INSTRUCTION MANUAL
Cordless Circular Saw
DHS630
012092
IMPORTANT: Read Before Using.
1

Advertisement

Table of Contents
loading

Related Manuals for Makita DHS630

Summary of Contents for Makita DHS630

  • Page 1 INSTRUCTION MANUAL Cordless Circular Saw DHS630 012092 IMPORTANT: Read Before Using.

  • Page 2: Specifications

    ENGLISH (Original instructions) SPECIFICATIONS Model DHS630 Blade diameter 165 mm at 90° 66 mm Max. Cutting depth at 45° 46 mm No load speed (min 3,100 Overall length 346 mm Net weight 3.5 kg Rated voltage D.C. 18 V • Due to our continuing program of research and development, the specifications herein are subject to change without notice.
  • Page 3 Do not abuse the cord. Never use the cord for 18. Do not use the power tool if the switch does carrying, pulling or unplugging the power tool. not turn it on and off. Any power tool that cannot Keep cord away from heat, oil, sharp edges or be controlled with the switch is dangerous and moving parts.
  • Page 4 Service Always use blades with correct size and shape 28. Have your power tool serviced by a qualified (diamond versus round) of arbour holes. repair person using only identical replacement Blades that do not match the mounting hardware parts. This will ensure that the safety of the power of the saw will run eccentrically, causing loss of tool is maintained.
  • Page 5 To avoid kickback, do support board or panel near the cut. 000154 000194 17. Never force the saw. Push the saw forward at a speed so that the blade cuts without slowing. Forcing the saw can cause uneven cuts, loss of accuracy, and possible kickback.
  • Page 6 Additional safety warnings 23. Use extra caution when cutting damp wood, pressure treated lumber, or wood containing knots. Maintain smooth advancement of tool without decrease in blade speed to avoid overheating the blade tips. 24. Do not attempt to remove cut material when blade is moving.

  • Page 7: Functional Description

    If electrolyte gets into your eyes, rinse them FUNCTIONAL DESCRIPTION out with clear water and seek medical attention right away. It may result in loss of your eyesight. CAUTION: Do not short the battery cartridge: Always be sure that the tool is switched off and the •...

  • Page 8: Adjusting Depth Of Cut

    NEVER use the tool if it runs when you simply pull the switch trigger without pressing the lock-off lever. Return tool a MAKITA service center for proper repairs BEFORE further usage. NEVER tape down or defeat purpose and function •...
  • Page 9 2. Thumb screw CAUTION: Be sure the blade is installed with teeth pointing up • at the front of the tool. Use only the Makita wrench to install or remove the • blade. 1. Shaft lock 012113 2. Hex wrench 3.

  • Page 10: Operation

    When you wish to perform clean cutting operation, Rip fence (Guide rule) connect a Makita vacuum cleaner to your tool. Install the dust nozzle on the tool using the screw. Then connect a 1. Clamp lever hose of the vacuum cleaner to the dust nozzle as shown 2.

  • Page 11: Replacing Carbon Brushes

    If you need any assistance for more details regarding 012101 these accessories, ask your local Makita Service Center. The parallelism between the blade and the base has Saw blades • been factory adjusted. But if it is off, you can adjust it as Rip fence (Guide rule) the following procedure.
  • Page 12 Makita Corporation www.makita.com 885270-0...
