Technical specifications Pro-Ject Phono Box II
THD, MM / MC
Gain, MM / MC
Output voltage typically, MM / MC
Input impedance, MM / MC
Noise floor, MM / MC
RIAA-equalisation curve accuracy
Power consumption
Outboard power supply
Dimensions (W x H x D)
Weight without power supply
Potential incorrect use and fault conditions
No signal on one or both channels:
No connection between player and phono amplifier ore amplifier. This could be due to a faulty plug,
broken wire or solder joint or simply loose plug/socket connection.
Strong hum:
No earth connection from cartridge or arm or arm cable to phono amplifier, or earth loop.
Output too quiet or too loud, or distorted:
MM / MC mode incorrectly set - input overloading or insufficiently amplified.
Service
Should you encounter a problem which you are not able to alleviate or identify despite the above information,
please contact your dealer for further advice. Only when the problem cannot be resolved there should the
unit be sent to the responsible distributor in your country.
Warranty
The manufacturer accepts no responsibility for damage caused by not adhering to these instructions
for use. Modification or change to any part of the product by unauthorized persons release the
manufacturer from any liability over and above the lawful rights of the customer.
PRO-JECT is a Registered Trademark of H. Lichtenegger.
This guide was produced by: Audio Trade GmbH
Copyright © 2005. All rights reserved.
< 0,01 / < 0,05%
40dB / 60dB
300mV at 1kHz - 3mV (MM Input) / 0,3mV (MC input)
47kohms/120pF / 100ohms/120pF
86dB / 68dB (94dB / 75dB - A weighted)
Max. 0,5dB/20Hz - 20kHz
16V/30mA AC
16V/200mA AC, suitable for your country's mains supply
103 x 38 x 115mm
570g
The information was correct at the time of going to
press. The manufacturer reserves the right to make
changes to the technical specification without prior
notice as deemed necessary to uphold the ongoing
process of technical development.
© Audio Trade GmbH · Pro-Ject Phono Box II · Revision 6.3.06/1.5.06
