WarninG SYSteMS

C. Lamp Failure System
The audible alarm and indicator lights on the systems continuously monitor a lamp
operation. If the lamp does not start at any time, the indicator red light will glow and
audible alarm will sound. This alarm indicated the UV lamp is no longer operating and
must be corrected. Please refer to Troubleshooting Guide for corrective procedures.
Ultraviolet Monitoring System
The ultraviolet system features a complete warning system for continuous water
protection by constantly sensing the UV light operation. The system features a single
LED indicator light, which will operate two distinct colors, Green and red. When the
UV output level changes, the warning system will operate in the following manner:
Green -
red -
THE BEST WAY TO CHECK UV OPERATION IS TO HAVE THE WATER TESTED FOR BACTERIA
BY A RECOGNIZED TESTING AGENCY ON A REGULAR BASIS.
(UV-1, UV-2, UV-6, UV-8C, UV-12C, UV-24B – UV-100B)
indicates that the UV lamp is satisfactory and the unit is in
good working order.
indicates that the unit needs immediate attention, the audible
alarm will automatically sound when the LED monitor light
switches to red If the lamp has been in service for a year or more
it should be replaced. The quartz sleeve and/or sensor probe
may require cleaning. The alarm will continue until the sensor
detects adequate UV intensity. When a lamp is replaced it is
recommended to clean the quartz sleeve and sensor probe prior
to returning the system to service.
THIS ADVANCED WARNING SYSTEM HAS BEEN INSTALLED
TO PROVIDE YOU WITH THE OPTIMUM PRECAUTIONS TO
ENSURE HIGH EFFICIENCY IN THE PROTECTION AGAINST
MICROBIOLOGICAL CONTAMINATION IN YOUR WATER.
DO NOT DISREGARD THE WARNING LIGHTS.
UV-1C
Page 4
UV-2C
