- Page 1 Super ActivO User Manual Europe 2014 Environmentally activated by...
-
Page 2: Table Of Contents
User Manual Table of contents Unpacking…………………………………………………….………………..2 General Information ……………………………………………………….…3 Declaration of Conformity…….…………………………………………..4 Safety Precautions & Warnings……………………………………………...4 The Super ActivO control panel and other indicators……………………..5 Technical Specifications………………………………………………………6 Operation………………………………………………………………………7 Controller settings…………………….…………………………..……...8 Activation, Deactivation and Total Operating Time……….………… …..13 Maintenance and Service……………………………………………….…..14 Troubleshooting………………………………………...…………….………18 Warranty…………………………………………………………….………..19... -
Page 3: General Information
In the first stage the room is enriched with ozone (generated from the air using Ecozone’s multi- patented technology) at a particularly high rate in order to reach homogeneous conditions and a high concentration level within the shortest possible time. -
Page 4: Safety Precautions & Warnings
Prior to removing the grill for maintenance, always disconnect the unit from power. There are no user serviceable parts inside the Super ActivO; removal of back panel by unauthorized personnel will result in voiding the WARRANTY! -
Page 5: Technical Specifications
P a g e 3. Technical Specifications 5.1 Description The Super ActivO system is a portable high-duty and rugged system. It features the most advanced technology in the field of odour- control and air-treatment. The Super ActivO employs Ecozone’s state-of-the-art and patented Singlet Unit which is characterized by relatively high activation rate and enhanced reliability. - Page 6 5.3 Normal Environmental Conditions: Indoor use only Temperature: -5 ºC to 40 ºC Humidity: maximum relative humidity: 95%; ECOZONE Technologies has a policy of continuous product improvement and reserves the right to modify or change this specification at any time without notice.
-
Page 7: Operation
INDICATING THAT THE MACHINE IS NO LONGER IN OPERATION. DO NOT ATTEMPT TO ENTER THE ROOM WHILE MACHINE ‹ Connect power cord to socket on Super ActivO’s rear panel (bottom) and only then connect it to the power source socket. -
Page 8: Controller Settings
P a g e 6.1 Controller settings Œ Press the ‘STOP’ (Red) button to Reset. STOP / RESET The display will present a code followed by the alternating Ready Set Room Size. prompt: • Select ‘Room Size’ by pressing the respective keypad button. Note: You may choose between the following 4 room sizes: Small;... - Page 9 P a g e Set Time The display will now prompt: Ž Short Intermediate Long Select the time cycle by pressing the respective button on keypad. Note: Select length of cycle to correspond Short Cycle-Time (Light odor) Intermediate Cycle-Time (Average odor) Long Cycle-Time (Strong odour) •...
- Page 10 P a g e | 10 Note: Time is indicated on LCD in hours and minutes. h=hours and m=minutes. For example 3 hours and 20 minutes would be indicated so: 3 h 20 m...
- Page 11 P a g e | 11 • green (I) START. Press button for CAUTION Before starting operation verify that the treated area has been vacated of people, animals, plants and items containing natural rubber EXAMPLES OF USE OF ITEMS CONTAINING NATURAL RUBBER Items made of natural rubber (gum) are many and differ in their rubber content;...
- Page 12 Place unit in CENTER of room. When treating smaller rooms you do not need to use air movers in order to circulate ozone since your Super ActivO sends ozone at a high rate of 265 CFM to the ceiling where it spreads out and drifts downward to cover all surfaces.
- Page 13 CAUTION In the event indications do not correspond to the above, leave the room immediately and call for ECOZONE service. • After the operation has ended and before moving the machine elsewhere, be sure to disconnect the power cord from the power socket.
- Page 14 P a g e | 14 Activation, Deactivation and Total Operating Times Generation Time = G Decomposition = D Total Cycle Time = T Inter = Intermediate Default Default Default Short Inter Long Time (minutes) Room Volume Small (<30m Medium (30-60m Large (60-120m 1440 1318...
-
Page 15: Maintenance And Service
| 15 5. Maintenance and Service Maintenance of your Super ActivO is required every 500 hours in order to insure trouble-free performance. The Super ActivO keyboard will display a message indicating that 500 hours of operation have been reached by displaying ‘Needs Service’. - Page 16 P a g e | 16 c. Gently slide filter up and out of its frame (Fig B below) Figure B d. Place the filter under warm tap water and wash out dust. It is ok to use a mild liquid soap if needed to loosen the dust.
- Page 17 P a g e | 17 Step 2 Clean Ozone Generating Cores (Singlets) There are two (2) Singlets to remove and clean. Figure C Singlet Core They are located side by side: Figure D b. Pull out the electrical cable of the Singlet core on the right side of Figure D and disconnect its electrical connector.
- Page 18 P a g e | 18 d. Gently pull out the Singlet in parallel motion from its supporting screws. Be careful not to touch or scratch the glass tubes. e. Clean the Singlet core under warm tap water, especially the gaps between the tubes. You may use a soft brush to remove any accumulated dirt.
-
Page 19: Troubleshooting
Ž CALL ECOZONE service. codes: a. "AL: Presso-Stat" b. "AL: Micro-Switch" Display shows: This notification will appear every 500 hours “Needs Service” of use. Upon notification, please refer to Section 6 above, page 15. Other Call local ECOZONE distributor for technical support. -
Page 20: Warranty
This warranty does not extend to Super ActivO’s that have been subject to misuse, accident, exposure to corrosive substances, tampering or use in a manner not approved by ECOZONE in writing. The Ozone Filtering Unit (shown in the picture on page 18 as #17) is a consumable and is expressly excluded from this warranty. - Page 21 PUNITIVE DAMAGES, EVEN IN THE EVENT OF NOTICE OF THE POSSIBILITY OF SUCH DAMAGES. IN NO EVENT SHALL LIABILITY UNDER THIS WARRANTY EXCEED THE PURCHASE PRICE OF THE SUPER ACTIVO PRODUCT. SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS OR THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO YOU.
