- Page 1 Hall Research Technologies, Inc 1163 Warner Ave. Tustin, CA 92780 Phone: (714) 641-6607 Fax: (714) 641-6698 ’ ’ Model 800-IEC 8-Channel VGA Video Splitter / Distribution Amplifier UMA1139 Rev. N/C...
- Page 2 Video Splitter/Distribution Amplifier Description The Model 800-IEC is a VGA video splitter that employs the latest technologies in high- resolution video distribution. The device is compact, lightweight, low power, and highly reliable. The splitter terminates; buffers and amplifies the computer's video signal with wide- bandwidth integrated circuits for display on multiple monitors.
-
Page 3: Connection Diagram
Model 800– IEC Video Splitter/Distribution Amplifier Plug-and-Play DDC (Direct Data Channel) is a standard by which a compatible monitor sends its identification and other parameters to a PnP operating system such as Windows 98 etc. Only one of the monitors connected to the splitter is allowed to communicate with the operating system. - Page 4 Warranty HRT warrants that the supplied equipment is free from defective workmanship and material. Subject to the agreements set forth, will repair or replace, at its option, the defective components for a period of 2 years after purchase. The following conditions apply to the Warranty: •...
