- Page 1 AMBRIDGE AMBRIDGE Industries (Group) Co Ltd. Industries (Group) Co Ltd. ONT G-25E Hardware Installation Manual August 2007 313-12201-02 Rev. B www.cambridgeig.com...
- Page 2 ONT G-25E Hardware Installation Manual Notice The CIG name, the CIG logo, and all CIG product names are trademarks of Cambridge Industries Group Co. Ltd (CIG). All other brand and product names are trademarks of their respective holders. Specifications, products, and products names are subject to change without notice.
- Page 3 ONT G-25E Hardware Installation Manual Product Information To learn more about this product or CIG, contact your local sales representative or contact CIG Marketing at: Address: Hong Kong 25th Floor, Jardine House, 1 Connaught Place Hong Kong, PRC Phone: +852 2827 1778...
-
Page 4: Technical Support
ONT G-25E Hardware Installation Manual Technical Support CIG offers technical support 24 hours a day, 7 days a week. To contact the CIG technical assistance center, use one of the following methods: NOTE: For urgent support requests, please contact CIG by telephone. Delays caused by e- mail may result in a longer response time. - Page 5 ONT G-25E Hardware Installation Manual Compliance with CE Marking Certification (Class B) The equipment was tested and found to comply with EN 60950-1:2001. The equipment is tested and only used with power adaptor included in the package. The equipment complies with the requirements according to the following standard: ETSI EN 300 386 V1.3.3: 2005 Electromagnetic compatibility and radio spectrum Matters...
-
Page 6: Table Of Contents
ONT G-25E Hardware Installation Manual Table of Contents About This Document _________________________________________________________ VI Purpose___________________________________________________________________________ VI Intended Audience _________________________________________________________________ VI Chapter Overview __________________________________________________________________ VI 1. Product Description _________________________________________________________ 1 Introduction __________________________________________________________________ 1 Services ______________________________________________________________________ 1 Features______________________________________________________________________ 1 Specifications _________________________________________________________________ 2 2. Safety... -
Page 7: About This Document
ONT G-25E Hardware Installation Manual About This Document Purpose This guide describes how to install the CIG optical network termination unit (ONT) at the customer premises. Intended Audience This document is intended for technicians responsible for: Unpacking and mounting the ONT and power supply... -
Page 8: Product Description
1.2 Services Equipped with ITU-T G.984 compliant 2.5G Downstream and 1.25G Upstream GPON UPLINK interface, ONT G-25E supports the full Triple Play of services including voice, video (IPTV/VOD), and high speed internet access. ONT G-25E is equipped with the following service interfaces... -
Page 9: Specifications
ONT G-25E Hardware Installation Manual 1.4 Specifications ONT physical, electrical, optical, and environmental specifications and compliance information are listed in the following tables. Dimensions 127mm (height) by 170mm (width) by 39mm (depth) Weight 0.4 KG excluding power adaptor GPON interface... - Page 10 ONT G-25E Hardware Installation Manual Minimum Nominal Maximum Notes Transmitter Wavelength 1260 nm 1310 nm 1360 nm Transmit power 0.5 dBm +5 dBm Digital receiver Wavelength 1480 nm 1490 nm 1500 nm Minimum received power Sensitivity -27 dBm for BER<10-10...
-
Page 11: Safety
This unit can only be used with the certified adaptor model included inside the package, which complies with the requirement of limited power source. DANGER: Do not open the enclosure without CIG’s permission and technical support, which is dangerous and voids the warranty. 313-12201-02 Rev. B: August 2007... -
Page 12: Laser Safety
ONT G-25E Hardware Installation Manual 2.2 Laser Safety CAUTION: Use of controls or adjustments, or performance of procedures other than those specified herein may result in hazardous laser radiation exposure. Invisible laser radiation may be emitted from the ends of un-terminated fiber cables or connectors. -
Page 13: Installation
CAUTION: Please use the power adaptor within the package only, or the replacement unit that provided by CIG. Other power adaptor may cause damage to the ONT and other disasters. 3.2 Connecting to Network Remove the Laser Lock Door (Figure 2). -
Page 14: Connecting Power
ONT G-25E Hardware Installation Manual Figure 3 Plug in the fiber connector Attach the Laser Lock Door to the ONT (Figure 4). Figure 4 Attach the Laser Lock Door Finally it looks like figure below (Figure 5). Figure 5 Connect to network: final view 3.3 Connecting Power... -
Page 15: Connecting Telephone (Pots) Service
ONT G-25E Hardware Installation Manual 3.4 Connecting Telephone (POTS) Service Locate the premises’ telephone wire pair. If the wire pair is not terminated, follow local practices to attach an RJ-11 connector. Plug the wire pair with RJ-11 connector into one of the ONT RJ-11 phone jacks. -
Page 16: Verify The Installation
ONT G-25E Hardware Installation Manual 3.6 Verify the Installation Check LED states to verify ONT status (Section 3.6.1). Services are not available until the ONT is ranged and provisioned in the PON network. If services must be verified at the time of installation, refer to Section 3.6.2 for additional instructions. -
Page 17: Verifying Services
ONT G-25E Hardware Installation Manual 3.6.2 Verifying Services Follow local practices to connect to each active service port in the ONT to confirm service activation. Connect to each active phone jack to verify telephone numbers and services. Verify that the POTS LED lights green when a line is off hook. -
Page 18: Troubleshooting
ONT G-25E Hardware Installation Manual 4. Troubleshooting 4.1 ONT Status LEDs The ONT status LEDs located on the enclosure (Figure 8) assist with installation and maintenance procedures. These LEDs are described in detail in Table 8. Figure 8 ONT Status LEDs location 313-12201-02 Rev. - Page 19 ONT G-25E Hardware Installation Manual LED Name Color Indicates Green/Solid ONT operating from AC power. Green/Quick Flash System Booting. POWER ONT operating from battery power (applicable Green/Flash only for ONT equipped with UPS power interface). Red/Solid Optical interface abnormal (LOS/LOF).
-
Page 20: Troubleshooting Procedures
ONT G-25E Hardware Installation Manual 4.2 Troubleshooting Procedures Problem Possible Solutions Make sure the power cable connector is properly seated in the ONT power input. Verify that the power adapter is plugged into a live AC outlet. The POWER LED is off Check the power cable for shorts or breaks.
