Machine Types:

   Summary of Contents for Lenovo ThinkServer RD650 70D0

  • Page 1

    Machine Types:...

  • Page 2

    Note: Read Me First First Edition (September 2014) © Copyright Lenovo 2014.

  • Page 3: Table Of Contents

    Contents Safety information ..Chapter 5. Configuring the server . . 55 Chapter 1. General information ..1 Chapter 2. Server setup road map . . . 5 Chapter 3.

  • Page 4

    Chapter 8. Getting information, help, and service ... . . Appendix A. Notices ..Chapter 7. Troubleshooting and diagnostics ... . . Index.

  • Page 5: Safety Information

    Safety information Note: 製品をご使用になる前に、製品に付属の Documentation DVD に収録されているマルチリンガルの「安 全に正しくご使用いただくために」を読んで理解してください。 제품을 사용하기 전에 제품과 함께 제공되는 문서 DVD의 다국어 안전 지침을 주의 깊게 읽어보십시오.

  • Page 6

    在使用本产品之前,请务必先阅读和了解产品附带的文档 DVD 中的多语言安全说明。 使用本產品之前,請務必閱讀並瞭解產品隨附的文件 DVD 上的多國語言版本安全資訊。 Important: Safety, Warranty, and Support Information...

  • Page 7

    Statement 1 DANGER Electrical current from power, telephone, and communication cables is hazardous. To avoid a shock hazard: Do not connect or disconnect any cables or perform installation, maintenance, or reconfiguration of this product during an electrical storm. Connect all power cords to a properly wired and grounded electrical outlet. Ensure that all power cord connectors are securely and completely plugged into receptacles.

  • Page 8

    Statement 3 CAUTION: When laser products (such as CD-ROMs, DVD drives, fiber optic devices, or transmitters) are installed, note the following: • Do not remove the covers. Removing the covers of the laser product could result in exposure to hazardous laser radiation. There are no serviceable parts inside the device. •...

  • Page 9

    Statement 6 CAUTION: If you install a strain-relief bracket option over the end of the power cord that is connected to the device, you must connect the other end of the power cord to a power source that is easily accessible in case it needs to be disconnected.

  • Page 10

    Statement 11 CAUTION: The following label indicates a potential heat hazard. Statement 12 DANGER Overloading a branch circuit is a potential fire hazard and a shock hazard under certain conditions. To avoid these hazards, ensure that your system electrical requirements do not exceed branch current ratings at the installation site.

  • Page 11

    Statement 16 CAUTION: To reduce the risk of electric shock or energy hazards: • This equipment must be installed by trained service personnel in a restricted-access location, as defined by your local electrical code and the latest edition of IEC 60950. •...

  • Page 12

    Statement 20 CAUTION: A lithium ion battery is provided. To avoid possible explosion, do not burn the battery. Replace the battery only with the Lenovo-approved part. Recycle or discard the battery as instructed by local regulations. Products that are not assessed...

  • Page 13

    Grounding requirements...

  • Page 15

    Chapter 1. General information Introduction...

  • Page 16

    Product name Machine type and model (MT-M) Serial number (S/N) Date of purchase Server documentation Printed documents Read Me First Rack Installation Instructions Note:...

  • Page 17

    Documentation DVD Note: Safety, Warranty, and Support Information Lenovo License Agreement User Guide and Hardware Maintenance Manual Rack Installation Instructions ThinkServer System Manager User Guide Note: MegaRAID SAS Software User Guide...

  • Page 19: Chapter 2. Server Setup Road Map

    Chapter 2. Server setup road map Rack Installation Instructions...

  • Page 21: Chapter 3. Product Overview

    Chapter 3. Product overview Server package Features Product Specifications Reference Microprocessor Memory...

  • Page 22

    Power supply Note: System fans Internal drives Drive bay size Drive bay quantity Drive type Note:...

  • Page 23

    Drive bay size Drive bay quantity Drive type Notes: Expansion slots Input/Output (I/O) features Notes:...

  • Page 24

    Video subsystem Ethernet connectivity Reliability, availability, and serviceability Security features Note: Basic system management features...

  • Page 25

    ThinkServer System Manager User Guide Advanced system management features ThinkServer System Manager User Guide...

  • Page 26: Specifications

    Specifications Dimensions Weight Environment Table 1. ASHRAE class A2, class A3, and class A4 specifications ASHRAE class A2 ASHRAE class A3 ASHRAE class A4 Note:...

  • Page 27

    Electrical input Software BIOS and TSM update utilities Lenovo Partner Pack for Microsoft System Center Operations Management...

  • Page 28

    Lenovo ThinkServer Deployment Manager Boot Manager ➙ Launch TDM Platform Update Application Next Browse Flash Note:...

  • Page 29

    Lenovo ThinkServer Diagnostics Lenovo ThinkServer Energy Manager Lenovo ThinkServer Power Planner Lenovo ThinkServer System Manager Lenovo ThinkServer System Manager Premium...

  • Page 30

    Locations Machine type, model, and serial number label Note: Figure 1. Label on server models with 3.5-inch-drive bays...

  • Page 31

    Figure 2. Label on server models with 2.5-inch-drive bays Figure 3. Label on server models with 2.5-inch/3.5-inch mixed drive bays Front view of the server...

  • Page 32

    Note: Front view of server models with 3.5-inch drives Figure 4. Front view of server models with 3.5-inch drives Rack handles Rack Installation Instructions Front panel 3.5-inch-drive bays (0–11)

  • Page 33

    Front view of server models with 2.5-inch drives Figure 5. Front view of server models with 2.5-inch drives Rack handles Rack Installation Instructions Front panel Pull-out information card 2.5-inch-drive bays (0–23)

  • Page 34

    Front view of server models with both 2.5-inch drives and 3.5-inch drives Figure 6. Front view of server models with both 2.5-inch drives and 3.5-inch drives Rack handles Rack Installation Instructions 2.5-inch-drive bays (0–5) 3.5-inch-drive bays (6–14) Front panel Pull-out information card...

  • Page 35

    Front view of server models with a slim optical drive Figure 7. Front view of server models with a slim optical drive Rack handles Rack Installation Instructions Front panel Pull-out information card 2.5-inch-drive bays (0–15) Slim optical drive...

  • Page 36

    Front view of server models with an internal tape drive Figure 8. Front view of server models with an internal tape drive Rack handles Rack Installation Instructions Front panel Pull-out information card Internal tape drive Slim optical drive 2.5-inch-drive bays (0–7)

  • Page 37: Front Panel

    Front panel Figure 9. Front panel of server models with 2.5-inch-drive bays Figure 10. Front panel of server models with 3.5-inch-drive bays Figure 11. Front panel of server models with 2.5-inch/3.5-inch mixed drive bays Network status LED Description Status Color...

  • Page 38

    System health LED Description Action Status Color Note: Power button with power status LED Status Color Description...

  • Page 39

    System ID button with ID LED Description Status Color DisplayPort connector Front USB 2.0 connectors (2) Rear view of the server 9 10 Figure 12. Rear view of the server...

  • Page 40

    Power supply 2 (available on some models) Power supply 1 3 4 7 Slot Physical link width Negotiable link width Supported card length and height Physical link width Negotiable link width Slot Supported card length and height 8 9 10 Slot Physical link width Negotiable link width...

  • Page 41

    Note: Slot Physical link width Negotiable link width Supported card length and height AnyFabric slot DisplayPort connector Serial connector USB 3.0 connectors (2) 2.5-inch-drive bays (2)

  • Page 42: Server Components

    Ethernet connector for system management (RJ-45) Figure 13. Ethernet status LEDs Ethernet status LED Description Color Status System ID LED Status Color Description Server components...

  • Page 43

    Note: Figure 14. Components of server models with an internal tape drive and a slim optical drive...

  • Page 44

    Notes: FRU description Self-service CRU Optional-service CRU...

  • Page 45

    FRU description Self-service CRU Optional-service CRU AnyRAID adapter, RAID card, and pass-through board Note: AnyRAID adapters (supported type varies by server model):...

  • Page 46

    RAID card: Pass-through board: Note: Lenovo ThinkServer RAID 510i AnyRAID Adapter Figure 15. Lenovo ThinkServer RAID 510i AnyRAID Adapter PCIE 0 connector PCIE 1 connector RAID upgrade key connector...

  • Page 47

    Lenovo ThinkServer RAID 720i AnyRAID Adapter Figure 16. ThinkServer RAID 720i AnyRAID Adapter ThinkServer RAID Super Capacitor Module connector PCIE 0 connector PCIE 1 connector...

  • Page 48

    ThinkServer RAID 720ix AnyRAID Adapter Figure 17. ThinkServer RAID 720ix AnyRAID Adapter SATA connector ThinkServer RAID Super Capacitor Module connector PCIE 0 connector PCIE 1 connector...

  • Page 49

    Lenovo ThinkServer 9286 RAID Adapter Figure 18. Lenovo ThinkServer 9286 RAID Adapter ThinkServer RAID Super Capacitor Module connector SAS connector...

  • Page 50

    Lenovo ThinkServer RAID 110i pass-through board Figure 19. Lenovo ThinkServer RAID 110i pass-through board SATA 0–3 connector SATA 4–7 connector Hot-swap-drive backplane...

  • Page 51

    Drive bay size Drive bay quantity Backplane quantity Drive type Drive bay size Drive bay quantity Backplane quantity Drive type...

  • Page 52

    Backplane for up to twelve 3.5-inch drives Figure 20. Front view of the backplane for up to twelve 3.5-inch drives Figure 21. Rear view of the backplane for up to twelve 3.5-inch drives Slot 0–slot 11 10-pin power connector 0 10-pin power connector 1 AnyRAID adapter slot 0 AnyRAID adapter slot 1...

  • Page 53

    Backplane for up to nine 3.5-inch drives Figure 22. Front view of the backplane for up to nine 3.5-inch drives Figure 23. Rear view of the backplane for up to nine 3.5-inch drives Slot 0–slot 8 AnyRAID adapter slot 4 AnyRAID adapter slot 5 10-pin power connector 0 10-pin power connector 1...

  • Page 54

    Backplane for up to sixteen 2.5-inch drives 0 1 2 3 4 5 6 7 10 11 13 14 Figure 24. Front view of the backplane for up to sixteen 2.5-inch drives Figure 25. Rear view of the backplane for up to sixteen 2.5-inch drives Slot 0–slot 15 10-pin power connector 0 AnyRAID adapter slot 0...

  • Page 55

    Backplane for up to eight 2.5-inch drives 0 1 2 3 4 5 6 7 Figure 26. Front view of the backplane for up to eight 2.5-inch drives Figure 27. Rear view of the backplane for up to eight 2.5-inch drives Slot 0–slot 7 10-pin power connector 0 AnyRAID adapter slot 0...

  • Page 56

    Backplane for up to six 2.5-inch drives 0 1 2 3 Figure 28. Front view of the backplane for up to six 2.5-inch drives Figure 29. Rear view of the backplane for up to six 2.5-inch drives Slot 0–slot 5 AnyRAID adapter slot 1 AnyRAID adapter slot 0...

  • Page 57: System Board Components

    Rear backplane for up to two 2.5-inch drives Figure 30. Front view of the rear backplane for up to two 2.5-inch drives Figure 31. Rear view of the rear backplane for up to two 2.5-inch drives Slot 0 Slot 1 Drive sideband signals connector Drive connector 0 Drive connector 1...

  • Page 58

    1 2 3 4 Figure 32. System board components SATA connector 1 (ports 4-7) AnyRAID connector 0-1 SATA connector 0 (ports 0-3)

  • Page 59

    Front panel connector Coin-cell battery SATA connector (optical drive) AnyFabric connector RAID upgrade key connector SD module connector Riser card assembly 1 slot PCIe slot 4 PCIe slot 7 PCIe slot 8 TPM connector TSM Premium connector Rear-backplane signal connector Riser card assembly 2 slot...

  • Page 60

    Rear-backplane power connector Front-backplane power connector Intrusion switch connector Power-distribution-board connector 23 25 27 29 31 33 System fan connector 24 28 30 34 Memory slots Microprocessor 2 socket Microprocessor 1 socket...

  • Page 61

    System board jumpers Figure 33. System board jumpers Attention: BIOS default settings jumper...

  • Page 62

    Clear password jumper BIOS recovery jumper Jumper cap storage...

  • Page 63

    System fan fault LEDs Figure 34. System fan fault LEDs Figure 35. Viewing the system fan fault LEDs from the top of the system fans...

  • Page 64

    Hot-swap-drive status LEDs Figure 36. Hot-swap-drive status LEDs Drive activity LED Drive status LED Description...

  • Page 65: Connecting Cables

    Power supply status LEDs Figure 37. Power supply status LEDs Status Description Action Connecting cables...

  • Page 67: Turning On The Server

    Chapter 4. Turning on and turning off the server Turning on the server Turning off the server CAUTION: The power control button on the device and the power button on the power supply do not turn off the electrical current supplied to the device. The device also might have more than one power cord.

  • Page 69: Chapter 5. Configuring The Server

    Chapter 5. Configuring the server Using the Setup Utility program Starting the Setup Utility program Viewing information in the Setup Utility program Setup Utility program interface Notes:...

  • Page 70

    System Information menu System Information System Information Advanced Settings menu Advanced Settings Advanced Settings Notes: Enabled Disabled Advanced Settings Processor Settings Memory Settings Advanced Power Settings PCI/PCIE Settings SATA Settings USB Settings Serial Settings Wakeup Settings...

  • Page 71

    Miscellaneous Settings System Security menu System Security Notes: Enabled Disabled System Security Administrator Password User Password Secure Boot TPM/TCM TSM Settings menu TSM Settings TSM Settings TSM Network Settings User Account Settings Boot Manager menu Boot Manager Boot Sequence Boot Manager Save &...

  • Page 72: Setting The System Date And Time, Using Passwords

    Save & Exit Save Changes and Reset Discard Changes and Exit Load Optimized Defaults Save as User Defaults Restore User Defaults Pure UEFI OS Optimized Defaults Setting the system date and time System Information System Date System Time Using passwords Setup Utility program password types Administrator password User password...

  • Page 73: Selecting A Startup Device

    Setting, changing, or deleting a password System Security Administrator Password User Password Note: Selecting a startup device Note: Note:...

  • Page 74

    Boot Sequence Boot Manager Boot Option #1 Boot Option #5 Configuring the TPM function TPM Settings ➙ TPM Support System Security TPM Support Enabled TPM Support Enabled TPM State TPM State Enabled Setting an Ethernet connector for system management TSM Settings TSM Network Settings ➙...

  • Page 75

    Updating or recovering the BIOS Updating (flashing) the BIOS Notes: Recovering from a BIOS update failure Note: Using the automatic recovery feature...

  • Page 76: Configuring Raid

    Using the BIOS recovery jumper Note: Configuring RAID About RAID...

  • Page 77

    RAID 0 RAID 1 RAID 5 RAID 6 RAID 10...

  • Page 78

    RAID 50 Note: RAID 60 MegaRAID SAS Software User Guide Configuring RAID using the Lenovo ThinkServer Deployment Manager program Configuring the advanced SATA or SAS hardware RAID Note: Boot Manager ➙ Adapters and UEFI Drivers...

  • Page 79: Updating The Firmware

    MegaRAID SAS Software User Guide Updating the firmware...

  • Page 81: Chapter 6. Replacing Hardware

    Chapter 6. Replacing hardware Guidelines Precautions...

  • Page 82

    Handling static-sensitive devices Attention: System reliability guidelines...

  • Page 83

    Working inside the server with the power on Attention: Removing or extending the server from the rack cabinet Rack Installation Instructions Rack Installation Instructions Removing the server cover Attention: Note:...

  • Page 84

    Figure 38. Unscrewing the cover lock Note: Figure 39. Removing the server cover Attention:...

  • Page 85

    Installing, removing, or replacing hardware Notes: Attention: Removing and reinstalling the rack handles Attention: Note: Figure 40. Removing the rack handles...

  • Page 86

    Figure 41. Installing the rack handles Removing and reinstalling the cooling shroud Attention:...

  • Page 87

    Figure 42. Removing the cooling shroud...

  • Page 88

    Note: Figure 43. Installing the cooling shroud Attention: What to do next: Installing or replacing a system fan Attention:...

  • Page 89

    CAUTION: Hazardous moving parts. Keep fingers and other body parts away. Note: Note: Figure 44. Removing the dummy fan...

  • Page 90

    Figure 45. Removing the system fan Figure 46. Installing the system fan What to do next:...

  • Page 91

    Removing and reinstalling the system fan cage Attention: Note: Figure 47. Removing the system fan cage...

  • Page 92

    Figure 48. Installing the system fan cage Figure 49. Securing the system fan cage What to do next: Installing or removing a memory module...

  • Page 93

    Note: Memory module installation rules...

  • Page 94

    CPU1 DIMMC1 CPU1 DIMMC2 CPU1 DIMMC3 CPU1 DIMMD1 CPU1 DIMMD2 CPU1 DIMMD3 CPU2 DIMMC1 CPU1 DIMMB3 CPU2 DIMMC2 CPU1 DIMMB2 CPU2 DIMMC3 CPU1 DIMMB1 CPU2 DIMMD1 CPU1 DIMMA3 CPU2 DIMMD2 CPU1 DIMMA2 CPU2 DIMMD3 CPU1 DIMMA1 CPU2 DIMMB3 CPU2 DIMMB2 CPU2 DIMMB1 CPU2 DIMMA3 CPU2 DIMMA2...

  • Page 95

    Table 3. Memory module installation rules for servers with two microprocessors (continued) CPU1 DIMM CPU2 DIMM A1 A2 A3 B1 B2 B3 C1 C2 C3 D1 D2 D3 A1 A2 A3 B1 B2 B3 C1 C2 C3 D1 D2 D3 Memory module installation order in independent mode Notes: Table 4.

  • Page 96

    Table 6. Memory module installation order in mirroring mode for servers with one microprocessor CPU1 DIMM Table 7. Memory module installation order in mirroring mode for servers with two microprocessors CPU1 DIMM CPU2 DIMM Memory module installation order in sparing mode Note: Table 8.

  • Page 97: Installing A Memory Module

    Memory module installation order in lockstep mode Notes: Table 10. Memory module installation order in lockstep mode for servers with one microprocessor CPU1 DIMM Table 11. Memory module installation order in lockstep mode for servers with two microprocessors CPU1 DIMM CPU2 DIMM Installing a memory module Attention:...

  • Page 98

    Figure 51. Opening the retaining clips of the memory slot Note: Note: Figure 52. Installing a memory module What to do next:...

  • Page 99: Replacing The Riser Card

    Removing a memory module Attention: Note: Figure 53. Removing a memory module What to do next: Replacing the riser card Attention:...

  • Page 100

    Note: Figure 54. Removing the riser card assembly from the chassis...

  • Page 101

    Figure 55. Removing the riser card Figure 56. Installing the riser card...

  • Page 102

    Figure 57. Installing the screws to secure the riser card...

  • Page 103

    Note: Figure 58. Installing the riser card assembly...

  • Page 104

    Figure 59. Tightening the screw What to do next: Installing or removing a PCI Express card: Ethernet card, RAID card, and other supported types of PCI Express cards Note: Installing a PCIe card...

  • Page 105

    Adjusting the card-retaining bracket Attention: Note: Figure 60. Removing the screws to adjust the card-retaining bracket...

  • Page 106

    Figure 61. Securing the card-retaining bracket for 176.4 mm (6.94 inches) PCIe cards Figure 62. Securing the card-retaining bracket for PCIe cards between 185 mm (7.28 inches) and 220 mm (8.66 inches)

  • Page 107

    Installing a PCIe card on the riser card assembly Attention: Notes: Note: Figure 63. Removing the PCIe slot bracket...

  • Page 108

    Note: Figure 64. Installing the PCIe card Figure 65. Pivoting the card latch to the closed position...

  • Page 109

    What to do next: Installing a PCIe card on the system board Attention: Notes: Figure 66. Opening the PCIe card latch Note:...

  • Page 110

    Figure 67. Removing the PCIe slot bracket Note: Note: Figure 68. Removing the full-height bracket...

  • Page 111

    Figure 69. Installing the low-profile bracket Figure 70. Installing the PCIe card...

  • Page 112

    Figure 71. Pivoting the card latch to the closed position What to do next: Removing a PCIe card Removing a PCIe card from the riser card assembly Attention: Notes:...

  • Page 113

    Figure 72. Pivoting the card latch to the open position Note: Figure 73. Removing the PCIe card...

  • Page 114

    What to do next: Removing a PCIe card from the system board Attention: Notes: Note: Figure 74. Removing the PCIe card...

  • Page 115

    What to do next: Replacing the AnyRAID adapter or the pass-through board Attention: Notes: Attention:...

  • Page 116

    Note: Figure 75. Removing the AnyRAID adapter or the pass-through board Note: Figure 76. Installing the AnyRAID adapter or the pass-through board...

  • Page 117

    Figure 77. Tightening the screws What to do next: Installing or removing the flash module Installing the flash module Attention: Notes:...

  • Page 118

    Note: Figure 78. Installing the flash module What to do next: Removing the flash module Attention: Note:...

  • Page 119

    Note: Figure 79. Removing the flash module What to do next: Installing or removing the Lenovo ThinkServer RAID 110i upgrade key Installing the RAID 110i key Attention: Note:...

  • Page 120

    Attention: Note: Figure 80. Installing the RAID 110i key What to do next: Removing the RAID 110i key Attention: Notes:...

  • Page 121

    Attention: Note: Figure 81. Removing the RAID 110i key What to do next: Installing or removing the Lenovo ThinkServer RAID 510i upgrade key...

  • Page 122

    Installing the RAID 510i key Attention: Note: Attention: Note: Note: Figure 82. Installing the RAID 510i key What to do next:...

  • Page 123

    MegaRAID SAS Software User Guide Removing the RAID 510i key Attention: Notes: Attention: Note: Figure 83. Removing the RAID 510i key What to do next:...

  • Page 124

    MegaRAID SAS Software User Guide Installing or removing the secure digital module Installing the SD module Attention: Notes: Note:...

  • Page 125

    Figure 84. Installing the SD module What to do next: Removing the SD module Attention: Notes:...

  • Page 126

    Note: Figure 85. Removing the SD module What to do next: Installing or removing the ThinkServer System Manager Premium Installing the TSM Premium Attention: Notes:...

  • Page 127

    Note: Figure 86. Installing the TSM Premium What to do next: ThinkServer System Manager User Guide Removing the TSM Premium Attention: Notes:...

  • Page 128

    Figure 87. Removing the TSM Premium What to do next: Installing or removing the ThinkServer Trusted Platform Module Installing the TPM Attention: Notes:...

  • Page 129

    Note: Figure 88. Installing the TPM What to do next: Removing the TPM Attention: Notes:...

  • Page 130

    Note: Figure 89. Removing the TPM What to do next: Installing or removing the AnyFabric adapter Installing the AnyFabric adapter Attention: Notes:...

  • Page 131

    Figure 90. Removing the protective shield for the AnyFabric adapter bay Note:...

  • Page 132

    Figure 91. Installing the AnyFabric adapter What to do next: Removing the AnyFabric adapter Attention: Note:...

  • Page 133

    Note: Figure 92. Removing the AnyFabric adapter What to do next: Installing or replacing a hot-swap redundant power supply Attention: CAUTION: Hazardous moving parts. Keep fingers and other body parts away. CAUTION: Never remove the cover on a power supply or any part that has the following label attached.

  • Page 134

    Hazardous voltage, current, and energy levels are present inside any component that has this label attached. There are no serviceable parts inside these components. If you suspect a problem with one of these parts, contact a service technician. Notes: Figure 93. Removing the protective shield for the power supply bay Note:...

  • Page 135

    Figure 94. Removing a power supply Figure 95. Installing a power supply What to do next: Installing or replacing a heat sink Attention:...

  • Page 136

    CAUTION: The heat sink might be very hot. Turn off the server and wait several minutes to let the server cool before removing the server cover. Note: Note: Figure 96. Removing the screws that secure the heat sink...

  • Page 137

    Notes: Figure 97. Installing the screws to secure the heat sink What to do next: Installing or replacing the microprocessor...

  • Page 138

    Installing the second microprocessor Attention: CAUTION: Turn off the server and wait several minutes to let the server cool before removing the server cover. Notes:...

  • Page 139

    Note: Figure 98. Opening the handles of the microprocessor retainer Note: Figure 99. Opening the microprocessor retainer...

  • Page 140

    Figure 100. Do not touch the pins Note: Figure 101. Installing the microprocessor...

  • Page 141

    Note: Figure 102. Removing the microprocessor socket cover Note: Figure 103. Securing the microprocessor in the socket...

  • Page 142

    What to do next: Replacing the microprocessor Attention: CAUTION: The heat sink and microprocessor might be very hot. Turn off the server and wait several minutes to let the server cool before removing the server cover. Notes:...

  • Page 143

    Note: Figure 104. Opening the handles of the microprocessor retainer Figure 105. Opening the microprocessor retainer...

  • Page 144

    Notes: Figure 106. Removing the microprocessor Figure 107. Do not touch the pins...

  • Page 145

    Note: Figure 108. Installing the microprocessor Note: Figure 109. Securing the microprocessor in the socket...

  • Page 146

    Notes: Figure 110. Applying the thermal grease to the top of the microprocessor What to do next: Installing or removing the ThinkServer RAID Super Capacitor Module Attention: Installing the ThinkServer RAID Super Capacitor Module Attention: Notes:...

  • Page 147

    Figure 111. Installing the ThinkServer RAID Super Capacitor Module onto the cooling shroud What to do next: Removing the ThinkServer RAID Super Capacitor Module Attention: Note:...

  • Page 148

    Figure 112. Removing the ThinkServer RAID Super Capacitor Module from the cooling shroud What to do next: Installing or replacing a hot-swap drive Attention: Attention: Notes:...

  • Page 149

    Figure 113. Opening the handle of a dummy tray...

  • Page 150

    Figure 114. Opening the handle of a drive Figure 115. Removing the drive...

  • Page 151

    Figure 116. Removing the dummy tray Note: Figure 117. Installing the drive...

  • Page 152

    What to do next: Installing a 2.5-inch solid-state drive into a 3.5-inch-drive bay Attention: Note: Figure 118. Opening the handle of the dummy tray Figure 119. Removing the dummy tray...

  • Page 153

    Note: Figure 120. Positioning the 2.5-inch solid-state drive into the drive adapter Figure 121. Installing the screws to secure the solid-state drive to the drive adapter...

  • Page 154

    Figure 122. Installing the screws to secure the drive adapter and the solid-state drive to the bracket Figure 123. Installing the bracket with the solid-state drive What to do next:...

  • Page 155

    Installing or removing the rear backplane/cage assembly Installing the rear backplane/cage assembly Attention: Notes: Figure 124. Removing the protective shield for the rear backplane/cage assembly bay...

  • Page 156

    Figure 125. Installing the rear backplane/cage assembly What to do next: Removing the rear backplane/cage assembly Attention: Note:...

  • Page 157

    Figure 126. Removing the rear backplane/cage assembly What to do next: Replacing the hot-swap-drive backplane Note: Replacing the front backplane Attention: Note:...

  • Page 158

    Figure 127. Releasing the front backplane...

  • Page 159

    Figure 128. Removing the front backplane Note: Figure 129. Installing the front backplane...

  • Page 160

    What to do next: Replacing the front backplane for up to six 2.5-inch drives Attention: Note: Figure 130. Removing the front drive cage...

  • Page 161

    Note: Figure 131. Removing the interposer cards Figure 132. Removing the backplane Note:...

  • Page 162

    Figure 133. Installing the new backplane to the front drive cage Figure 134. Installing the screws to secure the new backplane...

  • Page 163

    Figure 135. Installing the interposer cards Figure 136. Installing the screws to secure the interposer cards...

  • Page 164

    Figure 137. Installing the front drive cage Figure 138. Installing the screws to secure the front drive cage What to do next: Replacing the rear backplane Attention:...

  • Page 165

    Figure 139. Removing the rear backplane Note:...

  • Page 166

    Figure 140. Installing the rear backplane What to do next: Replacing the front panel board Notes: Replacing the front panel board for server models with 2.5-inch-drive bays and 2.5-inch/3.5-inch mixed drive bays Attention:...

  • Page 167

    Figure 141. Removing the front panel board Note:...

  • Page 168

    Figure 142. Installing the front panel board What to do next: Replacing the front panel board for server models with 3.5-inch-drive bays Attention:...

  • Page 169

    Figure 143. Releasing the front panel board from the secured position Figure 144. Removing the front panel board Note:...

  • Page 170

    Figure 145. Installing the front panel board Figure 146. Securing the front panel board What to do next: Installing or removing the intrusion switch...

  • Page 171

    Installing the intrusion switch Attention: Note: Figure 147. Assembling the intrusion switch with the bracket...

  • Page 172

    Figure 148. Installing the intrusion switch What to do next: Removing the intrusion switch Attention: Notes:...

  • Page 173

    Figure 149. Removing the intrusion switch What to do next: Installing or replacing the optical drive Note: Attention: CAUTION: When laser products (such as CD-ROMs, DVD drives, fiber optic devices, or transmitters) are installed, note the following:...

  • Page 174

    • Do not remove the covers. Removing the covers of the laser product could result in exposure to hazardous laser radiation. There are no serviceable parts inside the device. • Use of controls or adjustments or performance of procedures other than those specified herein might result in hazardous radiation exposure.

  • Page 175

    Figure 151. Removing the three screws Figure 152. Removing the drive partition What to do next: Installing the optical drive Attention:...

  • Page 176

    Notes: Figure 153. Removing the drive partitions Figure 154. Installing the optical drive cage or the tape drive cage into the chassis...

  • Page 177

    Figure 155. Installing the screws to secure the optical drive cage or the tape drive cage Note: Figure 156. Removing the optical drive dummy...

  • Page 178

    Figure 157. Installing the optical drive Figure 158. Connecting the connector on one end of the cable to the rear of the optical drive What to do next:...

  • Page 179

    Replacing the optical drive Attention: Notes: Note: Figure 159. Removing the optical drive...

  • Page 180

    Figure 160. Installing the optical drive Figure 161. Connecting the connector to the rear of the optical drive What to do next: Installing or replacing the tape drive Note:...

  • Page 181

    Attention: Installing the tape drive Attention: Notes: Figure 162. Removing the drive partitions...

  • Page 182

    Figure 163. Installing the tape drive into the tape drive bay Figure 164. Installing the screws to secure the tape drive to the tape drive cage...

  • Page 183

    Figure 165. Installing the tape drive cage with the tape drive into the chassis Figure 166. Installing five screws to secure the tape drive cage to the chassis...

  • Page 184

    Figure 167. Connecting the connector on one end of the cable to the rear of the tape drive What to do next: Replacing the tape drive Attention: Notes:...

  • Page 185

    Figure 168. Removing the tape drive cage...

  • Page 186

    Figure 169. Removing the tape drive What to do next: Replacing the coin-cell battery Attention:...

  • Page 187

    DANGER Danger of explosion if battery is incorrectly replaced. When replacing the lithium coin cell battery, use only the same or an equivalent type that is recommended by the manufacturer. The battery contains lithium and can explode if not properly used, handled, or disposed of.

  • Page 188

    Figure 170. Removing the coin-cell battery Figure 171. Installing the coin-cell battery What to do next: For service technician only: replacing the system board Attention: CAUTION: Hazardous moving parts. Keep fingers and other body parts away.

  • Page 189

    CAUTION: The heat sinks and microprocessors might be very hot. Turn off the server and wait several minutes to let the server cool before removing the server cover. Note:...

  • Page 190

    Note: Figure 172. Removing the system board...

  • Page 191

    Figure 173. Installing the system board Note: Notes: Figure 174. Applying the thermal grease to the top of the microprocessor...

  • Page 192

    Note: Figure 175. Securing the microprocessor retainer Figure 176. Installing the microprocessor socket cover...

  • Page 193

    What to do next: For service technician only: replacing the power distribution board Attention: CAUTION: Hazardous moving parts. Keep fingers and other body parts away. CAUTION: Never remove the cover on a power supply or any part that has the following label attached. Hazardous voltage, current, and energy levels are present inside any component that has this label attached.

  • Page 194

    Notes: Figure 177. Disengaging the system board from the power distribution board...

  • Page 195

    Figure 178. Removing the power distribution board Figure 179. Installing the power distribution board...

  • Page 196

    Note: Figure 180. Installing the screw to secure the power distribution board Note: Figure 181. Connecting the system board to the new power distribution board What to do next:...

  • Page 197

    Completing the parts replacement Reinstalling the server cover and reconnecting cables Attention: Attention: Note:...

  • Page 198

    Figure 182. Cable routing...

  • Page 199

    Figure 183. Installing the server cover Figure 184. Closing the server cover completely Attention:...

  • Page 200

    Note: Updating the server configuration...

  • Page 201

    Chapter 7. Troubleshooting and diagnostics Troubleshooting procedure Viewing the status and diagnostic LEDs...

  • Page 202

    Viewing the system event log ThinkServer System Manager User Guide Basic troubleshooting tables Lenovo ThinkServer Deployment Manager program problems Note: Symptom Action Optical drive problems Notes:...

  • Page 203

    Symptom Action Storage drive problems Notes:...

  • Page 204

    Action Symptom Memory module problems Notes:...

  • Page 205

    Symptom Action Keyboard, mouse, and USB device problems Symptom Action...

  • Page 206

    Symptom Action...

  • Page 207

    Chapter 8. Getting information, help, and service Information resources Using the documentation ThinkServer Web site Lenovo Support Web site...

  • Page 208: Help And Service, Calling For Service

    Help and service Before you call Calling for service Problem determination Hardware repair Engineering Change management...

  • Page 209

    Safety, Warranty, and Support Information Using other services Warranty Purchasing additional services...

  • Page 211

    Appendix A. Notices Lenovo (United States), Inc. 1009 Think Place - Building One Morrisville, NC 27560 U.S.A. Attention: Lenovo Director of Licensing...

  • Page 212

    Trademarks Important notes Polyvinyl Chloride (PVC) cable and cord notice WARNING: Wash hands after handling Recycling information...

  • Page 213

    Battery return program Battery recycling information for the United States and Canada Battery recycling information for the European Union Notice: Requirement for batteries containing perchlorate...

  • Page 214: Recycling Information For Brazil

    Recycling information for Brazil Declarações de Reciclagem no Brasil Descarte de um Produto Lenovo Fora de Uso Particulate contamination Attention: Table 12. Limits for particulates and gases Contaminant Limits Method of Testing General Ventilation Air-Cleaning Devices for Removal Efficiency by Particle...

  • Page 215

    Important WEEE information Restriction of Hazardous Substances Directive (RoHS) European Union RoHS German Ordinance for Work gloss statement Export classification notice...

  • Page 216: Electronic Emission Notices

    Electronic emission notices Federal Communications Commission (FCC) Statement Industry Canada Compliance Statement United Kingdom telecommunications safety requirement European Union - Compliance to the Electromagnetic Compatibility Directive Warning:...

  • Page 217

    German Class A compliance statement Deutschsprachiger EU Hinweis: Hinweis für Geräte der Klasse A EU-Richtlinie zur Elektromagnetischen Verträglichkeit Deutschland: Einhaltung des Gesetzes über die elektromagnetische Verträglichkeit von Betriebsmittein Zulassungsbescheinigung laut dem Deutschen Gesetz über die elektromagnetische Verträglichkeit von Betriebsmitteln, EMVG vom 20. Juli 2007 (früher Gesetz über die elektromagnetische Verträglichkeit von Geräten), bzw.

  • Page 218

    ENERGY STAR model information...

  • Page 219

    Index...

Comments to this Manuals

Symbols: 0
Latest comments:
