1. List of parts (Fig. 1)
1 Front finger guard
2 Front grip
3 Oil tank cover
4 Safety lock-off
5 On/Off switch
6 Rear grip
7 Mains cable
8 Cable holder
9 Chain wheel cover
10 Bar fastening nut incl. Protective cap
11 Chain bar
12 Saw chain
13 Claw stop

2. Technical data

Power Supply
Power rating:
Cutting length, max.:
Cutting speed at rated rpm:
Oil tank capacity:
Weight without sword + chain:
Protection class:
Guaranteed sound power level under load:
Sound pressure level under load:
Acceleration
(calculated acc. to EN 50144) Front grip under load:
3. Explanation of the signs
1
1. Wear protective headgear, goggles and ear muffs
2. Important! Read the operating instructions and follow the warnings and safety instructions
3. If the cable is damaged, pull out the power plug immediately!
4. Protect from the damp
Rear grip under load:
2
3
Helpline No: UK 0151 649 1500 / IRE 189 094 6244
4
GB
230 V ~ 50 Hz
1800 W
40 cm
13,5 m/s
250 ml
5,3 kg
II /
103 dB(A)
89 dB(A)
5,3 m/s 2
4,8 m/s 2
