Goldwingrc is located in the centre of the model plane manufacturing community, the
beautiful coastal city of ZHUHAI, near Hong Kong and close to Macao.
Our general manager ,Paul, who has flown models for 15 years, has won the much
coveted 3D Championship of China, assuring you quality and design of GW products.
GW has a working facility of over 4000sq.Ft. With up-to-date equipment producing an
assortment of R/C model airplanes. Annual average production ranges from 20,000 to
30,000 pcs .Our current focus areas are electric and gasoline aircraft with specialist
accessories. The superior quality and 3D performance of these planes are highly
praised by our American ,European and Japanese customers.
We hope to establish long-term business relationships with friends from around the
world on the basis of mutual equality and benefit.
Address:
No.19, Western Jinfeng Rd,
Jinding science and technology
Zone, Zhuhai ,China
Postcode: 519028
Tel:
86-756-6123059
Fax:
86-756-6123306
Info email: mfg@goldwingrc.com
sales@goldwingrc.com
Sales1@gwplane.com
．
1642378762@qq
com
WWW.GOLDWINGRC.COM
1 0 0 C C V 3 S E R I E S
／
CORVUS
RACER
EDGE540
EXTRA260
／
／
YAK54
SUKHOI
SU26M
SUKHOI
ASSEMBLY MANUAL
／
／
／
EXTRA330SC
YAK55M
YAK55SP
／
／
SU29
MXS
SBACH342
WWW.GOLDWINGRC.COM
Advertisement
Table of Contents
Related Manuals for Gold Wing CORVUS RACER EDGE540
Summary of Contents for Gold Wing CORVUS RACER EDGE540
- Page 1 1 0 0 C C V 3 S E R I E S ／ ／ ／ ／ CORVUS RACER EDGE540 EXTRA260 EXTRA330SC YAK55M YAK55SP ／ ／ ／ ／ YAK54 SUKHOI SU26M SUKHOI SU29 SBACH342 ASSEMBLY MANUAL Goldwingrc is located in the centre of the model plane manufacturing community, the beautiful coastal city of ZHUHAI, near Hong Kong and close to Macao.
-
Page 2: Introduction
INTRODUCTION Thank you for purchasing this excellent almost-ready to fly R/C model!!! This ARF adopts the latest 3Ddesign features and emphasizes high performance,light weight and fun.This plane is designed by professional engineers and built by skilled craftsmen.Many of the parts are already pre-installed for you! We wish you great success in the assembly and flying of your new model. -
Page 3: Attention
Attention 1.You should not regard this plane as toy! 2.Before the assembly please the careful reading instruction booklet, he can give you the full detail instruction if you are the first contact airplane model public figure, should assemble under the experienced correct instruction! 3.Please inspect in the packing all components, if lacks perhaps the damage, please immediately with dealer relation. -
Page 4: Table Of Contents
TABLE OF CONTENTS Introduction -------------------------------------------------------------------- Attention------------------------------------------------------------------------ Wing Assembly----------------------------------------------------------------- Aileron Control Horns -------------------------------------------------------- Aileron Servo Installation ---------------------------------------------------- Elevator Assembly ------------------------------------------------------------- Elevator Servo Installation --------------------------------------------------- Stap Tube Installation --------------------------------------------------------- Rudder Assembly -------------------------------------------------------------- Rudder Horns and Hinges ---------------------------------------------------- ... -
Page 5: Wing Assembly
Wing Assembly Aileron Control Horns 1.Scuff the horns with sand paper to ensure a good glue bond. 2.Pre－ hinged control surface is ready to fly． Remove the covering below to expose the pre-cut slots with a knife. . 3.Apply 30 minute epoxy inside the pre-cut slots and coat the horns with epoxy , Insert them into the pre-cut slots. -
Page 6: Aileron Servo Installation
Aileron Servo Installation Minimum Required Servo:180 in.oz / Metal Gear / Digital Serbo extension safety Connector clip 1.Use the provided safety clips to secure the servo and servo extension leads. 2.The covering of the servo location had been remove as shown.Put the end of the servo extension in the servo location.And then pull the extension l e a d t h r o u g h t o t h e r o o t o f t h e... -
Page 7: Elevator Assembly
Anodized 3mm latest nylon Long servo arm ball link assembly Epoxy hor n 3X60mm Stainless steel Adjustable pushrod 5. Install the arm pushrod and adjust the pushrod length to ensure the aileron and servo are in the neutral position. 6. Repeat all the previous steps for the other servo and wing. Elevator ... - Page 8 Elevator servo installation Minimum Required Servo:180 in.oz / Metal Gear / Digital 1.Pre－ hinged control surface is ready to fly． Remove the covering below to expose the pre-cut slots with a knife. . 2． Scuff the horns with sand paper to ensure a good glue bond.Install the two horns with M3*16mm screw and locking nut.
-
Page 9: Stap Tube Installation
5.Turn on the transmitter. Make sure the servo is in the neutral position. Install the servo arm. Position the servo arm 90 degrees to the servo,and tighten the arm screw. 6 . I n s t a l l t h e a r m p u s h r o d w i t h M3*16mm screws. -
Page 10: Rudder Assembly
Pre－ installed servo wire tube Pre－ installed servo wire tube ． ． 2 1 ． 2.Run the extension lead through the fuselage to the receiver. ． ． ． 2 1 ． 3． Slide the stab tubes in the fuse stab tube sleeves． 4.Install the stab with M3*12mm M3＊... -
Page 11: Rudder Horns And Hinges
Rudder Horns Hinges 1.Remove the covering below to expose the pre-cut slots with a knife. 2. Scuff the middle of horns with sand paper to ensure a good glue bond. Apply 30 minute epoxy inside the pre- cut slots． 3．... -
Page 12: Rudder Servo Installation
Ф1.6*420mm steel wire 5.Fit the rudder by aligning the hinges and inserting the hinge pin from the bottom of the rudder .The length of the hinge pin is enough to prevent the falling after the installation of the wheel tail． The rudder cables and couplers have been pre-installed. - Page 13 3． Mount the pushrod into the ball links and adjust the pushrod length same to the length of servo arm gear. 4． Mount the pre-installed bolt link to the servo arm with the M3*16mm screws and the locking nuts. 5． Remove any slack in the cables and crimp to secure.
- Page 14 Tail Wheel Installation 1.Drill a 6mm hole and fit the steering ball link. 6mm bit 2． Scuffing the ball link with sand paper to ensure a good glue bond is suggestted before gluing． Make sure the ball link hole is parallel to the rudder. ...
-
Page 15: Main Landing Gear Assembly
4． Remove the cover of the pre－ holes． And mount the wheel tail with three M3＊ 12mm screws． M3＊ 12mm screws Three M3＊ Removeable 12mm screws Rudder with a wire ? 1 ． 7 * 3 0 0 m m steel wire §¶ 1 ．5 ＊4 2 0 m m steel wire 3mm ... -
Page 16: Landing Gear Installation
Landing Gear Installation Straight edge to Front of fuse NOTE: the correct edge in mounting 1.Install the landing gear in the pre d r i l l e d h o l e s w i t h t h e s u p p l i e d M4*25mm screws and locking nuts. -
Page 17: Pants Installation
Pants Installation 1(For YAK series) M3＊ 20mm Screw and lock ． ． ． ． Ф5 Axle and Wheel collar 4.Install the inner wheel collar on the axle. screw and tighten the wheel collar in place. Adjust wheel collars in or out until wheel turns freely. Ф5．... -
Page 18: Engine Installation
． ． 1.Install the inner wheel collar on the axle. screw and tighten the wheel collar in place. Adjust wheel collars in or out until wheel turns freely. 2． And then install the wheel pant with two M3＊ 12mm screws． Engine ... -
Page 19: Engine Assembly
2 2 ． 2 1 ． 2． Install the firewall with the angle aluminum， screws and lock nuts． Engine Assembly 1.There are two pieces of wooden t e m p l a t e s s u p p l i e d , o n e f o r DA100，... -
Page 20: Throttle Servo Installtion
Rubber washer ． ． （ Not included） 3.Distance from front of firewall to front of engine prop hub should be proper.Use wood washers to achieve correct distance.r It allows for better shock absorption if you mount the engine with the rubber washer． Throttle Servo Installation 1.Position the hole and use a 6mm bit to 6mm ... -
Page 21: Muffler Assembly
． ． ． ． 4.Assemble the threaded end of pushrod to the servo arm as shown． Secure the screw with blue loctice． The 1－ 4steps depends on the type of the engine． 5.Before mount the servo arm with screws.Turn on the transmitter and plug the servo into receiver. - Page 22 ． ． ． ． ． 1 1 1 1 2 1. Use a knife to remove the cover from the pre-cut canister air ｅ xit opening. 2 ． C a r e f u l b e n d t h e f l e x ｉ b l e manifold． ...
- Page 23 Hatch And Fuel Tank ． ． ． ． 1 1 1 1 2 1.Fuel tube interface type has been originally marked,nothing remains but ． accord to connect well as show. 2 2 ． 2 1 ． 2.The tank bottom and cabin connect to the tank places had originally sticky connected to the VELCRO.You ...
-
Page 24: Ignition And Battery Assembly
Ignition and the battery Assembly 1.Position the ignition module on the side of the engine mounting box and mark the location of the nylon tie holes as shown. 1 4mm bit 2.Use a 4mm bit to drill the ignition module mounting holes. -
Page 25: Cowl Assembly
5.Use the provided safety clips to Nylon secure the ignition module and trigger wire.And secure the battery and the ignition module(via switch). Ensure the plugs will not come apart from vibration or light tension. Secure i g n i t i o n w i r e w i t h n y l o n t i e s a s necessary. -
Page 26: Flight Preparation
2.Secure the M3＊ 15mm screws with blue loctite． Install the cowl with the bolts and check that everything fits correctly and nothing rubs against cowl. NOTE： Special 4.5in fiber spinner of SBACH300 and SBACH342 included. Flight preparation Wing final assembly Ф36*937mm carbon fiber tube ．... -
Page 27: Canopy Assembly
Canopy Assembly ． ． ． ． ． 1 1 1 1 2 1． Us thin CA to secure front hatch hold down dowels.It is highly recommended you apply thin CA glue to the front hold down dowels. This is a High vibration area and can loosen the front dowels. -
Page 28: Control Throws
Control Throws C． G Location E X T R A 2 6 0 E X T R A 3 3 0 S C YA K 5 5 M YA K 5 5 S P Corvus Racer EDGE540 142mm 176mm 166mm 181mm... -
Page 29: Accessories List
ACCESSORIES Description Description Picture Picture Description Description Picture Picture Stab with Stab with Wings Wings Elevator Elevator Epoxy horn Epoxy horn Epoxy horn Epoxy horn AL anodized AL anodized AL anodized AL anodized Semi－ long arm Semi－ long arm Semi－ long arm Semi－... - Page 30 Description Picture Description Picture Carbon main Rudder Landing gear M5＊ 16mm Epoxy horn Hex socket Screw M5＊ 25mm 3mm ball link Hex socket Screw M3＊ 18mm M3 lock nut Hex socket Screw M3＊ 16mm F 5mm Hex socket Wheel axle Screw M3 ...
- Page 31 Description Description Picture Picture Barbon wheel Firewall board Tail plate M8 permanent 2mm under Seat AL screw Firewall board 2mm upper Lock nut Firewall board Φ 4mm wheel 2mm firewall Tail wire Hatch cover M2＊ 8mm Φ Wheel collar Tapping screw 1．...
- Page 32 Description Description Picture Picture Φ 1． 7＊ 300mm Canopy M3＊ 16mm 2mm ball link Nylon bolt 2mm nylon L bend Hexnut Decals M2＊ 8mm screw Instruction disk Servo board Servo fortified Board 5mm allen Provided Wrench Safety clip 3mm allen Wrench 2mm ...
-
Page 33: New Product
NEW PRODUCT KUZA wingbag Do you feel vexed,for damaging the wings in transport? Give your plane the best protection! GW detrusion new product:KUZA-Wingbag. Specialty wingbag can keep wings away from the impact and rubbing. 1.Special bag space to place wing tube ,hardware and other commom tools 2.According to the most popular wing planform. -
Page 34: 100Cc Series Plane
100CC SERIES PLANE... - Page 36 EXCLUSIVE DISTRIBUTORS IN THE WORLD...
