Specification; Warranty Information - TaKo Electronics EBi Direct Interpolation DAC User Manual

Specification Specification
Digital audio input Digital audio input
Coaxial terminal:RCA 75Ω (0.5V p-p) x1 Coaxial terminal:RCA 75Ω (0.5V p-p) x1
Optical terminal:Toslink (-24.0 to 14.5dbm peak) x1 Optical terminal:Toslink (-24.0 to 14.5dbm peak) x1
USB port: type B connector.USB 1.1 full speed x1 USB port: type B connector.USB 1.1 full speed x1
supported sampling frequency: supported sampling frequency:
-Coaxial,Optical:32, 44.1, 48, 88.2, 96Khz -Coaxial,Optical:32, 44.1, 48, 88.2, 96Khz
-USB:44.1/48Khz -USB:44.1/48Khz
Analog output Analog output
RCA unbalanced:1.75Vrms(1Khz,full scale,10KΩ) RCA unbalanced:1.75Vrms(1Khz,full scale,10KΩ)
Output impendance:560Ω Output impendance:560Ω
Frequency response:5Hz to 40Khz Frequency response:5Hz to 40Khz
Signal to noise ratio:96db Signal to noise ratio:96db
Total harmonic distortion:0.032% (1Khz) Total harmonic distortion:0.032% (1Khz)
General General
Power supply :AC100~120V,200~240V selectable Power supply :AC100~120V,200~240V selectable
Power consumption:apporx 10W Power consumption:apporx 10W
Operating temperture:+5°C to 35°C Operating temperture:+5°C to 35°C
Dimension:160x220x40mm(WxDxH) Dimension:160x220x40mm(WxDxH)
Weight:1.3Kg Weight:1.3Kg

Warranty Information

Warranty Information
The EBi is backed up by a 3 years warranty, with the remainder transferable between owners, The EBi is backed up by a 3 years warranty, with the remainder transferable between owners,
Upon receipt of the EBi,You should e-mail your model's serial number to warranty@takoelec.com with your Upon receipt of the EBi,You should e-mail your model's serial number to warranty@takoelec.com with your
full name,address ,Serial number and date of purchase - the warranty will begin when this e-mail is received. full name,address ,Serial number and date of purchase - the warranty will begin when this e-mail is received.
The warranty is subject to the following Requirements and understanding. The warranty is subject to the following Requirements and understanding.
1. The EBi must not have been modified in any manner whatsoever, or the warranty is immediately void. 1. The EBi must not have been modified in any manner whatsoever, or the warranty is immediately void.
2. The EBi must not be stored in a humid,damp environment;nor subjected to weather ,water or salt spray. 2. The EBi must not be stored in a humid,damp environment;nor subjected to weather ,water or salt spray.
3. The customer is responsible for the shipping charges for all repairs,warranty or non-warranty, shipped 3. The customer is responsible for the shipping charges for all repairs,warranty or non-warranty, shipped
to TaKo electronics. TaKo electronics will pay for return shipping to the Customer for all warranty repairs. to TaKo electronics. TaKo electronics will pay for return shipping to the Customer for all warranty repairs.
Special shipping method or service will not be covered by TaKo Electronics. Special shipping method or service will not be covered by TaKo Electronics.
