- Page 1 5 0 C C V 3 S E R I E S E DG E 540/E XT R A260/E XT R A300L P /K ATANA YAK 54/YAK 55M /R AVE N/SBAC H 342 SBAC H 300/YAK 55SP /M X2/SUK H O I SU26M /SUK H O I SU29/C O RVUS R AC E R 540 WWW.GOLDWI NGRC.COM...
-
Page 2: I N T R Od U Ct Ion
I NT R O DUC T I O N Thank you for purchasing this excellent almost-ready to fly R/C model!!! This ARF adopts the latest 3Ddesign features and emphasizes high performance,light weight and fun.This plane is designed by professional engineers and built by skilled craftsmen.Many of the parts are already pre-installed for you! We wish you great success in the assembly and flying of your new model. -
Page 3: At T En T Ion
At t en t ion 1.You should not regard this plane as toy! 2.Before the assembly please the careful reading instruction booklet, he can give you the full detail instruction if you are the first contact airplane model public figure, should assemble under the experienced correct instruction! 3.Please inspect in the packing all components, if lacks perhaps the damage, please immediately with dealer relation. -
Page 4: Table Of Contents
TABL E O F C O NT E NT S I n t r od u ct ion -------------------------------------------------------------------- At t en t ion ------------------------------------------------------------------------ Win g Assem b ly----------------------------------------------------------------- Aileron Control Horns -------------------------------------------------------- Aileron Servo Installation ---------------------------------------------------- E leva t or Assem b ly ------------------------------------------------------------- Elevator Servo Installation --------------------------------------------------- Stap Tube Installation --------------------------------------------------------- R u d d er Assem b ly --------------------------------------------------------------... -
Page 5: Win G Assem B Ly
Win g Assem b ly Ailer on C on t r ol H or n s 1.Scuff the horns with sand paper to ensure a good glue bond. 2.Cut the covering from the aileron horns to expose the pre-cut slots. 3.Apply 30 minute epoxy inside the pre-cut slots and coat the horns with epoxy , Insert them into the pre-cut... -
Page 6: Aileron Servo Installation
Ailer on Ser vo I n st a lla t ion M in im u m R eq u ir ed Ser vo: 180 in .oz / M et a l G ea r / Digit a l 1.Use the provided safety clips to secure the servo and servo extension leads. -
Page 7: E Leva T Or Assem B Ly
3mm latest nylon Anodized aluminum ball link assembly long servo arm Epoxy hor n 3X60mm Stainless steel Adjustable pushrod 5. Repeat all the previous steps for the other wing. E leva t or Assem b ly E leva t or ser vo in st a lla t ion M in im u m R eq u ir ed Ser vo: 180 in .oz / M et a l G ea r / Digit a l 1.Pre hinged control... - Page 8 2.Position the servo with the servo wire to the wire pre-slot. Drill 1mm holes for the servo mounting screws using the long aiguille. The serbo label facing the hinge 3.Install servo with M2*12mm servo mounting screws. Use a drop of thick CA glue on each screw to prevent s c r e w s f r o m l o o s e n i n g d u e t o vibration.
-
Page 9: Stap Tube Installation
Epoxy hor n 3mm latest nylon ball link assembly 3X60mm Stainless steel Anodized Adjustable pushrod Al long serbo arm St a b t u b e in st a lla t ion 1.Use the provided safety clips to secure the servo and servo extension leads. -
Page 10: R U D D Er Assem B Ly
4.Install the stab with M3*12mm screws. Secure the screws with Blue Loctite. M3 12 Screw 5.Repeat the previous steps for the remaining stabilizer. R u d d er Assem b ly Pre installed in this location R u d d er H in ge a n d H or n s 1.Remove the covering below to expose the pre-cut slots with a knife. -
Page 11: Rudder Servo Installation
3 Coat the horns with epoxy. Insert them into the pre-cut slots. Install the ball link with M3 16mm screws and locking nuts ightening the nuts is recommended Wipe away excess glue with rubbing alcohol Make sure the horns are correctly aligned and symmetry before the apoxy has cured 4 Scuff the hinges with sand paper to... - Page 12 2.Drill 3mm holes in the AL long arm for installing 3mm ball links and screws. 3 Mount the pre-installed bolt link to the servo arm with the M3*16mm screws and the locking nuts. The pull- pull connector is only threaded half way into the ball link to allow for final adjustment.
-
Page 13: Tail Wheel Installation
C a r b on F ib er Ta il W h eel I n st a lla t ion 1 1 1 2 2 2 1.Drill a 4mm hole and fit the steering ball link.Scuffing the ball link with sand paper to ensure a good glue bond is suggestted before gluing Make sure the ball link hole is parallel to the rudder. -
Page 14: M A In L A N D In G G Ea R Assem B Ly
3 M3 16 4 Mount the tail wheel struts using Tapping screws three M3*16mm tapping screws. Place a drop of thick CA on tail wheel strut tapping screws before inserting in the pre-drilled mounting holes on the bottom rear of the fuse. 2mm Ball link M3X16mm Tapping screw... -
Page 15: Landing Gear Installation
L a n d in g G ea r I n st a lla t ion Straight edge to Front of fuse NOTE: the correct edge in mounting 1.Install the landing gear in the pre d r i l l e d h o l e s w i t h t h e s u p p l i e d M4*25mm screws and locking nuts. -
Page 16: Pants Installation
P a n t s I n st a lla t ion 1(F or YAK ser ies) M3 20mm Screw and lock M5 Axle and Wheel collar 4.Install the inner wheel collar on the axle. screw and tighten the wheel collar in place. -
Page 17: E N Gin E I N St A Lla T Ion
E n gin e I n st a lla t ion DLE 55 engine F ir ewa ll Assem b ly 1.There are two pieces of wooden templates supplied, one for 3W 50cc gasoline engine,the other one for DA50 engine. Select the right template for your engine(if it is 3W 50cc or DA50)to mark the location of mounting holes. -
Page 18: Engine Assembly
2.Use a 4mm bit to drill the engine mounting holes in firewall. 4MM bit E n gin e Assem b ly 1.Use blue loctite to secure the engine mounting bolts(M5*20mm) in place. This will insure that the mounting bolts stay in place over time. M5 flat fender Washers 2.Using M5*25mm mounting bolts and flat fender washers mount engine to... -
Page 19: Throttle Servo Installtion
3.Distance from front of firewall to front of engine prop hub should be proper.Use wood washers(included) to achieve correct distance. T h r ot t le Ser vo I n st a lla t ion 6mm bit 1.Position the hole and use a 6mm bit to drill a pushrod exit hole in the firewall in line with the engine carburetor throttle arm. -
Page 20: Muffler Assembly
4.Assemble the threaded end of pushrod to the servo arm as shown 5.Before mount the servo arm with screws.Turn on the transmitter and plug the servo into receiver. Ensure every channel is neutral.Position the s e r v o a r m 9 0 d e g r e e s t o t h e servo.Finally,Install the pushrod to the servo arm. - Page 21 1 1 1 1 2 1. Use a knife to remove the cover from the pre-cut canister air xit opening. 2 C a r e f u l b e n d t h e f l e x b l e manifold Use the silicone coupler and clamps to join the manifold and the...
-
Page 22: Hatch And Fuel Tank Ignition Module
H a t ch An d F u el Ta n k 1 1 1 1 2 1.Fuel tube interface type has been originally marked,nothing remains but accord to connect well as show. 2.the tank bottom and cabin connect to the tank places had originally sticky connected to the VELCRO. -
Page 23: Ignition And Battery Assembly
I gn it ion a n d t h e b a t t er y Assem b ly 1.Position the ignition module on the side of the engine mounting box and mark the location of the nylon tie holes as shown. -
Page 24: C Owl Assem B Ly
5.Use the provided safety clips to Nilon secure the ignition module and trigger wire.And secure the battery and the ignition module(via switch). Ensure the plugs will not come apart from vibration or light tension. Secure i g n i t i o n w i r e w i t h n y l o n t i e s a s necessary. -
Page 25: F Ligh T P R Ep A R A T Ion
2.Secure the M3 15mm screws with blue loctite Install the cowl with the bolts and check that everything fits correctly and nothing rubs against cowl. 3.The cowl installed show If needed enlarge the cutouts and test fit again until everything fits correctly F ligh t p r ep a r a t ion Win g fin a l a ssem b ly Ф28*888mm carbon fiber tube... -
Page 26: Canopy Assembly
C a n op y Assem b ly New nilon bolt M3 16 1 1 1 1 2 1.Install the canopy to the front of fuselage,tighten the canopy with the nilon bolts. Sym m et r y C on t r ol Adjust the aircraft and make sure both sides are symmetrical.like the diagram shown.so that the plane is ready for... -
Page 27: Location
C G L oca t ion E n gin e Deb u ggin g Trial run the engine to check its stability at high speed and low speed to ensure there are no problems with vibration on the model. Run the motor at high speed about 30 seconds.Check the engine and make sure the temperature is below the prescription of manufacturer. - Page 28 K UZ A win gb a g (Not I n clu d ed ) Do you feel vexed,for damaging the wings in transport? Give your plane the best protection! GW detrusion new product:KUZA-Wingbag. Specialty wingbag can keep wings away from the impact and rubbing. 1.Special bag space to place wing tube ,hardware and other commom tools 2.According to the most popular wing planform.
- Page 31 E XC L USI VE DI ST R I BUTO R S I N T H E W O R L D...
