SKANTI provides the total
GMDSS communication
package consisting of:
- HF SSB radiotelephones with
200/250/400/750W output
power
- Digital Selective Calling
(DSC) for MF/HF/VHF
- Radiotelex
- VHF/Hand-held VHF
- IBM-compatibel PC and printer
- 2182 kHz watch receiver
- Cospas-Sarsat EPIRB
- Inmarsat terminals
- Wide range of accessories
for system installation
VHF 9110
Advertisement
Table of Contents
Related Manuals for Skanti VHF 9110
Summary of Contents for Skanti VHF 9110
- Page 1 SKANTI provides the total GMDSS communication package consisting of: - HF SSB radiotelephones with 200/250/400/750W output power - Digital Selective Calling (DSC) for MF/HF/VHF - Radiotelex - VHF/Hand-held VHF - IBM-compatibel PC and printer - 2182 kHz watch receiver - Cospas-Sarsat EPIRB...
- Page 2 Monitor switch for listening-in on a channel, irrespective of the squelch level setting. Backlight switch, used to turn-on the illumination of the display and/ or the keyboard, depending on programming. MONITOR LAMP PTT switch. (Call switch, for selective calling.) CALL Microphone. 28442A VHF 9110...
- Page 3 7. Squelch sign, the two digits above indicate the actual squelch setting. 8. Battery low indicator. 9. Keyboard lock indicator. 10. Individual call alarm indicator.* 11. AF-mute indicator.* 12. Tone system ON indicator.* * Functional only in conjunction with optional tone module for selective calling. VHF 9110...
-
Page 4: Table Of Contents
Contents Page Introduction Emergency Batteries Operator's guide Quick channel programming Additional features Installation Rechargeable batteries Mounting of clip Removing clip VHF 9110... -
Page 5: Introduction
Introduction SKANTI VHF 9110, your new VHF-transceiver, is approved to fulfil the GMDSS-requirements to portable VHF-transceivers, and so it is a part of the required safety equipment to be used in an emergency situation. However, the best way to guarantee func-... - Page 6 Furthermore, you have all the international simplex channels, quick selection of distress ch. 16 and two additional user programmable channels, and a lot of other useful features. VHF 9110...
-
Page 7: Emergency
Emergency Procedure for SKANTI VHF 9110 If an emergency situation forces you to leave the ship, do as follows: Remove the top-seal of the orange emer- gency battery package. Insert the battery package into the handheld transceiver unit. Push the... -
Page 8: Batteries
28468 Insert the new battery package into the bottom of the transceiver and press it upwards until it snaps in with a “click”. VHF 9110... -
Page 9: Operator's Guide
To turn on keyboard beep-function. To turn off keyboard beep-function. To change setting of a selected function, Default: Volume level function. To select Tx power level function. To select Channel selection function. To select Squelch level function. To select Volume level function. VHF 9110... - Page 10 To select quick channel A. To select quick channel B. To select distress channel 16. VHF 9110...
-
Page 11: Quick Channel Programming
Press the key (less than 1 sec.) followed by the key you want to programme, A or B , for more than 1 sec. VHF 9110... -
Page 12: Additional Features
Additional features Your SKANTI VHF 9110 has some other features which may show up to be useful in daily use. On the side of the transceiver you will find the following switches (look inside the cover of this folder): “Backlight” switch for turning on/off the key-... - Page 13 LOw level, to extend the remaining operation time of the battery. An audible alarm is heard each 10 seconds until the display readout shows “charGe”, and the set is switched off automatically. VHF 9110...
-
Page 14: Installation
Installation With your SKANTI VHF 9110 you have got a combined holder/charger. If the transceiver NOT is used in the daily work, the primary emergency battery may be stored in the holder. If however the charger is used frequently, the emergency battery must be stored in another place, due to charger heating. -
Page 15: Rechargeable Batteries
The battery must be at normal room temperature when it is charged, and the trans- ceiver must be switched off. WARNING The battery may explode if it is exposed to open fire. VHF 9110... - Page 16 Repeat this procedure at least three times. NOTE! As an option, SKANTI can offer a special charger, which includes a quick-charger and a special recycle feature with measurement and readout of actual battery capacity.
-
Page 17: Mounting Of Clip
Mounting of clip 28457A VHF 9110... -
Page 18: Removing Clip
Removing clip VHF 9110... - Page 19 Please note Any responsibility or liability for loss or damage in connection with the use of this product and the accompanying documen- tation is disclaimed. The information in this manual is furnished for informational use only, is subject to change without notice, may contain errors or inaccuracies, and represents no commitment whatsoever.
