VGA / HDTV Video Processor
Scalable (Up/Down) Resolution & Mirroring Converter
Changes the resolution and refresh rate of your video signal !
Can also change VGA to HDTV Component and Vice-Versa
Order toll-free in the U.S. 800-959-6439
CUSTOMER
FREE technical support, Call 714-641-6607 or fax 714-641-6698
SUPPORT
1163 Warner Ave. Tustin, CA 92780
Mail order: Hall Research Technologies,
INFORMATION
Web site: www.hallresearch.com • E-mail: info@ hallresearch.com
UMA1063 Rev. 2E
Advertisement
Table of Contents
Related Manuals for HRT SC-VGA-2
Summary of Contents for HRT SC-VGA-2
- Page 1 VGA / HDTV Video Processor Scalable (Up/Down) Resolution & Mirroring Converter Changes the resolution and refresh rate of your video signal ! Can also change VGA to HDTV Component and Vice-Versa Order toll-free in the U.S. 800-959-6439 CUSTOMER FREE technical support, Call 714-641-6607 or fax 714-641-6698 SUPPORT 1163 Warner Ave.
- Page 3 VGA / HDTV Video Processor TRADEMARKS USED IN THIS MANUAL Hall Research, HRT, and (logo) are trademarks of Hall Research Technologies, Inc. IBM is a registered trademark of International Business Machines Corporation. Any other trademarks mentioned in this manual are acknowledged to be the property of the trademark owners.
-
Page 4: Table Of Contents
Model SC-VGA-2 Table of Contents 1. Introduction ..................3 1.1 General..................3 1.2 Features..................3 2. Installation ..................4 2.1 Input connection ................. 4 2.2 Output connection............... 4 2.3 Connection Block Diagram ............5 3. Configuration & Operation..............5 3.1 Front and Rear Panels..............5 3.2 Menus and Adjustments ............. -
Page 5: Introduction
The controls include input/output setup picture adjustment, H/V phase adjustment, System information and many other advance options. The SC-VGA-2 allows you to specify a resolution and refresh rate for its output. Then it will output a steady (uninterrupted) VGA signal to your display device at your specified rate regardless of the input. -
Page 6: Installation
The SC-VGA-2 can automatically detect the mode and resolution of the PC/HDTV input. 2.2 Output connection The SC-VGA-2 can output a variety of PC resolutions as well as a number of HDTV resolutions. When one of the PC resolutions is selected as output, use the 15-pin D- Sub VGA cable to connect the PC/HDTV output of the SC-VGA-2 to the VGA input of a display monitor. -
Page 7: Connection Block Diagram
VGA / HDTV Video Processor 2.3 Connection Block Diagram 3. Configuration & Operation 3.1 Front and Rear Panels 3.2 Menus and Adjustments Pressing the Menu button will bring up the OSD menu controls on the screen as follows:... - Page 8 Model SC-VGA-2 Use +,or - to move the arrow cursor to your desired selection, then press MENU to confirm your selection and enter into sub menu. When it is selected, a sub menu of input signal capture adjustments will appear.
- Page 9 VGA / HDTV Video Processor sampling adjustment range. Using 5-coax extension cables (rather than 3 coax+ 4 TP) maintains the timing differential in long cable runs. Under normal condition the unit automatically detects and shows the input format as YPbPr or RGB. However, you can manually select the YPbPr or RGB to match the format of your input.
- Page 10 When it is selected, it shows the input/output resolution and their vertical refresh rate on the screen. When it is selected the SC-VGA-2 will automatically adjust the capture parameters for the current input video resolution to the factory preset values.
-
Page 11: Troubleshooting
VGA / HDTV Video Processor Notes The default output resolution of the SC-VGA-2 is XGA @ 60Hz. The unit has non-volatile memory and memorizes all your settings before power off and recalls those settings on next power on. Quickly Jumping to XGA or 480p Output... -
Page 12: Specifications
Model SC-VGA-2 5. Specifications General Input Resolutions PC Resolutions HDTV Resolutions 640 X 480@60/72/75/85Hz 1080i 1920 X1080@60Hz VGA 70 720 X 400@70Hz 720p 1280X 720@60Hz VESA 85 640 X 400@85Hz 576p 720X 576@50Hz SVGA 800 X 600@60/72/75/85Hz 576i 720X 576@50Hz... - Page 13 VGA / HDTV Video Processor...
- Page 14 Model SC-VGA-2...
- Page 16 The difference between a “good” installation and a “great” one! ™ © Copyright 2007. Hall Research Technologies, Inc.. All rights reserved. 1163 Warner Ave., Tustin, CA 92780 Ph: (714)641-6607 , Fax: (714)641-6698...
