represents the better recording quality, control and functionality as well as remote viewing. Unlike PC-based DVR, 2SAN’s embedded DVR enjoys much more benefits that contain NO software at all on the hard disks, but being installed in the flash memory on the board.

  • Page 7: Quick Installation

    4. Quick Installation Installation Steps: Step 1. Install camera Connect cameras to the video BNC inputs marked Video In 1~4. BNC Cable Step 2. Install monitor Connect a monitor to one of the connectors marked CVBS, S-Video or VGA (optional). Step 3.
  • Page 8 Hold the silver shaft, and pull the whole hot-swap tray out of case. Install SATA HDD into the Hot-swap tray, and use screws to tighten it. Insert the hot-swap tray into the case, and push to the end. Follow the direction to get silver shaft & blue tenon geared. After a “click”, DONE.
  • Page 9 Install Internal HDD： Remove the cover and pull the hot-swap HDD tray out. Disconnect the SATA cable & 4-pin HDD power cord. Loosen the screws and take the HDD bracket out. Install the HDD into the lower part of the HDD bracket and tighten it. Make sure the HDD is firmly connected with SATA connector.
  • Page 10 Step 4. Install e.SATA device (optional) 1. Use ACARD e.SATA RAID Tower ANS-9050E as an example. 2. Connect the e.SATA RAID Tower to the DVR with an e.SATA cable. Step 5. Install Power Cord. 1. Connect the power adapter to the connector marked DC-12V. 2.

  • Page 11: Appearance

    5. Appearance Front panel ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Name Function Hot-swap HDD Tray For hot-swap HDD LCD Panel Indicates the system status Setup Used for quick selecting the setup menu Used for changing the settings or for moving the cursor up/down/left/right.
  • Page 12 Rear panel Video In & Loop e.SATA port RS485 & Alarm In / Out Power Fan Audio In & Out Video Input Ethernet Power...
  • Page 13 IR Remote Controller 1. POWER 13. ROTATE Power off. The single channel mode switches according to the ○ specified time on the menu. 2. CHANNEL KEY Press the button to display 14. ESC the single channel. Back to the previous menu. ○...

  • Page 14: Time Setting

    6. Time Setting Step 1. Click SETUP on the MENU. Step 2. Click SYSTEM. Step 3. TIME SETUP. (NOTE - TIME: Year / Month / Hour / Minute / Second; FORMAT: ASIA / EURO / US)

  • Page 15: Record

    7. Record Power on the DVR system to let it start recording automatically. Meanwhile, the REC LED will indicate the recording status. You might want to change the recording mode. Follow the instructions below: Step 1. Click SETUP on the MENU. Step 2.
