- Page 1 OPERATION MANUAL CS5131P For customer Use: Enter below the Serial NO. which is located on the rear panel of the camera control unit. Retain this information for future reference. Model No. CS5131P Serial No.
- Page 2 Thank you for purchasing the teli CS5131P television color camera featuring compact arid light weight. To take lest advantage arid gain the most service from your camera, read this operation manual carefully and throughly. CAUTION To prevent electric shock, do not use the polarized...
-
Page 3: Table Of Contents
CONTENTS page 1, FEATURES 2, PRECAUTION 3, CONTROLS AND ADJUSTMENTS 3-1 Camera head 3-2 Camera control unit 4, CONNECTIONS 5, SUPPLEMENTAL INFORMATION (1) Color temperature (2) White balance (3) How to get good color (4) Color temperature of various artificial lighting (5) CCD image sensor (6) Smear (7) ELC and AGC... -
Page 4: 1, Features
To prevent electric shocks and fire hazards, do not use any other power source. (2) The CS5131P is designed to be used with PAL color television signals. It cannot be used for playback with a television of a different standard. -
Page 5: 3, Controls And Adjustments
(2) Focus ring Take the focus with the ring to focus for the sharpest picture. * CS5131P camera is fitted with the "C" type lens mounting system using the C mount adapter. This system allows you to use any lenses belonging to the "C" mount group according to your applications. -
Page 6: Camera Control Unit
Camera cable The camera cable can be extended from 2 meter to maximum 30 meters as necessary. 3-2 Camera control unit (front panel) POWER WHITE BALANCE CAMERA (1) “POWER” A power on/off switch. When power is turned on, the pilot lamp on the power switch will light. (2) "AGC"... - Page 7 * "AUTO" (Automatic follow-up system) The purpose of this white balance of "AUTO" is for a TV monitoring system, which installed to shoot a scenery with wide angle. This automatic white balance adjust- ment is performed by the detection of the average picture levels of red(R), green(G), and blue(B) signals picked up from the subject while they are balanced.
- Page 8 while watching the color monitor. For more information on color temperature and white balance, refer to the supplemental information of pages to and 11. * "ELC" (Electronic Light Control) This camera is provided with an automatic sensitivity control which adjusts the shutter speed according to the amount of light entering the lens so that correct exposure is obtained even when illumination of the object changes.
- Page 9 For more information on electronic shutter and ELC (automatic sensitivity control), refer to the supple- mental information of page 12. (2) AGC LEVEL When the input of video signal is rated, the output signal should be adjusted the same level as when AGC is "ON"...
-
Page 10: 4, Connections
4, CONNECTIONS When install the CS5131P camera to your system, you have to connect between equipments. 4-1. Typical connection. - 7 -... - Page 11 4-2 Camera control unit (rear panel) There are thirteen connectors at the rear panel on the camera control unit. Figure Camera control unit rear panel (1) "R OUT","G OUT",”B OUT" (RGB video outputs) R,G and B video signals are output individually from the BNC type connectors.
- Page 12 (3) "Y/C OUT” (S-terminal) Y (lumminance signal) and C (chrominance) are output from the "Y/C OUT" individually. The employment of an S-terminal allows reduction of cross color, dot disturbance, and color blurring that may occur especially during picture editing, compared to the PAL composite video signal.
-
Page 13: 5, Supplemental Information
Correct white balance makes all other colors correct. The CS5131P can perform automatic white balance adjust- ment with just the press of a switch. However, if illumination is insufficient, white balance adjustment cannot be performed. To obtain correct colors, therefore, sufficient illumination is essential. -
Page 14: Color Temperature Of Various
(4) Color temperature of various artificial lighting. Type of illumination Color Temperature Tungsten lamp for home use 2800 K Tungsten lamp for photographic use 3000 K Quartz-halogen lamp Blue lane for photographic use 5000 K Warm white 3500 K Fluorescent lamp White 4500 K Daylight type... -
Page 15: Smear
The spectral transmittance characteristics of each color filter are shown in Figure below. This spectrum offers high color-fidelity reproduced images. The horizontal resolution of 450 TV lines for the luminance signal (Y) is confirmed by a reproduced Retma chart on a television monitor with this complementary mosaic color filter- arrangement. -
Page 16: Lenses
the program AE mechanism housed in the video camera automatically selects the speed of the electronic shutter depending on the lighting. Simultaneously, the amplifier gain in the camera instead of the lens aperture (iris) value is likewise automatically adjusted according to the pre-selected shutter speed to obtain the most appropriate video signal level. -
Page 17: 6, Trouble-Shooting Guide
6, TROUBLE-SHOOTING GUIDE What may initially appear to be trouble is not always a real problem. Make sure first according to the following table before a requesting service. Symptoms Check points Power *Have you connected AC power cord No power correctly? is supplied *Are fuses blown? -
Page 18: 7, Specifications
7. SPECIFICATIONS TV system Image sensor Interline CCD Active pixel 752(H) X 582(V) Active image area 6.4mm(H) X 4.8mm(V) (equivalent to 1/2 inch optical image size) Number of scanning lines 625 lines Scanning system 2 . I interlace Sync. system Internal / External (automatic change over) Scanning frequencies... - Page 19 Horizontal 15.625 kHz± 30ppm Vertical 50 Hz ± 30ppm 1.0 Vpp/75Ω positive polarity Horizontal 15.625 kHz ± 30ppm Vertical 50 Hz -h 30ppm SC phase 4.433619 MHz ± 30ppm (13) Output pulses (TTL level) SYNC negative polarity (14) Gamma correction 0.45 (15) ON / OFF selectable...
-
Page 20: 8, Constitution
F=15 mm, F 2.0 f=24 mm, F 3.6 Lens adapter for C-mount CS5131P can be fitted with C mount lens using this C mount lens adapter. * Camera cable Make choice of the most appropriate cables, according to your system or application. -
Page 21: Camera Head
9 , APPERANCES (1) Camera head 18 -... -
Page 22: Camera Control Unit
(2) Camera control unit 19 -... -
Page 23: 10, Maintenance
10, MAINTENANCE (1) Cleaning Rhould be done only after the battery pack has been removed or other power units have been disconnected. (2) When the cabinet is dusty, clean by gently wiping with a soft cloth. And avoid the use of strong cleaning agents such as benzine or alcohol as they may damage the cabinet.
