Paradigm Millenia CT Setup Manual page 2

BEFORE YOU BEGIN, READ THE SAFETY PRECAUTIONS AND IMPORTANT SAFETY INSTRUCTIONS INCLUDED IN THE OWNERS MANUAL.
1
Connect Both Speakers
L
Left cable to left speaker
Right cable to right speaker
4
3
Connect Control Box
Analog connection to TV
(use for good audio)
2
Connect Subwoofer
L
Connect contoller cable to
subwoofer and to control box
4
5 5
4
1
Repeat for
subwoofer
TIP: If after set-up and
"power on" you do not hear
audio, press the "input"
button on the remote.
Digital connection to TV
(use for best audio)
2
3
5
5 5
4
Connect power cable to
subwoofer and to wall outlet
–
+
BASS
BASS
Your subwoofer's LEVEL switch is set to 12
o'clock to suit average preferences. If desired,
adjust to match sound level of your speakers.
Using Sub In Horizontal Position:
IMPORTANT: Use bumper pads (included) to
ensure necessary floor clearance .
OPTIONAL:
A Loosen Bracket, Adjust for Desired
Speaker Angle & Tighten Again
OR
B
To Use Control Box with Apple TV
Connect digital
output cable
For further instructions, refer to your
Apple TV Set-Up Guide.
