CIG ONT G-25A Hardware Installation Manual

Optical network termination unit

Advertisement

C
C
AMBRIDGE
AMBRIDGE
Industries (Group) Co Ltd.
Industries (Group) Co Ltd.
Hardware Installation Manual
www.cambridgeig.com
CIG
CIG
ONT G-25A
Release 1.2
October 2006
309-12201-01 Rev. A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ONT G-25A and is the answer not in the manual?

Questions and answers

Summary of Contents for CIG ONT G-25A

  • Page 1 AMBRIDGE AMBRIDGE Industries (Group) Co Ltd. Industries (Group) Co Ltd. ONT G-25A Hardware Installation Manual Release 1.2 October 2006 309-12201-01 Rev. A www.cambridgeig.com...
  • Page 2 ONT G-25A Hardware Installation Manual Notice The CIG name, the CIG logo, and all CIG product names are trademarks of Cambridge Industries Group Co. Ltd (CIG). All other brand and product names are trademarks of their respective holders. Specifications, products, and products names are subject to change without notice.
  • Page 3: Product Information

    ONT G-25A Hardware Installation Manual Product Information To learn more about this product or CIG, contact your local sales representative or contact CIG Marketing at: Address: Hong Kong 26th Floor, Jardine House, 1 Connaught Place Hong Kong, PRC Phone: +852 2827 1778...
  • Page 4: Technical Support

    ONT G-25A Hardware Installation Manual Technical Support CIG offers technical support 24 hours a day, 7 days a week. To contact the CIG technical assistance center, use one of the following methods: NOTE: For urgent support requests, please contact CIG by telephone. Delays caused by e- mail may result in a longer response time.
  • Page 5 ONT G-25A Hardware Installation Manual Compliance with CE Marking Certification (Class B) The equipment was tested and found to comply with EN 60951-1:2001. The equipment is tested and only used with power adaptor included in the package. The equipment complies with the requirements according to the following standard: ETSI EN 300 386 V1.3.3: 2005 Electromagnetic compatibility and radio spectrum Matters...
  • Page 6: Table Of Contents

    ONT G-25A Hardware Installation Manual Table of Contents About This Document ___________________________________________________________ i Purpose_____________________________________________________________________________ i Intended Audience ___________________________________________________________________ i Chapter Overview ____________________________________________________________________ i 1. Product Description _________________________________________________________1 Introduction __________________________________________________________________ 1 Services ______________________________________________________________________ 1 Features______________________________________________________________________ 1 Specifications _________________________________________________________________ 2 2. Safety...
  • Page 7: About This Document

    ONT G-25A Hardware Installation Manual About This Document Purpose This guide describes how to install the CIG optical network termination unit (ONT) at the customer premises. Intended Audience This document is intended for technicians responsible for: Unpacking and mounting the ONT and power supply...
  • Page 8: Product Description

    1.2 Services Equipped with ITU-T G.984 compliant 2.5G Downstream and 1.25G Upstream GPON UPLINK interface, ONT G-25A supports the full Triple Play of services including voice, video (Video Overlay or IPTV/VOD), and high speed internet access. ONT G-25A is equipped with the following service interfaces:...
  • Page 9: Specifications

    ONT G-25A Hardware Installation Manual 1.4 Specifications ONT physical, electrical, optical, and environmental specifications and compliance information are listed in the following tables. Excluding bracket: 270mm (height) by 190mm (width) by 60mm (depth) Including bracket, desktop mounting: Dimensions 279mm (height) by 274mm (width) by 162mm (depth)
  • Page 10 ONT G-25A Hardware Installation Manual Minimum Nominal Maximum Notes Transmitter Wavelength 1260 nm 1310 nm 1360 nm Transmit power 0.5 dBm +5 dBm Digital receiver Wavelength 1480 nm 1490 nm 1500 nm Minimum received power Sensitivity -28 dBm for BER<10-10...
  • Page 11: Safety

    SHIN INTERATIONAL ENTERPRISE CORP. which comply with the requirement of limited power source. DANGER: Do not open the box without CIG’s permission and technical support, which is dangerous and will void the warranty. 309-12201-01 Rev. A: October 2006 Cambridge Industries Group Co. Ltd...
  • Page 12: Laser Safety

    ONT G-25A Hardware Installation Manual 2.2 Laser Safety CAUTION: Use of controls or adjustments, or performance of procedures other than those specified herein may result in hazardous laser radiation exposure. Invisible laser radiation may be emitted from the ends of un-terminated fiber cables or connectors.
  • Page 13: Installation

    (input voltage, current, etc.) CAUTION: Please use the power adaptor within the package only, or the replacement unit that provided by CIG. Other power adaptor may cause damage to the ONT. 3.2 Mountings 3.2.1 Install the ONT on Desktop Locate a safe and accessible site for installation.
  • Page 14: Install The Ont On Wall

    ONT G-25A Hardware Installation Manual Figure 2 Install the ONT on desktop 3.2.2 Install the ONT on Wall Locate a safe and accessible site for mounting. Align the ONT mounting bracket vertically on the wall. Mount the bracket into a wall stud by driving the three sheet metal screws into the wall...
  • Page 15: Connecting The Network

    ONT G-25A Hardware Installation Manual Mount the ONT onto the bracket by plastic locker, as shown below: Figure 4 Mount the ONT onto the bracket 3.3 Connecting the Network Remove the screw that secure the Fiber Optic Access Door Open the Fiber Optic Access Door Remove the dust covers from both the ONT’s fiber optic input connector and the SC/APC...
  • Page 16: Connecting The Power

    ONT G-25A Hardware Installation Manual Figure 5 Connecting the network Close the Fiber Optic Access Door and tighten the screw. 3.4 Connecting the Power Wrap the power cable clockwise onto the bracket to get the desired length. Plug the circle two pin 12V DC power connector of power converter to ONT power port...
  • Page 17: Connecting Ethernet Service

    ONT G-25A Hardware Installation Manual DANGER: Please make sure the wire pair connected is from/to the telephone. Using the wire pair from/to the PSTN network falsely may cause damage to user and the device. 3.6 Connecting Ethernet Service Locate the premises’ Ethernet LAN cable.
  • Page 18 ONT G-25A Hardware Installation Manual Figure 6 Cable connections with ONT when installing on desktop Figure 7 Cable connections with ONT when mounting on wall 309-12201-01 Rev. A: October 2006 Cambridge Industries Group Co. Ltd...
  • Page 19: Verify The Installation

    ONT G-25A Hardware Installation Manual 3.8 Verify the Installation Check LED states to verify ONT status (3.8.1). Services are not available until the ONT is ranged and provisioned in the OLT network. If services must be verified at the time of installation, refer to Section 3.8.2 and Section 3.8.3 for additional instructions.
  • Page 20: Activating The Ont

    ONT G-25A Hardware Installation Manual If Data service has been enabled in the network, the DATA LED lights green. If Data service has not been enabled in the network, the DATA LED will be off. 3.8.2 Activating the ONT The ONT is placed into service remotely through the OLT. Services to the ONT are likewise provisioned and turned up remotely through the PON network.
  • Page 21: Troubleshooting

    ONT G-25A Hardware Installation Manual 4. Troubleshooting 4.1 ONT Status LEDs The ONT status LEDs located on the cartridge (Figure 9) assist with installation and maintenance procedures. These LEDs are described in detail in Table 9. TEST GPON DATA OFFH...
  • Page 22 ONT G-25A Hardware Installation Manual LED Name Color Function Green/Solid Operating from AC power Green/Flash Operating from battery power Operating from battery power and battery is in an depleted condition Green ONT is under loopback test ONT is in normal state with local Ethernet...
  • Page 23: Troubleshooting Procedures

    ONT G-25A Hardware Installation Manual 4.2 Troubleshooting Procedures Problem Possible Solutions: Make sure the power cable connector is properly seated in the ONT power input. Verify that the power adapter is plugged into a live AC outlet. The PWR LED is off Check the power cable for shorts or breaks.
