Integrated Socket

Button
FRITZ!Powerline 520E has two buttons:
Button
Reset button
Security button
LAN Port
FRITZ!Powerline 520E has a network port (LAN port) for com-
puters and other network devices.
This port is a gigabit Ethernet port.
2.4 Integrated Socket
The integrated socket on the FRITZ!Powerline 520E replaces
the electrical outlet where the FRITZ!Powerline 520E is
plugged in.
If you need a multi-outlet strip (power outlet strip) at this lo-
cation, plug the multi-outlet strip into FRITZ!Powerline 520E's
integrated socket. The integrated socket is equipped with a
mains filter for low-interference powerline connections.
Always operate the multi-outlet strip on FRITZ!Powerline's in-
tegrated socket. Do not connect FRITZ!Powerline to a multi-
outlet strip.
Function
Restores the factory settings to
FRITZ!Powerline.
Integrates into an existing
powerline network.
8
