MAINTENANCE MANUAL
WARNING: DO NOT USE THE PARTS MANUFACTURE BY ANOTHER
COMPANY WITH YOUR SPACE SCOOTER.
Read and understand this entire manual before replacement the part to your scooter!
DO NOT USE THE PARTS THAT MANUFACTURE BY ANOTHER COMPANY WITH
YOUR SPACE SCOOTER. All parts of Space Scooters have been built to certain
design specifications. The original equipment supplied at the time of sale was selected
on the basis of its compatibility with the frame, fork and all other parts. Parts from other
products may or may not be compatible.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the X580 and is the answer not in the manual?

Questions and answers

Related Manuals for Space Scooter X580

Summary of Contents for Space Scooter X580

  • Page 1 Read and understand this entire manual before replacement the part to your scooter! DO NOT USE THE PARTS THAT MANUFACTURE BY ANOTHER COMPANY WITH YOUR SPACE SCOOTER. All parts of Space Scooters have been built to certain design specifications. The original equipment supplied at the time of sale was selected on the basis of its compatibility with the frame, fork and all other parts.
  • Page 2 Replacement For The Air-Spring System If the Air-Spring system is not working, please replace the new Air-Spring system to it before riding. Tools： Two pcs 5mm Allen wrenches One pcs 17mm open end wrench Steps: 1. Take off the chain from the chain wheel on the front position. Loosen the lock screw on the position in the “U”-header, loosen it by inner hexagon spanner.
  • Page 3 3. Loosen the screw nut of the Air-Spring system. 4. Rotating to take off the Air-Spring system. 5. Check the new Air-Spring system Note： （ 1）Put the Nut nearly at the end of the screw （2）Put in the needle, smooth top end outwards 6.
  • Page 4 7. Tighten and locked the screw on the position of the “U”-header. Tighten and locked the screw nut. 9. Put the chain directly tightening it into the chain wheel position, checking the driving system before riding, make sure there is working well. 10.
  • Page 5 Replacement For The Flywheel If the driving system of flywheel is not working, please replace the new flywheel before riding. Tools: One pcs 4mm Allen wrench One pcs needle nose pliers Step 1: Take off the broken flywheel 1. Place the scooter upside down on the table and take off the chain from 2.
  • Page 6 8. Rotated to remove the both right 7. Remove the rear wheel assembly. and left flywheel. Step 2:Replacing new flywheel: Notice: Assemble the rear wheel and flywheel according the direction on the previous pictures. The scooter cannot run if assembled in wrong direction, and this would result in damage of the rear wheel assembly and flywheel.
  • Page 7 2. Put the scooter body upside down, with the rear part of scooter facing you. 5. Place the rear wheel on the rear 6. Mount on the bearing 6000 wheel frame; note the direction! with both sides. 6. Cover with bearing cap, 5.
