- Page 1 Telegesis TG-ETRX357USB-PM-014-102 ETRX3USB Product Manual 1.02 ® ZigBee USB STICKS: ETRX3USB ETRX3USB-LRS ETRX3USB+8M ETRX3USB-LRS+8M PRODUCT MANUAL ©2013 Telegesis (UK) Ltd ETRX3USB Product Manual (Rev 1.02)
-
Page 2: Table Of Contents
Macintosh and Linux drivers ................... 10 CUSTOM FIRMWARE DEVELOPMENT ................10 ORDERING INFORMATION ..................... 12 TRADEMARKS ......................... 13 DISCLAIMER ........................13 CONTACT INFORMATION ....................13 REFERENCES ........................13 ©2013 Telegesis (UK) Ltd - 2 - ETRX3USB Product Manual (Rev 1.02) -
Page 3: Introduction
The supplied Windows drivers create a virtual COM Port, so that the command line of the ETRX3 series module can be accessed via any terminal software application. ® When using Windows the Telegesis Terminal application can be used as described in the ETRX357 Development Kit manual. 1.1 Supported Operating Systems Windows 98SE... -
Page 4: Absolute Maximum Ratings
3.2 Firmware The Telegesis R3xx firmware does not have any capability of driving the SPI connection to the memory chip. Users will have to write or commission custom firmware to make use of this external memory. ©2013 Telegesis (UK) Ltd - 4 - ETRX3USB Product Manual (Rev 1.02) -
Page 5: Operating Conditions
During USB suspend the current will drop by 25.6mA in all modes. During USB suspend the current will drop by 25.6mA in all modes. Please note that the power consumption in various power modes is firmware and usage dependent. ©2013 Telegesis (UK) Ltd - 5 - ETRX3USB Product Manual (Rev 1.02) -
Page 6: Regulatory Information
Modifications not expressly approved by the manufacturer could void the user's authority to operate the equipment under FCC rules. An FCC declaration of conformity is available separately from the Telegesis website The ETRX3USB and ETRX3USB+8M contain a modular radio transmitter with FCC ID S4GEM35XA. -
Page 7: General
Safety: EN 60950-1:2006 An EC declaration of conformity is available separately from the Telegesis website. Important Note: In Europe the regulations for the 2.4GHz frequency band only permit.a maximum power spectral density of 10mW/MHz, which with a ZigBee spectrum equates to an e.i.r.p of 13dBm. -
Page 8: Driver Installation And Operation
Device Manager under the Windows Computer Management screen (see below) and click on the Ports (COM and LPT) section where you should find the new virtual COM port. By ©2013 Telegesis (UK) Ltd - 8 - ETRX3USB Product Manual (Rev 1.02) - Page 9 Figure 3. Device Manager Once the correct COM port has been selected, the Terminal software can be used to control the ETRX3USB stick as per the Development Kit Manual. Telegesis Terminal is a free download from www.telegesis.com/telegesis_zigbee_technology_-_technical_support_/software_download.htm ©2013 Telegesis (UK) Ltd - 9 - ETRX3USB Product Manual (Rev 1.02)
-
Page 10: Macintosh And Linux Drivers
Support Software download page. Recent versions of the Linux kernel have native support for Telegesis USB devices. The Silicon Laboratories CP2102 serial-to-USB bridge chip is configured with Vendor ID 0x10C4 and Product ID 0x8293, and the drivers must be written to recognise these identifiers. - Page 11 ETRX3USB ©2013 Telegesis (UK) Ltd - 11 - ETRX3USB Product Manual (Rev 1.02)
-
Page 12: Ordering Information
There is no “blank” version of the ETRX357 Module available. All Modules carry both the Silicon Labs Stack and the Telegesis AT style Command Layer. Where customers wish to add their own firmware they can erase and write it to the flash memory of the EM357. -
Page 13: Trademarks
