Introduction The Orange USB modem is a multi-mode USB modem, working in HSUPA/HSDPA/WCDMA/EDGE/GPRS/ GSM networks. With USB interface connecting to a laptop or a desktop PC, it integrates the functionality of a modem and a mobile phone (SMS), and combines mobile communication with Internet perfectly.
Page 3
Functions SMS service, Data service, Applications management, support microSD card, etc. Network Standards HSUPA/HSDPA/WCDMA/EDGE/GPRS/GSM Transmission speed HSUPA: 5.76Mbps UL (Max) HSPA+: 21.0Mbps DL Storage: -40°C ~ +80°C Temperature Operation:-10°C ~ +55°C Dimension 87.9mm×27.2mm×13.4mm Weight About 26g microSD capability Support up to 32GB microSD card Notes: MicroSD is a trademark of SD Card Association.
Getting to know your device The following figure shows the appearance of the MF192. It is only for your reference. The actual product may be different. 1. Indicator 2. Modem Cap 3. External antenna port 4. MicroSD card slot 5. SIM/USIM card slot...
Hardware Installation 1. Insert the SIM/USIM card into the USB modem To install SIM/USIM card Take down the modem cap, and then the USB connector is visible. Pull the plastic socket above the USB connector out. Notes: Do not pull the socket rudely for the socket is fixed with the modem. Otherwise the socket will get damaged.
Page 6
iii. Insert the SIM/USIM card into the socket. Make sure that metal contact area is facing to the modem. iv. Insert the plastic socket into the modem. You can hear a click when the SIM/USIM card locks in place. To Remove the SIM/USIM card from the USB modem Take down the modem cap.
Page 7
iii. Close the cover of microSD card slot and then you can use the microSD card freely. 3. Connect the USB modem to your PC Plug the USB modem into your computer’s USB port and make sure that it is tightly inserted. ...
Page 8
computer correctly. Follow the system prompts to complete the software installation. Notes: If the system does not launch installation automatically, you can run the installation program in path of My Computer > double click on the .exe file For Mac OS The system will automatically display a CD-ROM icon on the desktop, when you connect the modem to your computer correctly.
Page 9
Click to query your account balance buy data bundle Click to access the list of available data bundle Show the help information and also give you a link to quick tips, visit Orange help website and access the device manual...
Page 10
Installed user interface After installation the window shown below will pop up in your desktop, If it fails to appear double click on the Orange icon installed on your laptop or PC to start the application...
Page 11
Top up Click on the top up icon input the 12 digit card number and click send You will receive a notification indicating the success of the top up To buy data bundles Click on the buy bundles icon ...
Page 12
Ensure that the amount topped up is more or equal to the cost of the data bundle (visit www.Orange. co.ke or call customer care on 121 to know the cost of the bundle) Choose your preferred data bundle ...
You will receive a confirmation sms on successful purchase of the data bundle A failure message will also be send if the operation is unsuccessful Operation can fail if the chosen bundle cost more than the account balance ...
Page 14
Click disconnect once done surfing the net To check your account balance Click on the check balance Icon The account balance will be displayed in less than 5 seconds The message content is as below To know your usage, access phonebook and settings Go to advance option ...
Page 15
Click on the icon to access the advance options Click on statistics, to check usage Click phonebook , to view your contact list Click settings, to check on the network parameters...
Page 16
You will see the screen below and indicates the connection speed, upload, download on daily, monthly and annual...
Advanced options Allows you to check the following settings Security settings Connection settings Network settings and Alert settings Click on any of the tab shown in the screen shot below to confirm the default parameters...
Warning and Notice To the owner • Some electronic devices are susceptible to electromagnetic interference sent by modem if inadequately shielded, such as the electronic system of vehicles. Please consult the manufacturer of the device before using the modem if necessary. •...
Page 19
• Do not touch the inner antenna area if not necessary. Otherwise it will affect your modem’s performance. • Store the modem out of the reach of little children. The modem may cause injury if used as a toy. • Do not touch the metallic parts of the modem so as to avoid a burn, when the modem is working.
Page 20
• No dismantling by non-professionals and only qualified technicians can undertake repair work. • Operating temperature range of -10°C ~ +55°C and humidity range of 5% ~ 95% are recommended. Limited Warranty • This warranty does not apply to defects or errors in the Product caused by: Reasonable abrasion.
Page 21
vii. Any other cause beyond the range of normal usage intended for the Product. End User shall have no right to reject or return the Product, or receive a refund for the Product from Telkom Kenya Ltd under the above-mentioned situations. •...
How to get help You can get help by: • Clicking help on the software • Sending E-mail to bbcustomercare@orange-tkl.co.ke • Visiting http://www.orange.co.ke • Calling customer care on 121 or 020 2222121 from other networks...
