- Page 1 DOOR INTERCOM SYSTEM WITH 2.4” COLOUR LCD Model Number: HE414114 INSTRUCTION MANUAL...
- Page 2 After Sales Support Model Number HE414114 1300 663 907 customercare@winplus.com.au...
- Page 3 You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure. AFTER SALES SUPPORT 1300 663 907 customercare@winplus.com.au YEAR WARRANTY MODEL: HE414114 PRODUCT CODE: 49100 02/2015...
-
Page 4: Table Of Contents
Contents General Safety Instructions................1 Parts List ......................2 Product Features ....................2 Technical Specifications ................2 Product Overview ...................3 Getting Started ....................4 Installing your product ...................5 Accessories ....................7 Using your product ..................7 Troubleshooting Guide...................8 Repairs and Refurbished Goods or Parts Notice.........9... -
Page 5: General Safety Instructions
• Unplug this device during lightning storms or when unused for long periods of time. • Always observe basic security precautions – this device is not a substitute for basic security measures such as locking door and window locks. After Sales Support Model Number HE414114 1300 663 907 customercare@winplus.com.au... -
Page 6: Parts List
• 2.4" TFT LCD Panel • 1/4" CMOS camera • Night vision up to 3m • DC15V adaptor • 10m extension cable • Operating temperature -10 to 40 degrees C After Sales Support Model Number HE414114 1300 663 907 customercare@winplus.com.au... -
Page 7: Product Overview
7. Handset 2. Mounting Accessories 5. Rubberised Seal 3. Power Adaptor 6. Doorbell Unit 8. Colour LCD Screen 11. Unlock Button 9. Display Controls 12. Screen Power Button 10. Volume Control After Sales Support Model Number HE414114 1300 663 907 customercare@winplus.com.au... -
Page 8: Getting Started
Tighten each screw so your connection is firm and will not come loose during everyday use. d. Connect your AC adapter to your handset by plugging it into the back of the handset. TO CAMERA TO AC ADAPTOR After Sales Support Model Number HE414114 1300 663 907 customercare@winplus.com.au... -
Page 9: Installing Your Product
Position your Doorbell with the Doorbell’s camera approximately 145cm from the ground as this will capture most visitor’s height differences. Refer to the diagram: c. Position your Handset approximately 140cm from the ground, depending on the user’s height. After Sales Support Model Number HE414114 1300 663 907 customercare@winplus.com.au... - Page 10 Run wiring along the desired route from your Handset to your Doorbell. The cable may need to be secured depending on location. e. Connect your Handset to your Doorbell using the 4 pin connector on your cable. After Sales Support Model Number HE414114 1300 663 907 customercare@winplus.com.au...
-
Page 11: Accessories
You can adjust the image on the monitor using the buttons on the right hand side. Each of the settings has 7 different options, you simply keep pressing the button until you have the best picture. - Brightness Control - Contrast Control - Colour Control After Sales Support Model Number HE414114 1300 663 907 customercare@winplus.com.au... -
Page 12: Troubleshooting Guide
If you are still having difficulties, check that everything is properly installed as per the installation instructions. After Sales Support Model Number HE414114 1300 663 907 customercare@winplus.com.au... -
Page 13: Repairs And Refurbished Goods Or Parts Notice
Winplus Australasia PO BOX 537 Bayswater Business Centre Bayswater, VIC 3153 Winplus Help Desk 1300 663 907 (Operating Hours: Mon-Fri 08:30AM to 6:00PM) customercare@winplus.com.au www.winplus.com.au AFTER SALES SUPPORT 1300 663 907 customercare@winplus.com.au YEAR WARRANTY MODEL: HE414114 PRODUCT CODE: 49100 02/2015... - Page 14 Notes...
