CCD B/W camera
Model CS8531
Operation Manual
Model No.
Serial No.
The date of purchase
TOKYO ELECTRONIC INDUSTRY CO.,LTD
CS8531

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CS8531 and is the answer not in the manual?

Questions and answers

Summary of Contents for Teli CS8531

  • Page 1 CCD B/W camera Model CS8531 Operation Manual Please fill in the ①Serial No. which is found on the rear panel of the camera control unit and ②the date of purchase of this equipment below. This information can be helpful when requesting after-sales service.
  • Page 2 Thank you for purchasing our CS8531 B/W CCD camera. This operation manual includes some important information such as how to use this equipment correctly and safely. Please read through this manual carefully. After reading, keep this manual by the side of your equipment for your future reference.
  • Page 3: Important Safety Instructions

    Important Safety Instructions Be sure to use DC12V power supply. This equipment is designed and guaranteed to work from 0°C to 40°C. Do not use this equipment beyond that limit. Do not expose image pickup surface to sunlight or other intense light directly.(The heat of these light may do damages to CCDs[charge-coupled device]) Even when the equipment is not in use, make sure to put lens or lens-cap onto the camera head, so that sensitive image pickup surface is protected from fine dusts,...
  • Page 4: Table Of Contents

    CONTENTS 1. PRODUCT DESCRIPTION ----------------------------------------------------------------------------------------------- 4 2. FEATURES ------------------------------------------------------------------------------------------------------------------------------ 4 3. CONFIGURATION--------------------------------------------------------------------------------------------------------------- 5 4. OPTION ---------------------------------------------------------------------------------------------------------------------------------- 5 5. FUNCTION OF EACH SWITCH ------------------------------------------------------------------------------------- 5 6: CONNECTION --------------------------------------------------------------------------------------------------------------------- 7 7. SPECIFICATIONS ---------------------------------------------------------------------------------------------------------------- 8 8. SUPPLEMENTAL DRAWING, FIGURES ---------------------------------------------------------------------- 10 -1. CAMERA HEAD EXTERNAL VIEW -2.
  • Page 5: Product Description

    (3) All pixel’s data Read Out Unlike other CCDs, which read out all pixel’s data in 2 fields (1/30 sec.), the CCDs of CS8531 read out all pixel’s data in just 1 fields (1/60 sec.). (60Hz interlace, 2 lines output) (4) High vertical resolution As all pixel’s data are read out even in random trigger shutter mode, images with no...
  • Page 6: Configuration

    3. CONFIGURATION -1. CS8531 (1) Camera body Cable-fixed side(Viewed from the rear side) Cable length(- ①CS8531V- ① 01 : 1m V : Rear ②CS8531W- ② 02 : 2m W : Left ③CS8531X- X : Bottom ④CS8531Y- Y : Right(standard) ⑤CS8531Z-...
  • Page 7 Selection with a inner SW Shutter speed (s) Normal 1/100 1/250 1/500 1/1000 1/2000 1/4000 1/8000 ②Under MIX mode: The same as under NOR mode. ③Under R.R mode: The shutter speed is controlled via external VD signals. (Selection available with an inner SW) (Make sure to set this SW OFF to operate the camera in other modes) The shutter speed (exposure time) is determined by the interval of VD signals.
  • Page 8: 6: Connection

    External Sync. Signal is IN/OUT selectable by inner switch inside the camera control unit. (2) HD, VD Input / Output: IN/OUT selectable (With an inner SW, Initial factory-setting: IN) IN: For inputting HD, VD into CS8531. (Initial factory shipped setting) OUT: For outputting HD, VD from CS8531.
  • Page 9: Specifications

    7. SPECIFICATIONS Model CS8531 TV system EIA compatible Image sensor Interline CCD Active pixel 659(H) X 494(V) Unit cell size 7.4 (H) X 7.4 (V)µm Scanning area 4.8(H) X 3.6(V)mm Scanning lines 525 lines Scanning system 1/60 1/60s interlace 1/30...
  • Page 10 Shutter mode Normal/Random trigger switchable Normal shutter High speed shutter 1/8000s~1/60s (8 scale) Flicker-less 1/100s Random trigger shutter 1/10000s~l/4s Restart/reset Trigger Interval (Switching inside) GAIN Fix/Manu/Auto switchable Pre-set gain Manu Manual control (-6dB~+6dB in relation to Fix GAIN) Auto Automatic control (-12dB~+6dB in relation to Fix GAIN) γ...
  • Page 11: Supplemental Drawing, Figures

    8. SUPPLEMENTAL DRAWING, FIGURES -1. Camera head external view CS8531Y SERIES CS8531V SERIES...
  • Page 12: Camera Control Unit External View

    -2. Camera control unit external view...
  • Page 13: Spectrum Response Of Ccd

    -3. Spectrum response of CCD The following graph shows the spectrum response characteristics of CS8531’s CCD. (Lens characteristics are reflected in the graph, while light source characteristics are not reflected.)
  • Page 14: Timing Of In/Out Signal

    -4. Timing of in/out signal (1)1/60s Interlace mode In this mode, odd field’s and even field’s images are output through VIDEO1 and VIDEO2 terminals in 1/60s interlace video format. VIDEO1 OUT VIDEO2 OUT (2) 1/30s Non-interlace video signal is output through VIDEO1 terminal only. VIDEO1 OUT (3) Random trigger shutter mode Under ex-sync operation, the input of VD signal just after the completion of...
  • Page 15 (4) Restart & reset mode To use this mode, set the inner R.R SW ON. To let the camera in other mode, make sure to set it OFF. The shutter speed is determined by the interval of VD signals. In the timing chart below, signals market with * indicates externally inputted signals.
  • Page 16 (5) H rate timing...
